Summary of Contents for EVE HB60-2VC1TVC
- Page 1 Instruction Manual CERAMIC HOB HB60-2VC1TVC/TC...
-
Page 2: Safety Warnings
Please read these instructions carefully before attempting to install or use this appliance. It is advisable to keep these instructions in a safe place for future reference. Safety Warnings Your safety is important to us. Please read this information before using your cooktop. Installation Electrical Shock Hazard •... - Page 3 incorporates an isolating switch providing full disconnection from the power supply. • Failure to install the appliance correctly could invalidate any warranty or liability claims.
- Page 4 Operation and maintenance Electrical Shock Hazard • Do not cook on a broken or cracked cooktop. If the cooktop surface should break or crack, switch the appliance off immediately at the mains power supply (wall switch) and contact a qualified technician. •...
- Page 5 • Never use your appliance as a work or storage surface. • Never leave any objects or utensils on the appliance. • Never use your appliance for warming or heating the room. • After use, always turn off the cooking zones and the cooktop as described in this manual (i.e.
- Page 6 clients in hotels, motels and other residential type environments ; -bed and breakfast type environments. •WARNING: The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements. Children less than 8 years of age shall be kept away unless continuously supervised.
- Page 7 Read all the safety instructions carefully before use and keep this Instruction / Installation Manual for future reference. Product Overview Top View Model: HB60-2VC1TVC/TC 1. Ceramic cooker max. 1800 W zone 2. Ceramic cooker max. 1200 W zone 3. Ceramic cooker max.
-
Page 8: Product Information
Product Information The microcomputer induction/ceramic hob can meet different kinds of cuisine demands because of resistance wire heating, micro- computerized control and multi-power selection, really the optimal choice for modern families. indution/ceramic hob centers customers adpots personalized design. The hob has safe and reliable performances, making your life comfortable and enabling to fully enjoy the pleasure from life. -
Page 9: Using The Touch Controls
Using the Touch Controls • The controls respond to touch, so you don’t need to apply any pressure. • Use the ball of your finger , not its tip. • You will hear a beep each time a touch is registered. •... -
Page 10: To Start Cooking
Make sure that the base of your pan is smooth, sits flat against the glass, and is the same size as the cooking zone. Always centre your pan on the cooking zone. Always lift pans off the ceramic cooker – do not slide, or they may scratch the glass. -
Page 11: When You Have Finished Cooking
4. Set the power level by follow operation during the indicator flash: (1)touching the “-”, “+”; • If you don’t set up the power level in 5 second, you will need to start again at step 3. • If you don’t choose a heat setting within 1 minute, the cooker will automatically switch off. -
Page 12: Locking The Controls
4. Beware of hot surfaces“H” will show which cooking zone is hot to touch. It will disappear when the surface has cooled down to a safe temperature. It can also be used as an energy saving function if you want to heat further pans, use the hotplate that is still hot. 5.T ouch the heating zone selection control, then touch key, dual ring zone will begin to work.The LED indicator will light up,which is... -
Page 13: Over Temperature Protection
2. Touch and hold the keylock control /“-” and “+” for 3 seconds. 3. You can now start using your cooker. When the cooker is in the lock mode,all the controls are disable except the ON/OFF , you can always turn the ceramic cooker off with the ON/OFF control in an emergency, but you shall unlock the cooker first in the next operation Over-Temperature Protection... - Page 14 • You can use it as a minute minder when at least one cooking zone is working. In this case, the timer will not turn any cooking zone off when the set time is up. • You can set it to turn one cooking zone off after the set time is up. •...
-
Page 15: Setting The Timer To Turn One Cooking Zone Off
Hint: Touch the “-“ or “+” control of the timer once to decrease or increase by 1 minute. Touch and hold the “-“ or ”+” control of the timer to decrease or increase by 10 minutes. If the setting time exceeds 99 minutes, the timer will automatically return to 00 minute. - Page 16 Or touch the timer control, the timer indicator show “30”. The tens is flashing , setting the tens timer by power level bar. After the tens timer have be set, it will flash 3seconds, and then turn the ones flashing, please setting the timer by power level bar during flashing.
-
Page 17: Cooking Guidelines
Setting the timer to turn more than one cooking zone 1. If more than one heating zone use this function, the timer indicator will show the lowest time. (e.g. zone 1# setting time of 3 minutes, zone 2# setting time of 6 minutes, the timer indicator shows “3”.) NOTE: The red dot next to power level indicator will flash. -
Page 18: Simmering, Cooking Rice
• Using a lid will reduce cooking times and save energy by retaining the heat. • Minimise the amount of liquid or fat to reduce cooking times. • Start cooking on a high setting and reduce the setting when the food has heated through. -
Page 19: Heat Settings
For stir-frying 1. Choose an ceramic compatible flat-based wok or a large frying pan. 2. Have all the ingredients and equipment ready. Stir-frying should be quick. If cooking large quantities, cook the food in several smaller batches. 3. Preheat the pan briefly and add two tablespoons of oil. 4. -
Page 20: Care And Cleaning
Care and Cleaning What? How? Important! Everyday soiling 1. Switch the power to the • When the power to the cooktop on glass cooktop off. is switched off, there will be no (fingerprints, 2. Apply a cooktop cleaner ‘hot surface’ indication but the marks, stains left while the glass is still warm cooking zone may still be hot! -
Page 21: Hints And Tips
Hints and Tips Problem Possible causes What to do The hob cannot be No power. Make sure the hob is turned on. connected to the power supply and that it is switched on. Check whether there is a power outage in your home or area. If you’ve checked everything and the problem persists, call a qualified technician. - Page 22 Pans do not become The induction hob cannot Use cookware suitable for induction hot and appears in detect the pan because it is not cooking. See section ‘Choosing the the display. suitable for induction cooking. right cookware’. The induction hob cannot Centre the pan and make sure that detect the pan because it is too its base matches the size of the...
-
Page 23: Selection Of Installation Equipment
D(mm) A(mm) B(mm) X(mm) HB60-2VC1TVC/TC 50mini Under any circumstances, make sure the Induction cooker cooker is well ventilated and the air inlet and outlet are not blocked. Ensure the Induction cooker cooker is in good work state. As shown below Note: The safety distance between the hotplate and the cupboard above the hotplate should be at least 760mm. - Page 24 A(mm) B(mm) C(mm) 50 mini 30 mini Air intake Air exit 10mm Before you install the cooker, make sure that • the work surface is square and level, and no structural members interfere with space requirements • the work surface is made of a heat-resistant material •...
-
Page 25: Before Locating The Fixing Brackets
• the isolating switch will be easily accessible to the customer with the cooker installed • you consult local building authorities and by-laws if in doubt regarding installation • you use heat-resistant and easy-to-clean finishes (such as ceramic tiles) for the wall surfaces surrounding the cooker . When you have installed the cooker, make sure that •... - Page 26 screw bracket Screw base hole Cautions 1. The induction hotplate must be installed by qualified personnel or technicians. We have professionals at your service. Please never conduct the operation by yourself. 2. The cooker will not be installed directly above a dishwasher , fridge, freezer , washing machine or clothes dryer , as the humidity may damage the cooker electronics 3.
- Page 27 • If the cable is damaged or to be replaced, the operation must be carried out the by after-sale agent with dedicated tools to avoid any accidents. • If the appliance is being connected directly to the mains an omnipolar circuit-breaker must be installed with a minimum opening of 3mm between contacts.
