- Page 1 USER MANUAL Gas Step Up Hot Plate MODELS: CK HPSU212, CK HPSU424, 06 / 2017 CK HPSU636...
- Page 2 IMPORTANT FOR FUTURE REFERENCE Please complete this information and retain this manual for the life of the equipment. For Warranty Service and/or parts, this information is required. Model Number Serial Number Date Purchased WARNING: For your safety, do not store or use gasoline or other flammable vapors or liquids in the vicinity of this or any other appliances.
-
Page 3: Table Of Contents
Congratulations on your purchase of CPG commercial cooking equipment. CPG takes pride in the design and quality of our products. When used as intended and with proper care and maintenance, you will experience years of reliable operation from this equipment. To ensure best results, it is important that you read and follow the instructions in this manual carefully. -
Page 4: Safety Precautions
LOCATION OF DATA PLATE The data plate is located on the side panel. IMMEDIATELY INSPECT FOR SHIPPING DAMAGE Equipment should be examined for damage before and during unloading. The freight carrier has assumed responsibility for its safe transit and delivery. If equipment is received damaged, either apparent or concealed, a claim must be made with the delivering carrier. -
Page 5: General Installation Instructions
SPECIFICATION AND DIMENSIONS MODEL WIDTH DEPTH HEIGHT # OF BTU/PER W.C. TOTAL IN. (MM) IN. (MM) IN. (MM) BURNERS NAT/LP BTU/ Hr CK HPSU212 12(305) 26.8(680) 18.9(480) 30,000 60,000 6/10 CK HPSU424 26.8(680) 18.9(480) 30,000 120,000 6/10 24(610) CK HPSU636 36(915) 26.8(680) -
Page 6: Conversion
CONVERSION Instructions are for conversion from Natural Gas to Propane (L.P.) on all models. The conversion should be done before connecting the unit to the gas supply. Units are shipped from the factory equipped for use with natural gas. Orifices necessary for LP (propane) are provided in a bag tied to the valve on the front panel. -
Page 7: Lighting Instructions
LIGHTING INSTRUCTIONS Lighting pilot The pilot light on the appliance has been set at the factory. A screwdriver may be required for the first lighting to adjust the flame for your elevation. 1. Turn off the manual valve and wait 5 minutes to clear the gas. 2. -
Page 8: Cleaning & Maintenance
CLEANING & MAINTENANCE CAUTION: Use only non abrasive cleaners. Abrasive cleaners could scratch the finish of your unit, marring it’s appearance and making it susceptible to dirt accumulation. Do not use steel wool, other abrasive cleaners or cleaners/sanitizers containing chlorine, iodine, ammonia or bromine chemicals as these will deteriorate the stainless steel and glass material and shorten the life of the unit. -
Page 9: Explosion View Drawing
EXPLOSION VIEW DRAWING MODEL: CK HPSU424... -
Page 10: Spare Parts List 10
Spare Parts List CK-HPSU212 Dial CK-HPSU424 06.05.1472429 3511473191 CK-HPSU636 Tray CK-HPSU212 01.05.1029410 3511029410(15") CK-HPSU424 01.05.1029318 3511029318(24") CK-HPSU636 01.05.1029365 3511029365(36") CK-HPSU212 Foot CK-HPSU424 01.02.1005373 3511005373 CK-HPSU636 CK-HPSU212 Regulator CK-HPSU424 01.22.1069501 3511069501 CK-HPSU636 CK-HPSU212-NAT CK-HPSU424-NAT 01.20.1068643 CK-HPSU636-NAT Orifice CK-HPSU212-LPG 3511068643 3511068652 CK-HPSU424-LPG 01.20.1068652 CK-HPSU636-LPG CK-HPSU212... - Page 11 CK-HPSU212 Pilot pipe assy.-Front CK-HPSU424 01.24.1071015 3511071015 CK-HPSU636 CK-HPSU212 Main pipe assy.-Front CK-HPSU424 06.05.1473192 3511473192 CK-HPSU636 CK-HPSU212 Main pipe assy.-Rear CK-HPSU424 06.05.1473193 3511473193 CK-HPSU636 CK-HPSU212 Valve connection CK-HPSU424 66.04.1820085 3511820085 CK-HPSU636 CK-HPSU212 Valve CK-HPSU424 01.20.1068502 3511068502 CK-HPSU636 CK-HPSU212 Pilot valve CK-HPSU424 01.20.1068508 3511068508...
-
Page 12: Warranty
G15, G24, G36, G48, G15T, G24T, G36T, G48T Char broilers: CBL15, CBL24, CBL36, CBL48, CBR15, CBR24, CBR36, CBR48 Hot Plates: HP212, HP424, HP636, CK HPSU212, CK HPSU424, CK HPSU636 Fryers: CF15, CF30 All new Cooking Performance Group Griddles, Char broilers, Hot Plates, and Fryers used for commercial purpose are warranted against defects in materials and workmanship under normal use and maintenance.
