- Page 1 HZ031300TX ALYSSA WINE STORAGE For assistance with assembly, contact. Southern Enterprises Inc. Customer Service 1-800-633-5096 Assembly Instructions service@seidal.com www.seidal.com PO:13876 Top supports up to 25 lb. Drawer supports up to 10 lb.
-
Page 2: Parts List
HZ031300TX ALYSSA WINE STORAGE Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Carefully study the diagrams below. You may receive extra hardware with your unit. Drawer Front Drawer Right Panel... - Page 3 12PCS 14PCS 4PCS 10PCS Screws 4x12mm Wood Dowel 8x30mm Screws 4x32mm Bolts 4x25mm 10PCS 10PCS 8PCS Cam Locks Cam Bolts Screws 4x12mm Screws 4x38mm 5PCS 4PCS 4PCS Bolts 4x9mm End Caps L Metal Chip 2PCS 2PCS 2PCS Plastic Wall Anchor Screws 4x25mm Plastic Straps Care and Cleaning Instructions:...
- Page 4 HZ031300TX ALYSSA WINE STORAGE Assembly Instructions Step 1: Attach Drawer Right Panel (2) and Drawer Left Panel (3) to Drawer Front (1) using Wood Dowels (B) and Cam Bolts (F) as shown. Fix Drawer Right Panel (2) and Drawer Left Panel (3) to Drawer Front (1) with Cam Locks (E) as shown.
- Page 5 Step 4: Attach Wood Dowels (B) and Cam Bolts (F) to Right Wood Panel (7) and Left Wood Panel (8) as shown. Step 5: Please pull out Left Metal Glide (13) and Right Metal Glide (14). Aim at the hole with arrow tip label on Metal Glides (13), (14) and the pre-drilled holes on Right Wood Panel (7)
- Page 6 Step 7: Fix Top Panel (11) to Right Wood Panel (7) using Cam Locks (E). Using Wood Dowels (B), attach Stretcher (10) to Right Wood Panel (7) as shown. Step 8: Attach Shelf Panel (12) to Right Wood Panel (7). The groove of Shelf Panel (12) is facing along Back Panel (9) as shown.
- Page 7 Step 10: Aim at the pre-drilled holes on Right Wood Panel (7) and Left Wood Panel (8) attach Rear Wine Bottle Panel (15) using Screws (A) as shown. Step 11: Then, using Screws (A) again, aim at the pre-drilled holes on Right Wood Panel (7) and Left Wood Panel (8) to attach...
- Page 8 Step 13: Pull out Left Metal Glide (13) and Right Metal Glide (14) first. Then, put the assembled drawer to the frame of drawer and aim at the pre-drilled holes on Drawer Right Panel (2) and Drawer Left Panel (3) to attach Left Metal Glide (13) and Right Metal Glide (14) to assembled drawer using Screws (G) as shown.
- Page 9 Insert Wall Anchors (M) into the two 3/16″ holes. Make sure that the wall anchors are flush with the wall. Tip: It may be necessary to use a hammer to gently tap the anchors into place. Attach L Metal Chips (L) to Wall Anchors (M) u sing Phillips Head Screws (N) and the Phillips Screwdriver as shown.
- Page 10 90 days of your receipt, we are under no obligation to provide parts or replacement merchandise. Please contact Southern Enterprises at 800-633-5096 or in Dallas 972-869-0111/ 9am – 4pm Mon-Fri Central time if you have product issues or email us at service@seidal.com. Please ask for customer service representative for issues involving damages or replacement parts.
