SIRCHIE PVS200EG Technical Information

All-purpose evidence recovery kit

TI06-527ENG-REV7

TECHNICAL INFORMATION

All-Purpose Evidence Recovery Kit

Catalog No. PVS200

INTRODUCTION

The PVS200 Kit opens a whole new realm of possibilities for the crime scene evidence technician. Using

liquid silicone materials is not new to the CSI—what's new is the delivery method.

Silicone materials used in evidence collection consist of a base material and a catalyst (hardener). The

PVS200 eliminates the guesswork in achieving the correct

mixture ratio. Simply load the gun and pull the trigger. Mixing

is done automatically in a unique mixing nozzle. The PVS200

extruder gun uses equal amounts of base material and catalyst

(polyvinyl siloxane). Pulling the trigger forces both substances

into the mixing nozzle and out the end of the spreader tip.

This incredible formula is the perfect method for lifting pow-

dered latent prints from textured, irregular or curved surfaces.

PVS200 contains 3 formula cartridges: brown, white and trans-

parent. The transparent formula enables direct viewing of the

100 HUNTER PLACE, YOUNGSVILLE, NC 27596 USA

Ph: (919) 554-2244, (800) 356-7311 • Fax: (919) 554-2266, (800) 899-8181 • Web: www.sirchie.com • Email: sirchieinfo@sirchie.com

1 of 4

Table of Contents

Do you have a question about the PVS200EG and is the answer not in the manual?

Page 1 PVS200 contains 3 formula cartridges: brown, white and trans- parent. The transparent formula enables direct viewing of the 100 HUNTER PLACE, YOUNGSVILLE, NC 27596 USA Ph: (919) 554-2244, (800) 356-7311 • Fax: (919) 554-2266, (800) 899-8181 • Web: www.sirchie.com • Email: sirchieinfo@sirchie.com 1 of 4...
Page 2 PVS200. detail shown below. propriate Material Safety Data Sheets (MSDS) found on our website at www.sirchie.com/support. PROCEDURE Loading The Extruder 1. Release the cartridge latch. 2. Insert the piston driver into the gun and hold up the release.
Page 3 TI06-527ENG-REV7 9. Affix mixing nozzle. 10. Twist clockwise to lock. 11. Place the tip close to the surface where the impression is to be made and begin pulling the trigger until the silicone mixture begins to flow. Continue applying the silicone until the area to be lifted is fully covered.
Page 4 This will provide you with a handle to assist in cast removal. The spatula is easily removed from the cast after curing is complete. PVS200 CONTENTS: CAT. NO. REPLACEMENT SUPPLIES 1- PVS200EG Extruder Gun PVS200W White Dual Cartridge, 75ml 12- PVS200N Nozzles with spreader tips 12- PVS200NT Nozzles w/out spreader tips...
