TP-Link TL-WPA7617 Quick Installation Manual

Quick Installation Guide
* TL-WPA7617 (European version) is used for demonstration in this guide.
* Images may differ from actual products.
e
r l i n
w e
P o
New Extender
TL-WPA7617
1
Plug in the new extender near one of your existing powerline devices.
2
Check the new extender's Powerline LED
Existing Powerline Device
(for demonstration only)
. Is it on?
> Step 4
> Step 3
3
Pair the powerline devices.
A
Press the Pair button on the existing powerline
device for 1 second. The Power LED starts
blinking.
Note: If the Power LED does not blink, press
the Pair button again.
Blinking
Existing Powerline Device
4
Relocate the extender to the Wi-Fi "dead" zone. Connect your devices to the
internet using the default SSIDs (network name) and password on the label at
the side of the extender.
SSID:TP-Link_XXXX
SSID:TP-Link_XXXX_5G
Wireless Password:XXXXXXXX
Tip:
If you cannot find the SSIDs in your Wi-Fi network list, your new extender
has automatically copied over the existing wireless settings. In this case,
use the SSID and password of your existing powerline network to connect.
If you want to unify your Wi-Fi networks, refer to the back page for
instructions.
Attention
1. Use the product only in the upright direction.
2. Plug powerline devices into wall outlets instead of power strips.
Note: Using power strip will affect network performance or even cause connection drops.
Wall Outlet Power Strip
B
Within 2 minutes, press the Pair button on the
new extender for 1 second. The Power LED
starts blinking.
When the Powerline LED on the new extender
turns on, the pairing process is complete.
Blinking
On
Within 2 minutes
Extender TL-WPA7617
