OBID i-scan
final
public (B)
2008-05-26
H40801-5e-ID-B.doc
®
ID ISC.MR200
Standard-Reader
from Firmware-Version 1.12
MANUAL

Advertisement

Table of Contents
loading

Related Manuals for Feig Electronic IBID i-scan ID ISC.MR200

Summary of Contents for Feig Electronic IBID i-scan ID ISC.MR200

  • Page 1 ® MANUAL OBID i-scan ID ISC.MR200 Standard-Reader from Firmware-Version 1.12 final public (B) 2008-05-26 H40801-5e-ID-B.doc...
  • Page 2 Composition of the information in this manual has been done to the best of our knowledge. FEIG ELECTRONIC GmbH does not guarantee the correctness and completeness of the details given in this manual and may not be held liable for damages ensuing from incorrect or incomplete information.

  • Page 3: Table Of Contents

    3.4.1. Dedicated Input / Output Functions ................32 3.5. CFG3: RF-Interface ......................33 3.6. CFG4: Transponder Parameters..................35 3.7. CFG5: Anticollision......................37 3.8. CFG6 - 9: Reserved ......................39 3.9. CFG10: Trigger ........................40 3.10. CFG11 Read Mode Data....................42 FEIG ELECTRONIC GmbH Page 3 of 144 H40801-5e-ID-B.doc...
  • Page 4 4. Protocols for Reader Configuration 4.1. [0x80] Read Configuration ....................67 4.2. [0x81] Write Configuration ....................68 4.3. [0x82] Save Configuration....................69 4.4. [0x83] Set Default Configuration (Reset) ................70 5. Protocols for Reader Control 5.1. [0x52] Baud Rate Detection....................71 FEIG ELECTRONIC GmbH Page 4 of 144 H40801-5e-ID-B.doc...
  • Page 5 6.1.5. [0x24] Write Multiple Blocks ..................95 6.1.6. [0x25] Select........................97 6.1.7. [0x26] Reset to Ready ....................98 6.1.8. [0x27] Write AFI......................99 6.1.9. [0x28] Lock AFI......................100 6.1.10. [0x29] Write DSFI ....................101 6.1.11. [0x2A] Lock DSFI.....................102 FEIG ELECTRONIC GmbH Page 5 of 144 H40801-5e-ID-B.doc...
  • Page 6 8. Supported ISO15693 Host commands for I-Code EPC Transponders 9. Supported ISO15693 Host commands for I-Code UID Transponders 10. Protocols for Buffered Read Mode 10.1. The Buffered Read Mode Procedure ................130 10.2. Transponder Access in the Buffered Read Mode ............131 FEIG ELECTRONIC GmbH Page 6 of 144 H40801-5e-ID-B.doc...
  • Page 7 ANNEX E: Codes of Reader Types ..................143 ANNEX I: Examples for Read Data ..................144 ISO15693 Host Command (DB-Size of the Transponder = 4 bytes)........144 ISO15693 Host Command (DB-Size of the Transponder = 8 bytes)........144 FEIG ELECTRONIC GmbH Page 7 of 144 H40801-5e-ID-B.doc...

  • Page 8: Revision History Of Documentation

    WLAN Settings Configuration of Scan Mode 09.06.06 Integration of Notification Mode 25.09.06 Configuration of Notification Mode Supported Antenna Multiplexing 04.10.06 Configuration of Trigger Configuration of Reader Login 26.05.08 Configuration of Costumer Parameter FEIG ELECTRONIC GmbH Page 8 of 144 H40801-5e-ID-B.doc...

  • Page 9: Abbreviations

    Most Significant Byte Number Output Read / Write Access Read Relay Radio Frequency RSSI Received Signal Strength Indicator Real Time Clock Table Transponder Timeslot Unique Identifier (read only Serial Number) Write Only Access Write FEIG ELECTRONIC GmbH Page 9 of 144 H40801-5e-ID-B.doc...

  • Page 10: Data Transmission Between Obid I-Scan ® Id Isc.mr200 And Host

    The Reader control is immediately processed and the response from the Reader contains status or data information of the control command. Host (Terminal / PC / ..) Reader parameter- / control command parameter received and stored / control command processed status / error status data FEIG ELECTRONIC GmbH Page 10 of 144 H40801-5e-ID-B.doc...

  • Page 11: Iso15693 Host Commands

    = Transponder read no Transponder data in Reader field write data to Transponder with UID Transponder with correct UID in antenna field ? OK status status = no Transponder in Reader field FEIG ELECTRONIC GmbH Page 11 of 144 H40801-5e-ID-B.doc...

  • Page 12: 0X66] Get Reader Info

    Transponder in antenna field ? status / status = no Trans- Transponder read ponder data in Reader field write data Transponder in antenna field ? OK status status = no Trans- ponder in Reader field FEIG ELECTRONIC GmbH Page 12 of 144 H40801-5e-ID-B.doc...
  • Page 13 Transponder in antenna field ? status / status = Transponder read no Transponder data in Reader field write data selected Transponder in antenna field ? OK status status = no Transponder in Reader field FEIG ELECTRONIC GmbH Page 13 of 144 H40801-5e-ID-B.doc...

  • Page 14: Buffered Read Mode

    Transponder data read ? OK status status = no valid data Note: Only read operations are available with the Buffered Read Mode. The Buffered Read Mode is only available if Scan Mode is disabled FEIG ELECTRONIC GmbH Page 14 of 144 H40801-5e-ID-B.doc...

  • Page 15: Notification Mode

    (s. CFG41/CFG43) of a LAN/WLAN con- nection initiated by a host. Note: The MR200-Reader does support only one TCP/IP – Connection at the same time. The reader hardware version FE556/4 is necessary for using the Notification Mode. FEIG ELECTRONIC GmbH Page 15 of 144 H40801-5e-ID-B.doc...

  • Page 16: Scan Mode

    2 Transponder in detection range UID and data block should be read: UID1 data1 UID2 data2 Com-Prefix (optional) SCAN-LOCK-TIME UID: Serial-Number (fix) time to the next new Transponder reading data: data blocks (free programmable) Separation character (optional) End character (optional) FEIG ELECTRONIC GmbH Page 16 of 144 H40801-5e-ID-B.doc...
  • Page 17 Transponder should be within the detection range of the Reader during this time. Only read operations are available with the Scan Mode. Scan Mode is only available if Buffered Read Mode is disabled FEIG ELECTRONIC GmbH Page 17 of 144 H40801-5e-ID-B.doc...

  • Page 18: Interface

    Reader. If you use the TCP/IP protocol please be aware that the data packaged in the TCP/IP frame is trans- ferred with Protocol frame: Advanced Protocol-Length as describe below. FEIG ELECTRONIC GmbH Page 18 of 144 H40801-5e-ID-B.doc...

  • Page 19: Serial Data Format And Protocol Frames

    Protocol frame: Advanced Protocol-Length Reader m Host (6...n-2) CONTROL- © COM-ADR (DATA) (0x02) ALENGTH ALENGTH BYTE ª CRC16 CRC16 Host m Reader (7...n-2) CONTROL- © COM-ADR STATUS (DATA) (0x02) ALENGTH ALENGTH BYTE ª CRC16 CRC16 FEIG ELECTRONIC GmbH Page 19 of 144 H40801-5e-ID-B.doc...

  • Page 20: Set Output Examples

    Cyclic redundancy check of the protocol bytes from 1 to n-2, as specified by CCITT- CRC16 Polynom: + 1 (0x8408) Start Value: 0xFFFF Direction: Backward see ANNEX D: Index of Status Bytes FEIG ELECTRONIC GmbH Page 20 of 144 H40801-5e-ID-B.doc...

  • Page 21: Crc16 Calculation Algorithm

    /* cnt = number of protocol bytes without CRC */ crc ^= DATA[i]; for (j = 0; j < 8; j++) if (crc & 0x0001) crc = (crc >> 1) ^ CRC_POLYNOM; else crc = (crc >> 1); FEIG ELECTRONIC GmbH Page 21 of 144 H40801-5e-ID-B.doc...

  • Page 22: Configuration Parameters (Cfg)

    If BRM-Mode is enable, an RF OFF stops the communication and ISO-Host commands are al- lowed. With a RF ON command the BRM-Mode starts again. see ANNEX D: Index of Status Bytes see ANNEX D: Index of Status Bytes FEIG ELECTRONIC GmbH Page 77 of 144 H40801-5e-ID-B.doc...

  • Page 23: Protocols For Iso15693 Host Commands

    6.1.9. [0x28] Lock AFI — 6.1.10. [0x29] Write DSFI — 6.1.11. [0x2A] Lock DSFI — 6.1.12. [0x2B] Get System Information — 6.1.13. [0x2C] Get Multiple Block Security Status only Philips I-Code UID FEIG ELECTRONIC GmbH Page 86 of 144 H40801-5e-ID-B.doc...

  • Page 24: Cfg0: Passwords

    RESPONSE-DATA: Command specific response Notes: x Data is only transferred if STATUS = 0x00, 0x83, 0x94, 0x95. x These commands aren’t available if Scan-Mode, Buffered Read Mode, or Notification Mode is active. FEIG ELECTRONIC GmbH Page 87 of 144 H40801-5e-ID-B.doc...

  • Page 25: 0X01] Inventory

    Bit: Function MORE MORE: new Inventory requested more data requested (IF Status 0x94 appears-> more data sets are available) DATA-SETS: Number of Transponder data sets to be transferred in this Reader response. FEIG ELECTRONIC GmbH Page 88 of 144 H40801-5e-ID-B.doc...
  • Page 26 I-Code EPC Transponder type. UID: For UID Transponder: the 19 Byte Identifier Data (IDD) will be displayed. Identifier Data (IDD): User Data UD CRC 16 (Read/Write) (Read/Write) (ReadOnly) DB 0-11 DB12-13 DB14-18 FEIG ELECTRONIC GmbH Page 89 of 144 H40801-5e-ID-B.doc...
  • Page 27 STATUS Byte 0x94 (More Data) is displayed dependence on the Tag Typ: Tr-Type ISO15693 I-Code EPC 96 I-Code UID amount of Trans- ponder setting status 0x94 > 50 > 38 > 25 (with Advanced Protocol Length) FEIG ELECTRONIC GmbH Page 90 of 144 H40801-5e-ID-B.doc...

  • Page 28: 0X02] Stay Quiet

    This command sets one Transponder to Quiet State. REQUEST-DATA 6-13 0x02 MODE MODE: Bit: Function ADR: b001 addressed UID: Read only UID of the Transponder. Note: x This command is only available for ISO15693Transponders. FEIG ELECTRONIC GmbH Page 91 of 144 H40801-5e-ID-B.doc...

  • Page 29: 0X22] Lock Multiple Blocks

    Number of data blocks to be locked, starting at DB-ADR. The maximum number of DB-N is ISO15693 ERROR: ISO15693 ERROR code of Transponder response. This byte is only available if STATUS = 0x95. DB-ADR-E: Block number where the error occurred. FEIG ELECTRONIC GmbH Page 92 of 144 H40801-5e-ID-B.doc...

  • Page 30: Cfg2: Inputs / Outputs General

    The maximum number of DB-N, depend on DB-Size and the interface transmit buffer size TX- BUF. The maximum number of DB-N is: (TX-BUF - 10 )/(DB-Size+1) ISO15693 ERROR: ISO15693 ERROR code of Transponder response. This byte is only available if STATUS = 0x95. FEIG ELECTRONIC GmbH Page 93 of 144 H40801-5e-ID-B.doc...
  • Page 31 If a Transponder does not support Read Multiple Blocks commands several Read Single Block commands are used for this Transponder. x Only one Transponder can be read in the non-addressed mode. FEIG ELECTRONIC GmbH Page 94 of 144 H40801-5e-ID-B.doc...

  • Page 32: Dedicated Input / Output Functions

    Number of bytes of one data block. This value depend on the specification of the Trans- 7.1. ) Supported ISO15693 Host commands for ponder manufacturer, see chapter ISO15693 Transponders. DB-SIZE must be 1 for the I-CODE EPC Transponder. FEIG ELECTRONIC GmbH Page 95 of 144 H40801-5e-ID-B.doc...

  • Page 33: Cfg3: Rf-Interface

    A write command on I-Code UID and EPC Transponders can only be performed in the non- addressed mode whereas the block-size (DB-SIZE) must be 1 Byte. x If an I-Code UID and EPC Transponder is already locked, the reader answers with status = [0x03]. FEIG ELECTRONIC GmbH Page 96 of 144 H40801-5e-ID-B.doc...

  • Page 34: 0X25] Select

    Read-only UID of the Transponder. ISO15693 ERROR: ISO15693 ERROR code of Transponder response. This byte is only available if STATUS = 0x95. Note: x This command is only available for ISO15693 Transponders. FEIG ELECTRONIC GmbH Page 97 of 144 H40801-5e-ID-B.doc...

  • Page 35: Cfg4: Transponder Parameters

    Read-only serial number of the Transponder. The UID is required only in the addressed mode. ISO15693 ERROR: ISO15693 ERROR code of Transponder response. This byte is only available if STATUS = 0x95. Note: x This command is only available for ISO15693 Transponders. FEIG ELECTRONIC GmbH Page 98 of 144 H40801-5e-ID-B.doc...

  • Page 36: 0X27] Write Afi

    Application Family Identifier of the Transponder. ISO15693 ERROR: ISO15693 ERROR code of Transponder response. This byte is only available if STATUS = 0x95. Note: x This command is only available for ISO15693 Transponders. FEIG ELECTRONIC GmbH Page 99 of 144 H40801-5e-ID-B.doc...

  • Page 37: Cfg5: Anticollision

    Read-only serial number of the Transponder. The UID is required only in the addressed mode. ISO15693 ERROR: ISO15693 ERROR code of Transponder response. This byte is only available if STATUS = 0x95. Note: x This command is only available for ISO15693 Transponders. FEIG ELECTRONIC GmbH Page 100 of 144 H40801-5e-ID-B.doc...

  • Page 38: 0X29] Write Dsfi

    Data Storage Format Identifier of the Transponder. ISO15693 ERROR: ISO15693 ERROR code of Transponder response. This byte is only available if STATUS = 0x95. Note: x This command is only available for ISO15693 Transponders. FEIG ELECTRONIC GmbH Page 101 of 144 H40801-5e-ID-B.doc...

  • Page 39: Cfg6 - 9: Reserved

    Read-only serial number of the Transponder. The UID is required only in the addressed mode. ISO15693 ERROR: ISO15693 ERROR code of Transponder response. This byte is only available if STATUS = 0x95. Note: x This command is only available for ISO15693 Transponders. FEIG ELECTRONIC GmbH Page 102 of 144 H40801-5e-ID-B.doc...

  • Page 40: Cfg10: Trigger

    The LSB (32bits) from the Read only Serial Number of the Transponder. AFI: Application Family Identifier. If not supported by the Transponder, this value will return 0x00. Manufacturer Code: Manufacturer specific code (see: ANNEX A: Codes of Transponder Types) FEIG ELECTRONIC GmbH Page 103 of 144 H40801-5e-ID-B.doc...
  • Page 41 IC reference (version) of the Transponder. If not supported by the Transponder, this value will return 0x00. Chip Version: Chip version of the Transponder Note: This command is only available for ISO15693 Transponders. FEIG ELECTRONIC GmbH Page 104 of 144 H40801-5e-ID-B.doc...

  • Page 42: Cfg11 Read Mode Data

    The maximum number of DB-N is 255. ISO15693 ERROR: ISO15693 ERROR code of Transponder response. This byte is only available if STATUS = 0x95. SEC-STATUS: Block security status . Note: This command is only available for ISO15693 Transponders FEIG ELECTRONIC GmbH Page 105 of 144 H40801-5e-ID-B.doc...
  • Page 43 302Ps. If there is no response within 20ms the command sends back Status “no Transponder” 0x01 b011 = write request with Option “1” The Reader tries to sample the response after CMD-RES-DELAY. If there is see ANNEX D: Index of Status Bytes FEIG ELECTRONIC GmbH Page 106 of 144 H40801-5e-ID-B.doc...
  • Page 44 Reader should code the data in the RF forward link and decode the data in the RF return link. TxCRCEn: A CRC is calculated over the transmitted data and the CRC byte(s) are appended to the data stream FEIG ELECTRONIC GmbH Page 107 of 144 H40801-5e-ID-B.doc...
  • Page 45 The response data ever contains the in RSP-LENGTH defined number of data bytes. Note: x This command is only available for ISO15693 Transponders. x This command is not available if the Scan Mode or Buffered Read Mode is switched on. FEIG ELECTRONIC GmbH Page 108 of 144 H40801-5e-ID-B.doc...
  • Page 46 If the EPC doesn't match, the reader also answers with status [0x83]. x If the command was not successfully (reader may continue read the EPC), the reader an- swers with status [0x03]. FEIG ELECTRONIC GmbH Page 109 of 144 H40801-5e-ID-B.doc...
  • Page 47 Reading of one block in non addressed mode is only possible, if parameter “Read Mode” in CFG4 is set to “10: Multiple Read“. The WR-OPTION will be set automatically by the FEIG Readers if the WR-OPTION parameter in “CFG4 Transponder Parameters” is set to “00: automatically set”. FEIG ELECTRONIC GmbH Page 110 of 144 H40801-5e-ID-B.doc...
  • Page 48 Reading of one block in non addressed mode is only possible, if parameter “Read Mode” in CFG8 is set to “10: Multiple Read“. The WR-OPTION will be set automatically by the FEIG Readers if the WR-OPTION parameter in “CFG4 Transponder Parameters” is set to “00: automatically set”. FEIG ELECTRONIC GmbH Page 111 of 144 H40801-5e-ID-B.doc...
  • Page 49 The WR-OPTION will be set automatically by the FEIG Readers if the WR-OPTION parameter is set to “00: automatically set”. Up to two blocks of data can be written for one request. FEIG ELECTRONIC GmbH Page 112 of 144 H40801-5e-ID-B.doc...
  • Page 50 The WR-OPTION will be set automatically by the FEIG Readers if the WR-OPTION parameter is set to “00: automatically set”. Up to two blocks of data can be written for one request. FEIG ELECTRONIC GmbH Page 113 of 144 H40801-5e-ID-B.doc...
  • Page 51 The WR-OPTION will be set automatically by the FEIG Readers if the WR-OPTION parameter is set to “00: automatically set”. Up to two blocks of data can be written for one request. FEIG ELECTRONIC GmbH Page 114 of 144 H40801-5e-ID-B.doc...
  • Page 52 “CFG4 Transponder Parameters” is set to “00: automatically set”. The user has to take the Custom Specific Commands Read [0x10], Write [0x30] and the Wri- te Byte [0x90]. The commands will be not used automatically by the Reader. FEIG ELECTRONIC GmbH Page 115 of 144 H40801-5e-ID-B.doc...
  • Page 53 Get Multiple Block Security — — — — 0x2C Status The WR-OPTION will be set automatically by the FEIG Readers if the WR-OPTION parameter in “CFG4 Transponder Parameters” is set to “00: automatically set”. FEIG ELECTRONIC GmbH Page 116 of 144 H40801-5e-ID-B.doc...
  • Page 54 “CFG4 Transponder Parameters” is set to “00: automatically set”. Reading of more than one block in non addressed mode is only possible, if parameter “Read Mode” in CFG4 is set to “01: Single Read“. FEIG ELECTRONIC GmbH Page 117 of 144 H40801-5e-ID-B.doc...
  • Page 55 — — 0x2C Get Multiple Block Security Status The WR-OPTION will be set automatically by the FEIG Readers if the WR-OPTION parameter in “CFG4 Transponder Parameters” is set to “00: automatically set”. FEIG ELECTRONIC GmbH Page 118 of 144 H40801-5e-ID-B.doc...
  • Page 56 “CFG4 Transponder Parameters” is set to “00: automatically set”. Reading of more than one block in non addressed mode is only possible, if parameter “Read Mode” in CFG4 is set to “01: Single Read“. FEIG ELECTRONIC GmbH Page 119 of 144 H40801-5e-ID-B.doc...
  • Page 57 “ CFG4 Transponder Parameters” is set to “00: automatically set”. Reading of more than one block in non addressed mode is only possible, if parameter “Read Mode” in CFG4 is set to “01: Single Read“. FEIG ELECTRONIC GmbH Page 120 of 144 H40801-5e-ID-B.doc...
  • Page 58 ”CFG4 Transponder Parameter” is set to “00: automatically set”. Reading of more than one block in non addressed mode is only possible, if parameter “Read Mode” in CFG4 is set to “01: Single Read“. FEIG ELECTRONIC GmbH Page 121 of 144 H40801-5e-ID-B.doc...
  • Page 59 ”CFG4 Transponder Parameter” is set to “00: automatically set”. Reading in non addressed mode is only possible, if parameter “Read Mode” is set to “01”: Single Read“ and DB-Blocksize is set to “1” in CFG4. FEIG ELECTRONIC GmbH Page 122 of 144 H40801-5e-ID-B.doc...
  • Page 60 ”CFG4 Transponder Parameter” is set to “00: automatically set”. Reading of LRIS2k in non addressed mode is only possible, if parameter “Read Mode” is set to “01”: Single Read“ in CFG4. FEIG ELECTRONIC GmbH Page 123 of 144 H40801-5e-ID-B.doc...
  • Page 61 Single Read — — — — 0x24 Write Multiple Blocks 0x25 Select 0x26 Reset to Ready 0x27 Write AFI 0x28 Lock AFI 0x29 Write DSFID 0x2A Lock DSFID 0x2B Get System Information FEIG ELECTRONIC GmbH Page 124 of 144 H40801-5e-ID-B.doc...
  • Page 62 The WR-OPTION will be set automatically by the FEIG Readers if the WR-OPTION parame- ter in “CFG4 General” is set to “00: automatically set”. When using the “non-addressed” mode the WR-OPTION must be set manually to “WR- OPTION = 1”. FEIG ELECTRONIC GmbH Page 125 of 144 H40801-5e-ID-B.doc...
  • Page 63 Inventory Read Multiple Blocks 0xAB Inventory Get System Infor- mation 0xAC Inventory Get Multiple Block Security Status — — — — 0xA2 Write 2 Blocks — — — — 0xA3 Lock 2 Blocks FEIG ELECTRONIC GmbH Page 126 of 144 H40801-5e-ID-B.doc...
  • Page 64 This will only become an effect if the block address starts with an even-numbered ad- dress. In the case of writing / locking an odd number of blocks the “Write_2_Blocks”/“Lock_2_Blocks” command will be combined with the “write single Block”/ “Lock single Block” command. FEIG ELECTRONIC GmbH Page 127 of 144 H40801-5e-ID-B.doc...
  • Page 65 Reset to Ready 0x27 Write AFI 0x28 Lock AFI 0x29 Write DSFID 0x2A Lock DSFID 0x2B Get System Information Get Multiple Block Security 0x2C Status 0xA0 Read Config Block 0xA1 Write Config Block FEIG ELECTRONIC GmbH Page 128 of 144 H40801-5e-ID-B.doc...
  • Page 66 Reset to Ready 0x27 Write AFI 0x28 Lock AFI 0x29 Write DSFID 0x2A Lock DSFID 0x2B Get System Information Get Multiple Block Security 0x2C Status 0xA0 Read Config Block 0xA1 Write Config Block FEIG ELECTRONIC GmbH Page 129 of 144 H40801-5e-ID-B.doc...

  • Page 67: Cfg1: Interface

    Host is able to do other jobs e.g. to communicate with other Readers Additional information about the capacity of the data buffer can be determined with the 10.4. [0x31] Read Data Buffer Info command. FEIG ELECTRONIC GmbH Page 130 of 144 H40801-5e-ID-B.doc...
  • Page 68 The Buffered Read Mode only reads data blocks from the Transponders in the antenna field The anticollision procedure can be configured in the 3.7. CFG5: Anticollision configuration block. con- figuration block are used. FEIG ELECTRONIC GmbH Page 131 of 144 H40801-5e-ID-B.doc...
  • Page 69 DB = data block Byte Order = b0:MSB first, b1:LSB first ANT-No = Antenna number if a antenna multiplexer is used. Without multiplexer it is set to TIMER = internal system timer FEIG ELECTRONIC GmbH Page 132 of 144 H40801-5e-ID-B.doc...
  • Page 70 Transponder is read will by set in the bit field. Bit: Function ANT8 ANT7 ANT6 ANT5 ANT4 ANT3 ANT2 ANT1 FEIG ELECTRONIC GmbH Page 133 of 144 H40801-5e-ID-B.doc...
  • Page 71 This command is only available in the Buffered Read Mode. x Data are only transferred if STATUS = 0x00, 0x83, 0x84, 0x93, 0x94. x If STATUS = 0x83, 0x84, 0x85 the TR-DATA and DATA SETS will be always trans- ferred. FEIG ELECTRONIC GmbH Page 134 of 144 H40801-5e-ID-B.doc...
  • Page 72 Number of Transponder data sets reserved in the data buffer. Notes: x Additional information about the data table status is transferred if STATUS = 0x00, 0x84, 0x85, 0x93. see ANNEX D: Index of Status Bytes FEIG ELECTRONIC GmbH Page 135 of 144 H40801-5e-ID-B.doc...
  • Page 73 The command Initialize Buffer clears the data buffer to an initial state. It does not matter if the data sets in the data buffer were read or not. Host o Reader 4...5 COM-ADR [0x33] CRC16 Host m Reader 5...6 COM-ADR [0x33] STATUS CRC16 see ANNEX D: Index of Status Bytes FEIG ELECTRONIC GmbH Page 136 of 144 H40801-5e-ID-B.doc...
  • Page 74 ANNEX A: Codes of Transponder Types Value Transponder type 0x03 ISO15693 Tags 0x06 Philips I-Code EPC 0x07 Philips I-Code UID The Information will be send by performing the 6.1.1. [0x01] Inventory command. FEIG ELECTRONIC GmbH Page 137 of 144 H40801-5e-ID-B.doc...
  • Page 75 1 Block (16 Bytes) all ( 8 ) Blocks 5.7. [0x69] RF Reset 6.1. [0xB0] Host com- mands for ISO15693 Man- datory and Optional Com- mands as configured in 3.3. CFG1: Interface TR-RESPONSE-TIME FEIG ELECTRONIC GmbH Page 138 of 144 H40801-5e-ID-B.doc...
  • Page 76 The extent of the data that needs to be read or written Types of Transponders supported by the Reader, Position of the Transponder at the time of the requirement, Probable local electromagnetic interferences present. FEIG ELECTRONIC GmbH Page 139 of 144 H40801-5e-ID-B.doc...
  • Page 77 The timing is measured inclusive of the communication time at 38,4Kbaud. A modified baud rate will slightly increase the timing but the Inventory timing is mostly determine by the anticollision so you may neglect the communication time. Execution time Communication time FEIG ELECTRONIC GmbH Page 140 of 144 H40801-5e-ID-B.doc...
  • Page 78 The address is beyond the configured address space of the Transponder. 0x05 Wrong Transponder-type: This command is not applicable at the Transponder: x Attempt to write on or read from a Transponder. A special command is not applicable to the Transponder. FEIG ELECTRONIC GmbH Page 141 of 144 H40801-5e-ID-B.doc...
  • Page 79 1. Read the Device-ID using the command [0x66] Firmware version (Mode 0x80) 2. Send the Device-ID and the serial number of the reader to Feig Electronic 3. Write the upgrade code into the reader using the command [0x5F] Set Firmware Update...
  • Page 80 ID ISC.LR100 ID ISC.LR200 ID ISC.LRU1000 ID CPR.M02 ID CPR.02 ID CPR.M03 (586/#) ID CPR04-U ID ISC MR101-U / PR101-U ID ISC.MR101-A / PR101-A ID ISC.PRH101-A (RS232 or Bluetooth) ID ISC.PRH101-U (USB-Version) FEIG ELECTRONIC GmbH Page 143 of 144 H40801-5e-ID-B.doc...
  • Page 81 The setting "LSB first" and "MSB first" gives the direction of the received data bytes ISO15693 Host Command (DB-Size of the Transponder = 4 bytes) ISO15693 Host Command (DB-Size of the Transponder = 8 bytes) FEIG ELECTRONIC GmbH Page 144 of 144 H40801-5e-ID-B.doc...
