- Page 1 Alcatel-Lucent OmniPCX Enterprise Communication Server Alcatel-Lucent 3 Port PoE Gigabit Adapter...
- Page 2 Legal notice: Alcatel, Lucent, Alcatel-Lucent and the Alcatel-Lucent logo are trademarks of Alcatel-Lucent. All other trademarks are the property of their respective owners. The information presented is subject to change without notice. Alcatel-Lucent assumes no responsibility for inaccuracies contained herein.
-
Page 3: Chapter 3 Installation
Chapter 1 Introduction to the 3 Port PoE Gigabit Adapter Restriction ....................Functional components ............... LAN port ....................... Phone port ....................PC port ......................Console port RS232C .................. Power connector ..................Power adaptor ....................Power consumption and cabling ............Chapter 2 LED indicators Chapter 3 Installation... -
Page 4: Chapter 4 Configuration
Chapter 4 Configuration Default configuration ................Advanced configuration .............. -
Page 5: Functional Components
1 GB connection for the PC. This feature is not possible if the PC is connected through the IP phone. The Alcatel-Lucent PoE GA can draw power over the Ethernet (PoE), or locally using an adaptor. The Alcatel-Lucent PoE GA provides:... -
Page 6: Power Connector
Chapter You can connect a PC to this port to configure the Alcatel-Lucent PoE GA using a Command Line Interface (CLI). 1.2.5 Power connector This is used to accept power from a 48 V DC local power adaptor. 1.2.6 Power adaptor This is used to supply 48 V DC from local wall power. - Page 7 The Alcatel-Lucent 3 port PoE Gigabit Adapter has single color LEDs to indicate the correct functionality of all the components and functions. The LEDs can be: OFF (if the monitored function or component is not active or connected), ON (if the monitored function is active or connected), BLINKING (if the monitored component is transmitting and receiving).
- Page 8 Chapter...
- Page 9 3 meters if the Alcatel-Lucent PoE GA is powered over Ethernet. Alcatel-Lucent PoE GA PC port to PC: 100 meters. If not using PoE, make sure the Alcatel-Lucent PoE GA is connected to an approved 48 V DC adaptor that is connected to a grounded power outlet.
- Page 10 Chapter...
-
Page 11: Default Configuration
In most cases, the Alcatel-Lucent 3 Port PoE Gigabit Adapter works properly with the default configuration. If any default value needs to be changed, you can connect a PC to the Alcatel-Lucent PoE GA through the RS232 port and use the Command Line Interface (CLI) to change the configuration. - Page 12 To view the other commands that are available, type at the prompt for the Help menu. The following table summarizes the Alcatel-Lucent PoE GA CLI commands and their functions: Command Function To enable auto-negotiation of port speed and...
