- Page 1 Instruction Manual HB30-2INDFZ/TC HB60-4VC/TC HB73-2IND1DVC/TC...
- Page 2 Safety Warnings Your safety is important to us. Please read this information before using your cooktop. Installation Electrical Shock Hazard • Disconnect the appliance from the mains electricity supply before carrying out any work or maintenance on it. • Connection to a good earth wiring system is essential and mandatory. •...
- Page 3 Operation and maintenance Electrical Shock Hazard • Do not cook on a broken or cracked cooktop. If the cooktop surface should break or crack,switch the appliance off immediately at the mains power supply (wall switch) and contact a qualified technician. •...
- Page 4 • Never use your appliance as a work or storage surface. • Never leave any objects or utensils on the appliance. • Never use your appliance for warming or heating the room. • After use, always turn off the cooking zones and the cooktop as described in this manual (i.e.
- Page 5 clients in hotels, motels and other residential type environments ; -bed and breakfast type environments. •WARNING: The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements. Children less than 8 years of age shall be kept away unless continuously supervised.
- Page 6 Read all the safety instructions carefully before use and keep this Instruction / Installation Manual for future reference. Product Overview Top View Model: HB30-2INDFZ/TC (Induction Hob) Model: HB60-4VC/TC (Ceramic Hob) Model: HB73-2IND1DVC/TC (Combined Hob)
- Page 7 Control Panel 1. Heating zone selection controls Model: HB30-2INDFZ/TC (Induction Hob) 2. Timer control 3. Power control 4. Keylock control 5. ON/OFF control 6. Flexible zone power selection Model: HB60-4VC/TC (Ceramic Hob) 1. Heating zone selection controls 2. Timer control 3.
- Page 8 A Word on Induction Cooking Induction cooking is a safe, advanced, efficient, and economical cooking technology. It works by electromagnetic vibrations generating heat directly in the pan, rather than indirectly through heating the glass surface. The glass becomes hot only because the pan eventually warms it iron pot magnetic circuit ceramic glass plate...
- Page 9 Before using your New Hob • Read this guide, taking special note of the ‘Safety Warnings’ section. • Remove any protective film that may still be on your hob. • Do not use cookware with jagged edges or a curved base. •...
- Page 10 Using the Touch Controls • The controls respond to touch, so you don’t need to apply any pressure. • Use the ball of your finger, not its tip. • You will hear a beep each time a touch is registered. •...
- Page 11 3. Touching the heating zone selection control, and the indicator next to the key will flash. 4. Adjust the timer setting by touch the “-“or “+” controls or slide along the “—”control, or just touch any point of the “—”. The minute minder indicator will start flashing and will show in the timer display.
- Page 12 2. Turn the cooking zone off by scrolling down to”0”. Make sure the display shows”0”,then show ”H” and then 3. Turn the whole cooktop off by touching the “ON/OFF” control. 4. Beware of hot surfaces “H” will show which cooking zone is hot to touch. It will disappear when the surface has cooled down to a safe temperature.
-
Page 13: Flexible Zone
Touch the heating zone selection button that you want to boost, an indicator next to the key will flash. Touch the boost button, the heating zone will begin to work at boost mode. The power display will show “P” to indicate that the zone is boosting. The boost power will last for 5 minutes and then the zone will go back to the power stage which was set before boost. - Page 14 As big zone 1. To activate the flexible area as a single big zone, simply press the dedicated key. 2. The power setting works as any other normal area. As two independent zones To use the flexible area as two different zones with different power settings, press the dedicated key again and the zones will return into their old settings.
- Page 15 Auto Shutdown Protection Auto shut down is a safety protection function for your hob. It shut down automatically if ever you forget to turn off your cooking. The default shutdown times are shown in the table below: Power level Default working timer (hour) Using the Timer You can use the timer in two different ways: •...
- Page 16 5. When the time is set, it will begin to count down immediately. The display will show the remaining time and the timer indicator will flash for 5 seconds. 6. Buzzer will beep for 30 seconds and the timer indicator shows “- - “...
- Page 17 5. When the time is set, it will begin to count down immediately. The display will show the remaining time and the timer indicator will flash for 5 seconds. NOTE: The red dot next to power level indicator will illuminate indicating that zone is selected. Setting the timer to turn more than one cooking zone off 1.
- Page 18 Simmering, cooking rice • Simmering occurs below boiling point, at around 85˚C, when bubbles are just rising occasionally to the surface of the cooking liquid. It is the key to delicious soups and tender stews because the flavours develop without overcooking the food. You should also cook egg-based and flourthickened sauces below boiling point.
- Page 19 from about 2 – 8 minutes per side. Press the steak to gauge how cooked it is – the firmer it feels the more ‘well done’ it will be. 5. Leave the steak to rest on a warm plate for a few minutes to allow it to relax and become tender before serving.
- Page 20 Care and Cleaning What? How? Important! • When the power to the cooktop is Everyday soiling on 1. Switch the power to switched off, there will be no ‘hot glass (fingerprints, the cooktop off. marks, stains left by 2. Apply a cooktop cleaner surface’...
- Page 21 Hints and Tips Problem Possible causes What to do The induction No power. Make sure the induction cooker cooker cannot be is connected to the power turned on. supply and that it is switched Check whether there is a power outage in your home or area.
- Page 22 Technical fault. Please note down the error The induction cooker letters and numbers, or a cooking zone switch has turned itself off the power to the induction unexpectedly, a tone cooker off at the wall, and sounds and an error contact a qualified technician.
- Page 23 Technical Specification Model Cooking Supply Rating Product Size Building-in Dimension A×B(mm) Zones Voltage Power L×W×H(mm) HAI-7323 S 2 Zones 220-240V~ 4000W 730 X 430 X 695*410 HAM-7322 2 Zones 220-240V~ 4200W 730 X 430 X 695*410 HAM-7332 3 Zones 220-240V~ 5200W 730 X 430 X 695*410...
- Page 24 Under any circumstances, make sure the Induction cooker cooker is well ventilated and the air inlet and outlet are not blocked. Ensure the Induction cooker cooker is in good work state. As shown below Note: The safety distance between the hotplate and the cupboard above the hotplate should be at least 760mm.
- Page 25 wiring rules allow for this variation of the requirements) • the isolating switch will be easily accessible to the customer with the cooker installed • you consult local building authorities and by-laws if in doubt regarding installation • you use heat-resistant and easy-to-clean finishes (such as ceramic tiles) for the wall surfaces surrounding the cooker.
- Page 26 Cautions 1. The induction hotplate must be installed by qualified personnel or technicians. We have professionals at your service. Please never conduct the operation by yourself. 2. The cooker will not be installed directly above a dishwasher, fridge, freezer, washing machine or clothes dryer, as the humidity may damage the cooker electronics 3.
- Page 27 • If the cable is damaged or to be replaced, the operation must be carried out the by after-sale agent with dedicated tools to avoid any accidents. • If the appliance is being connected directly to the mains an omnipolar circuit-breaker must be installed with a minimum opening of 3mm between contacts.
