Summary of Contents for Velex VX326
- Page 1 VX326 Instruction Manual Quick Start Guide For Gauge Hole Receivers Not all features listed in this QSG are available on all models. THIS PACKAGE CONTAINS Trim Bezel Power/Speaker Harness Mounting Screws User's Manual www.velextech.com...
-
Page 2: Installation
Installation Source Unit Trim Bezel Panel Mounting Screws Mounting (Using Mounting Plate) 1.Choose a mounting location on the dash board or instrument panel that will allow room behind to run radio cables to the power source. Consider how you will use the AUX IN, LINE OUT and USB connectors and route the appropriate extension cables to an accessible area. -
Page 3: Wiring Diagram
WIRING DIAGRAM BLACK BLACK RADIO ANTENNA RED AUDIO IN R GREY WHITE AUDIO IN L BLACK YELLOW VIDEO OUT GREEN GREEN SUBWOOFER OUT BLACK AUX IN BROWN VIDEO IN ORIENTATION SECTION A-A SECTION B-B PIN NO. WIRE COLOR WIRE DEFINITION BLACK GROUND (B-) GREEN... -
Page 4: Control Locations - Receiver
Control Locations - Receiver VX 326 MUTE Next Preset Stations (Radio -FM) MENU / Return Source / Power Previous Preset Stations (Radio- FM) VOL Knob (Rotate)/ Confirm (Press) Play / Pause | Band (Radio) | Video I/O Switch (Press and Hold While Playing Video) Mute / Button Brightness Adjust (Day / Night) Tune Up / Next Track Tune Down / Previous Track... -
Page 5: General Operation
General Operation Power on/off Press the ' ' button to turn the unit on. Press and hold ' to turn unit off. Changing Modes Press 'SRC' button to switch between Radio, AUX IN, Bluetooth Music, Media (USB). MENU- Press MENU button and use the Volume Knob to select between MEDIA, RADIO, BLUETOOTH, AUX IN, SETTINGS. -
Page 6: Fm Tuner Operation
Auto Programming of Radio Station Press and hold 'AMS button for 1 second, VX326 will commence searching the band for radio stations and auto matically stored in the available preset memory location. The new stations will replace any stations previously stored in that band. -
Page 7: Mp3/Wma Operation
MP3/WMA Operation When an USB stick is plugged in, VX326 start to play the audios from the first location. If user want to play MOVIE/PHOTO on the USB stick, press MENU then enter MEDIA selection, MUSIC/MOVIE/PHOTO will be displayed on LCD screen, rotate the VOL Knob to make choice. - Page 8 MUSIC/MOVIE/PHOTO Operation When an USB stick is plugged in, VX326 will auto detect the audio files and start to play from the first location. When VX326 is playing audio, press and hold the VOL knob for 1 second, MUSIC /MOVIE/PHOTO selection will be toggled, rotate and press the VOL knob to confirm the selection.
-
Page 9: Bluetooth Operation
Activate the Bluetooth on your smartphone to search for new devices. Connect with the device name 'VX326' when founded. Once pairing is successful, ' icon on the top title will change from white to blue color which means 'device paired'. -
Page 10: Troubleshooting
Trouble Shooting ISSUE OPTIONS Cause: Yellow/red wire not connected or incorrect voltage Action: Check connections for proper voltage (11-16V DC) Unit will not turn Cause: Black wire not connected on (no power) Action: Check connection to ground Cause: Fuse blown Action: Replace the fuse Cause: Speaker wire not connected Action: Check connections at speakers... -
Page 11: Specifications
Specifications General Power supply requirements: DC 12V Negative Ground Load impedance: 4-8 Ohms/channel Maximum output power: 40W x 4 (CH) Operate temperature: -10-50℃ MUTLIMEDIA SUPPORT AUDIO FORMAT: MP3/WMA/OGG/FLAC/APE/AAC/AC3 VIDEO FORMAT: MPEG 1/ MPEG 2/ MPEG 4-XVID/DIVX/H.264/H.263/WMV9/RMVB PHOTO: JPEG/BMP FM Tuner: Tuning range: 87.9MHz-107.9MHz (USA) 87.5MHz-108MHZ (EUR) AM Tuner: Tuning range:...
