Installation Manual For 250.2300 - Non Diverting Tub Spout
BEFORE YOU BEGIN
•
You must observe all local plumbing laws and codes.
•
Do not install this product if it does not meet plumbing codes.
Shut off the main water supply.
•
Ver. 2.53
www.isenbergfaucets.com
NOTICE TO HOMEOWNER
•
We recommend that this product is installed by a qualified
professional plumber.
•
Please check this product immediately to ensure that it has
not been damaged and is complete. Before installation, please
make sure this product is the correct model and you have all
the parts required for installation and use.
•
Please flush the water system to ensure that no metal swarf,
solder, and other impurities can enter the product.
• Turn off water supply before commencing work.
•
Please read these instructions carefully and retain for future
reference.
Made For Responsible Luxury
Advertisement
Table of Contents
Related Manuals for Isenberg 250 Series
Summary of Contents for Isenberg 250 Series
- Page 1 Made For Responsible Luxury Installation Manual For 250.2300 - Non Diverting Tub Spout NOTICE TO HOMEOWNER • We recommend that this product is installed by a qualified professional plumber. • Please check this product immediately to ensure that it has not been damaged and is complete. Before installation, please make sure this product is the correct model and you have all the parts required for installation and use. • Please flush the water system to ensure that no metal swarf, solder, and other impurities can enter the product. • Turn off water supply before commencing work. • Please read these instructions carefully and retain for future reference. BEFORE YOU BEGIN • You must observe all local plumbing laws and codes. • Do not install this product if it does not meet plumbing codes. Shut off the main water supply. • Ver. 2.53 www.isenbergfaucets.com...
- Page 2 Made For Responsible Luxury ROUGH IN SPECIFICATION Fig 1 3/8''~1-3/8'' [9.5mm~35mm] FINISHED WALL PREPARING FOR INSTALLATION The recommended pipe depth to the finished wall is 3/8" -1-3/8" (9.5 mm - 35 mm), as shown in the Fig.1. www.isenbergfaucets.com...
- Page 3 Made For Responsible Luxury INSTALLING THE TUB SPOUT Step 1 Step 2 Before installation, wrap thread sealant tape Tighten the connector (2) over the inlet shank (not included) around the top of the pipe of the pipe (1). Then tighten the ange (not included, 1) in a clockwise direction, (3) over the connector (2).
- Page 4 Made For Responsible Luxury INSTALLING THE TUB SPOUT Step 3 Step 4 Install the spout assembly (1) onto the After installation is complete, remove aerator. connector (2). Be sure the spout assembly Turn on water supply and allow both hot and (1) is resting rmly on the board. Push down cold water to run for at least one minute on spout assembly (1) and tighten set screw each.
