- Page 1 VISION & CONTROL Instructions for Use Instructions for Use TZB28-B450-P-24V TZB28-B450-P-24V Telecentric Lights, Telecentric Lights, Luminous colour: Blue - 450 nm Luminous colour: Blue - 450 nm 999.995.404.10-en-1.4 © Vision & Control GmbH 2021...
- Page 2 Impress Publisher / Manufacturer Vision & Control GmbH Mittelbergstraße 16 98527 Suhl, Germany Telephone: +49 (0) 3681 7974-0 Telefax: +49 (0) 3681 7974-33 www.vision-control.com Name of the document 999.995.404.10-en-1.4 Date of first issue 2020-12-15 Date modified 2021-04-20 Copyright © Vision & Control GmbH 2021 Copyright It is forbidden to pass this document on to third parties, reproduce and communicate its contents in as far as this has not been expressly authorized.
- Page 3 Validity These instructions for use are valid for the following device: Device Order no. TZB28-B450-P-24V 1-33-240 Product Identification Designation Description Telecentric Lights Luminous field diameter in mm B450 Luminous colour: Blue - 450 nm Power LED 24 V DC operating voltage, with integrated lighting controller ©...
-
Page 4: Table Of Contents
TZB28-B450-P-24V Table of Contents TABLE OF CONTENTS 1 Information about the Instructions of Use..........5 1.1 Intended Use....................5 1.2 Improper Use....................6 1.3 Qualified Personnel..................6 1.4 Warranty and Liability...................7 2 Safety......................8 2.1 Presentation of Safety Instructions.............. 8 2.2 Safe Handling of the Device................ 9 3 Scope of Delivery and Accessories............ -
Page 5: Information About The Instructions Of Use
TZB28-B450-P-24V Information about the Instructions of Use 1 INFORMATION ABOUT THE INSTRUCTIONS OF This document contains technical information, important instructions for correct installation, commissioning and use, as well as product information which were up-to-date at the time of going to press. -
Page 6: Improper Use
TZB28-B450-P-24V Information about the Instructions of Use 1.2 Improper Use All unintended use and all device-related activities not described in these instructions of use is to be deemed as unauthorised misuse outside the legal limits of indemnity of the manufacturer. -
Page 7: Warranty And Liability
TZB28-B450-P-24V Information about the Instructions of Use 1.4 Warranty and Liability The contents of this document have been checked carefully and correspond to current legislation and best practise at the time of going to press. However, the manufacturer shall not be liable for any damage arising from the use of this edition of the manual, and rejects any warranty derived therefrom. -
Page 8: Safety
TZB28-B450-P-24V Safety 2 SAFETY 2.1 Presentation of Safety Instructions Each safety instruction is introduced by a key word and colour highlighted. The key word indicates the degree of danger. The danger and its cause are described, and then the measures to prevent conceivable consequences of the danger. -
Page 9: Safe Handling Of The Device
TZB28-B450-P-24V Safety 2.2 Safe Handling of the Device Read the following applicable safety instructions carefully and completely. Follow the instructions for your own safety, the safety of other people, and to avoid damage to the device and the connected technical equipment. Hazards going beyond the general safety instructions are referred to separately at the relevant points in this manual. -
Page 10: Scope Of Delivery And Accessories
Because of the many possible configurations, the cables are listed in the accessories rather than included in the scope of delivery. 3.1 Scope of Delivery Designation Quantity Device TZB28-B450-P-24V Covering cap TZB28-B450-P-24V Instructions for Use TZB28-B450-P-24V 3.2 Accessories Lens holder Designation Description Order no. Lens Holder d35.5... - Page 11 TZB28-B450-P-24V Scope of Delivery and Accessories DIN rail power supplies Designation Description Order no. HSN24/5.2 DIN rail power supply, 1-92-017 24 VDC-10% +20%, 5.2A +/-5%, without connection cable, for lighting Connection cable M8-4-pin, straight plug, 4A, 60V Designation Description Order no.
-
Page 12: Device Description
TZB28-B450-P-24V Device Description 4 DEVICE DESCRIPTION 4.1 Device Views Image 1: Geräteansicht Casing Light-emitting surface Identification plate Note screw-in depth Mounting surface with mounting holes Connector M8-4pin 999.995.404.10-en-1.4 © Vision & Control GmbH 2021... -
Page 13: Notices On The Device
TZB28-B450-P-24V Device Description 4.2 Notices on the device Following instructions are provided on the device: Type plate Type: TZB28-XXXX-P-24V SN.: XXXXXXXX Image 2: Type plate Device designation Serial number Notice Screw-in depth screw-in depth max. 7mm Image 3: Notice Screw-in depth ©... -
Page 14: Technical Data
TZB28-B450-P-24V Technical Data 5 TECHNICAL DATA 5.1 General Parameters Parameter Characteristic Housing material Aluminium, black anodised Optical material Glass Housing dimensions Length: 94.5 mm without connector Diameter max.: 35.5 mm Dimensions light-emitting Diameter: 29 mm surface Connector Male connector, M8, 4-pin... -
Page 15: Electrical Parameters
TZB28-B450-P-24V Technical Data 5.2 Electrical Parameters Parameter Operating voltage U 19 V 24 V 29 V Power consumption at U = 24 V DC 0.4 W 0.5 W 0.6 W Switch input Input voltage OFF 2.0 V ON/OFF Input current OFF 0 mA 0.2 mA... -
Page 16: Conditions For Operation, Storage And Transport
TZB28-B450-P-24V Technical Data Spectral Emission Wavelength [nm] Image 4: Spectral emission 5.4 Conditions for Operation, Storage and Transport Observe the specified ambient conditions when transporting and storing the device. For accessories, connected devices and components observe the specific information in the associated instructions for use. -
Page 17: Technical Drawings
TZB28-B450-P-24V Technical Data 5.5 Technical Drawings Image 5: Technical Drawings (dimensions in mm) © Vision & Control GmbH 2021 999.995.404.10-en-1.4... -
Page 18: Commissioning
TZB28-B450-P-24V Commissioning 6 COMMISSIONING NOTICE Installation and connection operations may only be performed in the off and de-energised state. 6.1 Unpacking 1. Lift the cardboard, together with the device, out of the carton. 2. Fold out the tucked in sides on the bottom of the cardboard. The film loosens and forms an insertion pocket. -
Page 19: Mounting The Accessories
TZB28-B450-P-24V Commissioning 6.3 Mounting the accessories Mount the Lens Holder 2.) 3.) 1. Loosen the M5 hexagon nuts (a) on the lens holder. 2. Slide the lens holder to the desired location on the lighting. 3. Tighten the M5 hexagon nuts alternately hand-tight in small steps. - Page 20 TZB28-B450-P-24V Commissioning Mount the Deflection Mirror 2.) 3.) 1. Loosen the M3 threaded pins (a) of the deflection mirror. 2. Attach the deflection mirror on the lighting. Rotate the mirror (b) to the desired position. 3. Tighten the M3 thread pins alternately hand-tight in small steps.
-
Page 21: Connecting
TZB28-B450-P-24V Commissioning 6.4 Connecting NOTICE Cable damage • Comply with the specified minimum bending radius. • Cables must generally be mounted with a strain relief clamp. • Use cables corresponding to the specification (see data sheet). 6.4.1 Pin assignment Use the M8 connector to connect the device according to the pin assignment. -
Page 22: Operation
TZB28-B450-P-24V Operation 7 OPERATION CAUTION Physiological effects by flashing lights • Working under flashing lights can cause effects such as headache, nausea, or epileptic seizures. • Avoid exposure to certain kinds of flashing lights or stroboscopes. • Wear protective goggles. -
Page 23: Operating Modes
TZB28-B450-P-24V Operation 7.2 Operating Modes The integrated controller supports the following operating modes: Continuous operation The lighting is switched on by setting the ON/OFF signal after the delay time t Resetting the ON/OFF signal turns off the lighting. Continuous operation, switchable The switchable continuous operation is carried out by continuously setting and resetting the switching signal ON/OFF. -
Page 24: Maintenance And Service
TZB28-B450-P-24V Maintenance and Service 8 MAINTENANCE AND SERVICE 8.1 Maintenance The device is maintenance-free. Depending on the operating environment, it may have to be cleaned. The housing can be cleaned according to the conditions applicable to the given protection class. -
Page 25: Service
TZB28-B450-P-24V Maintenance and Service 8.2 Service Technical Support Please contact our technical support if you have any technical questions concerning our products. We will be glad to be of service: Monday to Thursday 8:00 to 17:00, and Friday 8:00 to 15:00. -
Page 26: Disposal
TZB28-B450-P-24V Disposal 9 DISPOSAL The device and its accessories and packaging must be sent to environmentally compatible recycling. Do not throw electrical devices or tools into the household waste! According to European Directive 2012/19/EU on waste electrical and electronic equipment and its implementation in national law, unusable electric tools must be collected separately, and sent to environmentally compatible recycling. -
Page 27: Eu Declaration Of Conformity
D-98527 Suhl, Germany Representative: Dr. Jürgen Geffe, Managing director We, Vision & Control GmbH Suhl, declare that the product described below – Designation: TZB28-B450-P-24V – Order no.: 1-33-240 has been manufactured in accordance with the following standards and normative documents: •... - Page 28 Vision & Control GmbH Mittelbergstraße 16 98527 Suhl, Germany Telephone +49 (0) 3681 7974-0 Telefax: +49 (0) 3681 7974-33 Vision & Control GmbH...
