SMALL ROLL W / CENTR.+ PLAITED HU1800
Operation Manual
Introduction .....................................................................................................................2
Caution ............................................................................................................................2
Safety precautions .........................................................................................................3
Installation of this option ...............................................................................................5
Part name and function..................................................................................................6
About media ................................................................................................................. 12
Set a media ................................................................................................................... 13
Print out ........................................................................................................................ 21
User maintenance ........................................................................................................ 25
Troubleshooting .......................................................................................................... 25
Specifications .............................................................................................................. 26
DISCLAIMER OF WARRANTY ............................................................................................................ 2
On this operation manual ..................................................................................................................... 2
Attention .............................................................................................................................................. 2
Symbols ............................................................................................................................................... 3
Installation location .............................................................................................................................. 5
Overall ................................................................................................................................................. 6
SMALL ROLL W / CENTR. .................................................................................................................. 7
PLAITED HU1800 ................................................................................................................................ 8
Operation panel ................................................................................................................................... 9
Available media size .......................................................................................................................... 12
Plaited media ..................................................................................................................................... 13
Roll media ......................................................................................................................................... 18
For the plaited media ......................................................................................................................... 21
For roll media ..................................................................................................................................... 23
The tension bar rises up / falls even when the folding bar is adjusted ................................................ 25
SMALL ROLL W / CENTR. ................................................................................................................ 26
PLAITED HU1800 .............................................................................................................................. 26
MIMAKI ENGINEERING CO., LTD.
Option - J0487
D203440-10
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for MIMAKI J0487
Summary of Contents for MIMAKI J0487
-
Page 1: Table Of Contents
Option – J0487 SMALL ROLL W / CENTR.+ PLAITED HU1800 Operation Manual Introduction ........................2 Caution ..........................2 DISCLAIMER OF WARRANTY ......................2 On this operation manual ........................2 Attention .............................. 2 Safety precautions ......................3 Symbols ............................... 3 Installation of this option ....................5 Installation location .......................... -
Page 2: Introduction
Caution DISCLAIMER OF WARRANTY THIS LIMITED WARRANTY OF MIMAKI SHALL BE THE SOLE AND EXCLUSIVE WARRANTY AND IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS, AND MIMAKI NEITHER ASSUMES NOR... -
Page 3: Safety Precautions
Safety precautions Symbols In this document, symbols are used for explaining the contents of cautions on operation. The symbol to be displayed differs depending on the caution content. Understand the meaning of each symbol and use this unit safely and correctly. Example of symbol Description Failure to observe the instructions given with this symbol... - Page 4 Warning on use Warning The set of power cables provided with this option is for use with this option only, and cannot be used with other electrical devices. Do not use any power cables other than the ones provided with this option.
-
Page 5: Installation Of This Option
Installation of this option Installation location This option is a Tiger-specific option kit for the ML Tiger-1800B series (hereinafter referred to as the printer main unit) that enables use of folded fabric media. The space required when this option is mounted on the printer main unit is shown below. Determine the installation location in consideration of the size when this option is mounted on the printer main unit and the space required for printing. -
Page 6: Part Name And Function
Part name and function Overall DRYERJET for FABRIC Printer main unit SMALL ROLL W / CENTR. Feed the roll media PLAITED HU1800 Feed the folding media The equipment included in this option is as follows. SMALL ROLL W / CENTR. ···· 1 unit ... -
Page 7: Small Roll W / Centr
SMALL ROLL W / CENTR. 8. Media end 3. Emergency detection sensor 1. Seam detection sensor stop button 2. Setting panel of the seam detection sensor 3. Emergency stop button 7. Beam sensor 4. Operation panel 6. 2 inch paper core set shaft 5. -
Page 8: Plaited Hu1800
PLAITED HU1800 1. Pinch bar 3. Folding bar 4. Tension adjustment handle 5. Centering unit 2. Centering unit adjustment handle Name Function Opens and closes in synchronization with the tension Pinch bar bar. Tension the media. Centering unit adjustment Handle to adjust the position of the centering unit. handle Folding bar Folding bar for applying tension to media. -
Page 9: Operation Panel
Operation panel Startup screen Main menu The screen changes to each of the following screens. Item with a green button are currently active. Name Function UNWINDER Operation screen of SMALL ROLL W / CENTR. SEAM Settings related to the seam detection sensor. It is a setting related to another option, BIG ROLL UNWINDER HU1800 INVERTER (Option-J0485). - Page 10 UNWINDER screen Page 1 Roll / Plaited switch button Error history display (When an error occurs) Error reset To page 2 Face out winding / Automatic / Manual rotation button Face in winding Valid only in manual mode Manual switch button switch button Page 2 To page 1...
- Page 11 SEAM screen Seam detection enable / disable button ON: Function enabled OFF: Function disabled Distance from the start of printing to detect the seam (display only) Distance from the start of printing to the alarm after seam detection (display only) After seam detection feed amount setting (*) When a seam is detected, the specified amount is fed and printing stops in the pause state.
-
Page 12: About Media
About media This section describes the available media size and how to handle them. Available media size Maximum media width 1,890 mm Minimum media width 500 mm Media thickness 5 mm or less Media outside diameter 400 mm or less For SMALL ROLL W / Media weight 100 kg or less... -
Page 13: Set A Media
Set a media This section mainly describes changes to the media setting method that are caused by using this option. For the basic media setting method in the printer main unit, refer to the operation manual of the printer main unit. Plaited media Set the plaited media in this option. - Page 14 Set of media Use a stepladder, etc. for work at height, and be careful not to fall. Pass the media through the folding bar. Pass the media through the folding bar as shown. The direction of the folding bar can be changed by rotating the tension adjustment handle. ...
- Page 15 Remove the sensor cover. Pull the sensor cover of the centering unit straight inward and remove it. When not using the centering unit, be sure to return the sensor cover to its original position (the lamp changes from red to green). Temporarily adjust the width of the centering unit.
- Page 16 Pass the media through the centering unit. Pass the media between the black roller and the amber roller of the centering unit. The sensor may react when the media is passed, and the roller may move. If the sensor ...
- Page 17 Pass the media through SMALL ROLL W / CENTR. Insert the media into SMALL ROLL W / CENTR. as shown. Tension bar...
-
Page 18: Roll Media
Roll media Set the roll media wound on the paper core in SMALL ROLL W / CENTR. Preparation Note that the part is different from that of plaited media. Because roll media is heavy, use a lift or work with two or more people. ... - Page 19 Remove the air shaft. Open the disc-shaped support and remove the shaft. Set the shaft on the media, and attach the shaft to the SMALL ROLL W / CENTR. Close the disc-shaped support. Secure media. Inject air into the shaft with the supplied air gun to fix the media and shaft. ...
- Page 20 Pass the media (when using the centering unit). The way to pass the media to the pinch bar and centering unit is the same as for the folding media. Face in cannot be set. Tension bar...
-
Page 21: Print Out
Print out For the plaited media How to adjust the folding bar Unlike roll media, back tension can not be applied to the folding media due to the roll rotation. Adjust the tension by changing the angle of the folding bar. Adjustment of tension is performed while flowing media by automatic operation. - Page 22 Close the pinch bar. Press the “Automatic / Manual” switch button on the first page of the operation panel UNWINDER screen to set automatic operation. The pinch bar closes when automatic operation is performed. If you are using SP V1.41 or earlier, the pinch bar will not close and a “DANCING ...
-
Page 23: For Roll Media
For roll media Face out / face in switch button Set using the “Face out winding / Face in winding” switch button on the first page of the operation panel UNWINDER screen. UNWINDING FROM UP ···················· Face out UNWINDING FROM DOWN ··············· Face in ... - Page 24 Start automatic operation Press the “Automatic / Manual” switch button on the first page of the operation panel UNWINDER screen to set automatic operation. Operate the printer main unit to start printing. ...
-
Page 25: User Maintenance
User maintenance User maintenance should be taken according to the frequency of use or on a regular basis so that you can keep using this option for a long time. If the exterior of this option becomes dirty, wipe it off with a soft cloth which contains water or a diluted ... -
Page 26: Specifications
Specifications SMALL ROLL W / CENTR. Item Specifications Overall length 1,750 mm Overall width 2,665 mm Overall height 1,315 mm Weight 575 kg Operating environment Compliant with the printer main unit Power and air sources Supply from the printer main unit PLAITED HU1800 Item Specifications... - Page 27 memo...
- Page 28 D203440-10-07022020 All Rights Reserved. © MIMAKI ENGINEERING CO., LTD.
