TI17-715ENG-REV2
Copyright© 2017 by SIRCHIE
All Rights Reserved.
TECHNICAL INFORMATION
Cyanowand
and Accessories
®
Catalog Nos. CW100, CW200, CW300, CW400, CW4001
Background
Cyanoacrylate (superglue) is a proven method for developing latent fingerprints on most non-porous sur-
faces. In traditional applications, liquid glue is sublimated into a gaseous form within a closed chamber
with evidence, and reacts with moisture present in regions
where latent fingerprints are present. This reaction causes the
cyanoacrylate to polymerize and form visible ridges and detail
on latent fingerprints.
In some situations, it is impossible to place an item in a closed
chamber for fuming. Examples of these situations are: outside
windows on buildings, remote outdoor locations, and large
objects like the interior/exterior of vehicles. The Cyanowand®
uses direct heat via a butane torch to quickly vaporize
cyanoacrylate in a convenient cartridge. The fumes that are
projected can be used to develop latent prints by simply pass-
ing the wand over the surface in a controlled manner.
100 HUNTER PLACE, YOUNGSVILLE, NC 27596 USA
Ph: (919) 554-2244, (800) 356-7311 • Fax: (919) 554-2266, (800) 899-8181 • Web: www.sirchie.com • Email: sirchieinfo@sirchie.com
1 of 4
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SIRCHIE Cyanowand CW100
Summary of Contents for SIRCHIE Cyanowand CW100
- Page 1 100 HUNTER PLACE, YOUNGSVILLE, NC 27596 USA Ph: (919) 554-2244, (800) 356-7311 • Fax: (919) 554-2266, (800) 899-8181 • Web: www.sirchie.com • Email: sirchieinfo@sirchie.com 1 of 4...
- Page 2 TI17-715ENG-REV2 The Cyanowand® can also be used with the Cyanoacrylate Laboratory Fuming Chamber (FR100) or the Cyanoacrylate Fuming Chambers (FR200 and FR600) as an alternate fuming source. Set-up Fueling the Cyanowand: Warning: Butane gas is highly flammable. Do not perform refueling operation near a heat source, electrical source, or open flame.
- Page 3 TI17-715ENG-REV2 Controls/Operation Cyanowand Cartridge (installed) Lock button Ignition switch Vent port Fuel port Flame adjustment Torch lock Figure 2: Cyanowand Operation: Attach Cyanowand® cartridge (CW200, CW300, CW400, CW4001) to end until finger tight (do not attempt to tighten further). Set Flame Adjustment (6) halfway between 1 and 4. Press the Lock Button (2) and slide the Ignition Switch (3) down away from the burner and hold down.
- Page 4 TI17-715ENG-REV2 12. For additional fuming, remove the cartridge by unscrewing and replace with a new cartridge. Repeat steps 2-11. CAUTION! When cartridge is exhausted it is VERY HOT. Remove cartridge with enclosed tweezers (Figure 3) or wait until it completely cools down before touching.
