Installation Manual For 250.2410 - Three Hole Roman Tub Faucet
BEFORE YOU BEGIN
•
You must observe all local plumbing laws and codes.
•
Do not install this product if it does not meet plumbing codes.
Shut off the main water supply.
•
Ver. 2.53
www.isenbergfaucets.com
NOTICE TO HOMEOWNER
•
We recommend that this product is installed by a qualified
professional plumber.
•
Please check this product immediately to ensure that it has
not been damaged and is complete. Before installation, please
make sure this product is the correct model and you have all
the parts required for installation and use.
•
Please flush the water system to ensure that no metal swarf,
solder, and other impurities can enter the product.
• Turn off water supply before commencing work.
•
Please read these instructions carefully and retain for future
reference.
Made For Responsible Luxury
Advertisement
Table of Contents
Related Manuals for Isenberg 250.2410
Summary of Contents for Isenberg 250.2410
- Page 1 Made For Responsible Luxury Installation Manual For 250.2410 - Three Hole Roman Tub Faucet NOTICE TO HOMEOWNER • We recommend that this product is installed by a qualified professional plumber. • Please check this product immediately to ensure that it has not been damaged and is complete. Before installation, please make sure this product is the correct model and you have all the parts required for installation and use. • Please flush the water system to ensure that no metal swarf, solder, and other impurities can enter the product. • Turn off water supply before commencing work. • Please read these instructions carefully and retain for future reference. BEFORE YOU BEGIN • You must observe all local plumbing laws and codes. • Do not install this product if it does not meet plumbing codes. Shut off the main water supply. • Ver. 2.53 www.isenbergfaucets.com...
- Page 2 Made For Responsible Luxury INSTALLING THE THREE HOLE ROMAN TUB FAUCET 1-3/8 in. Diamter 1-1/8 in. Diamter 1-3/8 in. Diamter Step 1 Step 2 Shut o the water supply. Remove the old faucet. Loosen the connector (1) from the middle body. Adjust the rubber l l i r washer (2), metal washer (3) and mounting nut (4) to the bottom of middle body.
- Page 3 Made For Responsible Luxury INSTALLING THE THREE HOLE ROMAN TUB FAUCET Fig. 1 keep flush Step 5 Step 6 From underneath the deck, insert the valve body with the washer Connect the hoses (1) to the bottom of the hot and cold end valves (1) and mounting nut (2) through hole on the right (cold) side. From (2 &...
- Page 4 Made For Responsible Luxury INSTALLING THE THREE HOLE ROMAN TUB FAUCET Step 9 Step 10 Ensure the faucet handles are in the o position, and turn on Connect a 1/2 in. IPS faucet connector (not included) to the water supplies underneath the deck using wrenches (not the water supply and check for leaks. If you discover any included).
