OPT-J0475, OPT-J0476
10kg Ink supply unit
10kg イ ン ク供給ユ ニ ッ ト
Conversion to 2L Ink Unit
2L
イ ン ク ユ ニ ッ ト 変換セ ッ ト
10kg Ink automatic stirring unit
10kg
イ ン ク自動攪拌ユ ニ ッ ト
English
Japanese
MIMAKI ENGINEERING CO., LTD.
OPT-J0494
OPT-J0501
Foreword ........................................................................2
Safety Precautions ........................................................3
Warning labels ...............................................................5
Name of Each Part .........................................................6
Setting of 10kg Ink Tank ...............................................7
Set 10kg ink automatic stirring unit .............................9
Set 2L ink pack .............................................................15
Replace 2L ink pack ....................................................17
Use the same color ink in one tank ............................19
About ink level correction ...........................................21
Maintenance .................................................................22
If abnormality occurs ..................................................26
はじめに ........................................................................28
安全にお使いいただくために ........................................29
警告ラベルについて ......................................................31
各部の名称 .....................................................................32
10kg インクタンクをセットする ..................................33
10kg インク自動撹拌ユニットをセットする ................35
10kg インクタンクを交換する ( 供給パイプ装着時 ) ....36
10kg インクタンクを交換する ( 自動撹拌ユニット装着時 ) ...39
2L インクパックをセットする ......................................42
2L インクパックを交換する ..........................................44
同色インクを 1 つのタンクで使用する .........................46
インク残量補正について ...............................................48
メンテナンス .................................................................49
異常が発生したら ..........................................................53
https://mimaki.com/
https://japan.mimaki.com/
D203324-13
Advertisement
Table of Contents
Related Manuals for MIMAKI OPT-J0501
Summary of Contents for MIMAKI OPT-J0501
-
Page 1: Table Of Contents
10kg インクタンクをセットする ........33 10kg インク自動撹拌ユニットをセットする ....35 10kg インクタンクを交換する ( 供給パイプ装着時 ) ..36 10kg インクタンクを交換する ( 自動撹拌ユニット装着時 ) ...39 2L インクパックをセットする ........42 2L インクパックを交換する ..........44 同色インクを 1 つのタンクで使用する ......46 インク残量補正について ..........48 メンテナンス ..............49 異常が発生したら ............53 MIMAKI ENGINEERING CO., LTD. https://mimaki.com/ https://japan.mimaki.com/ D203324-13... -
Page 2: Foreword
CAUTION THIS LIMITED WARRANTY OF MIMAKI SHALL BE THE SOLE AND EXCLUSIVE WARRANTY AND IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTY OF MER-... -
Page 3: Safety Precautions
Safety Precautions Symbols In this document, symbols are used for explaining the contents of cautions on operation. The symbol to be displayed differs depending on the caution content. Understand the meaning of each symbol and use this machine safely and correctly. Examples of Symbols Meaning Failure to observe the instructions given with this symbol can result in death or seri-... - Page 4 Warning for Use Warning How to handle ink • When operating it in poorly ventilated area or closed room, make sure to install ventilation system. • If you swallow ink or maintenance cleaning solution mistakenly, rest and see a doctor to consult immediately. Never swal- low the vomit.
-
Page 5: Warning Labels
Warning labels Warning labels are stuck on the machine. Be sure to fully understand the warning given on the labels. If a warning label is illegible due to stains or has come off, purchase a new one from a distributor or our sales office. Order No. -
Page 6: Name Of Each Part
Name of Each Part • Be sure to lock the casters of the 10kg ink supply unit before turning on the power. • Your waist may get hurt by the weight of the ink tank, be careful enough when setting the tank. •... -
Page 7: Setting Of 10Kg Ink Tank
Setting of 10kg Ink Tank • Be sure to wear the included safety glasses and gloves. Ink and cleaning solution for maintenance may enter the eyes. Attach the ink IC chip. • Insert the ink IC chip with the surface having metal pieces facing up. Inserting the wrong side by accident can cause faults or damage of the ink IC chip. - Page 8 Stir the ink with a supply pipe. • Ink may be scattered. Always wear the included safety glasses. Supply pipe Set the supply pipe in the ink tank. Supply pipe Ink tank arrangement of each ink set, and ink IC chip arrangement 4-color 6-color 7-color...
-
Page 9: Set 10Kg Ink Automatic Stirring Unit
Set 10kg ink automatic stirring unit • Be sure to wear the included safety glasses and gloves. Ink and cleaning solution for maintenance may enter your eyes. Refer to Steps 1 to 3 of P.7 "Setting of 10kg Ink Tank" to set a new ink tank. Attach the automatic stirring unit to the 10kg ink Handle tank. -
Page 10: Replace 10Kg Ink Tank (When The Supply Pipe Is Attached)
Replace 10kg ink tank (when the supply pipe is attached) Do as follows when [INK END] or [INK NEAR END] is displayed on the sub-display. • Be sure to wear the included safety glasses and gloves as there is a danger of ink splashing. •... - Page 11 Remove the used Ink IC chip. • Replace the ink IC chip after setting a new 10kg ink tank. • Remove and attach ink IC chips in local mode. Ink IC chip. Attach the ink IC chip. • After the ink IC is inserted, the supply between the ink supply unit and the ink supply attachment is automatically performed.
-
Page 12: Replace 10Kg Ink Tank (When The Automatic Stirring Unit Is Attached)
Replace 10kg ink tank (when the automatic stirring unit is attached) Do as follows when [INK END] or [INK NEAR END] is displayed on the sub-display. • Be sure to wear the included safety glasses and gloves as there is a danger of ink splashing. •... - Page 13 Remove the used ink tank. Refer to Step 2 of P.9 "Set 10kg ink automatic stirring unit" to set a new ink tank. 10kg ink tank Remove the used ink IC chip. • Replace the ink IC chip after setting a new 10kg ink tank. •...
- Page 14 When [INK NEAR END] is displayed Very little ink remains in the bottle. Although the print operation can continue without replacing the ink bottle, the ink may run out during the printing operation. We recommend that you replace the ink tank with a new one soon after this is indicated.
-
Page 15: Set 2L Ink Pack
Set 2L ink pack By attaching 2L ink unit conversion set, 2L ink pack of spot color ink can be used. Set it in the ink supply unit by the following procedure. • 2L ink unit conversion set is optional item. Purchase at our sales office because it is necessary to install by our service techni- cian. - Page 16 Put 2L ink pack in 2L eco_case. (1) Open the 2L eco-case. • Push the knob and spread the case to the left and right. (2) Remove the seal from the 2L ink pack connector. • The remained seal may cause a large amount of ink leak out when removing the 2L ink pack from the base.
-
Page 17: Replace 2L Ink Pack
Replace 2L ink pack Do as follows when [INK END] or [INK NEAR END] is displayed on the sub-display. • Be sure to wear the included safety glasses and gloves as there is a danger of ink splashing. • When exchanging the ink tank, perform it after curing the surroundings with a waste etc. The surroundings become dirty with ink dripping from the supply pipe. - Page 18 Remove the used Ink IC chip. • Replace the ink IC chip after setting a new 2L ink pack. • Remove and attach ink IC chips in local mode. • Store the ink IC chip that removed together with the used 2L ink pack.
-
Page 19: Use The Same Color Ink In One Tank
Use the same color ink in one tank The 10 kg supply unit can change the 10 kg ink tank to use one tank per color. • Changing the number of 10 kg ink tanks requires setup by a service person. Please contact your dealer or our sales office or call center. - Page 20 7 color ink set Front About ink bottle lamp When using a 10 kg ink tank for each color, the ink bottle lamp displays the status of only the odd numbered path. • The even numbered route displays the status only when a problem occurs.
-
Page 21: About Ink Level Correction
About ink level correction If the difference between the ink level of IC and the actual ink level in the 10kg ink tank is large, correct it with [Ink Remaining Corr.]. Perform the ink level correction Select [MENU] > [MAINTENANCE] > [Ink Remaining Corr.], and press the [ENTER] key. -
Page 22: Maintenance
Maintenance Maintenance of 10kg Ink Tank: When the supply pipe is used Stir the ink in the tank every day to prevent the ink components from settling. A message prompting to stir the ink tank will be displayed every 24 hours. In 10kg ink tank Stir the ink. - Page 23 Set the supply pipe in the ink tank. Supply pipe Press the [FUNC2] key to cancel the message display. Maintenance of 10kg Ink Tank: When the automatic stirring unit is used The ink in the tank is automatically stirred every day to prevent the ink components from settling. If the ink in the ink tank has not been stirred for a long time, a message prompting you to perform the stir for recovery will be dis- played.
- Page 24 ● When stirring ink manually Remove the automatic stirring unit from the ink tank, and stir ink in the ink tank. Handle (1) Refer to P.12 "Remove the automatic stirring unit from the ink tank." to remove the automatic stirring unit. (2) Grip the handle of the automatic stirring unit removed from the ink tank, and stir the ink in the ink tank about five times.
- Page 25 • Be sure to wear the included safety glasses and gloves as there is a danger of ink splashing. • Do not shake the ink pack strongly. If you shake it largely or strongly, the ink may leak from the ink pack. •...
-
Page 26: If Abnormality Occurs
If abnormality occurs If an abnormality occurs in the 10kg ink tank or 2L ink pack, a warning message will be displayed. All operations related to ink discharge such as printing and cleaning can not be performed. When an error occurs, please do as follows. •... - Page 27 Even when ink is consumed, the Tank remaining amount H amount of ink in the sub tank is not • Restart the machine. reduced. • If displaying again, contact your local distributor, our sales office, ・Failure occurs in ink suction. or service center.
