Summary of Contents for Aalberg Audio EKKO EK-1
- Page 1 User Manual: EKKO DELAY PEDAL EK-1 EKKO EK-1 User Manual - v2.0.6 - June 2016...
- Page 2 CONGRATULATIONS! You are now the owner of the EKKO EK-1 Delay Pedal! EKKO EK-1 is a high-quality, custom aluminum housing pedal with true bypass. It can be controlled like a stand-alone effects pedal or by using the AERO AE-1 Wireless Controller to unleash the pedal’s full potential (optional).
-
Page 3: Table Of Contents
COMPLIANCE & FCC and IC Statements ..11 About AALBERG AUDIO ..... . . 12 HISTORY . -
Page 4: Getting Started
FX SELECT/TAP FX-SELECT – Choose active effect parameter (TIME, LEVEL or TEMPO FEEDBACK) for wireless control with AERO controller (optional) ON/OFF Set the pedal to ON (activated) or OFF (true bypass). EKKO EK-1 User Manual - v2.0.6 - June 2016... -
Page 5: Overview
Stereo out Mono in Mono out Adjust parameter levels Mode 1: Tap speed ON/OFF Mode 2: FX-select (Bypass) (Hold 2 sec to toggle) Set active parameter for AERO AE-1 Wireless Controller EKKO EK-1 User Manual - v2.0.6 - June 2016... -
Page 6: Technical Specifications
93 x 57 x 142 mm / 3.7 x 2.2 x 5.6 inches (W x H x D) Weight (excl. 0.372 kg / 13.0 oz packaging) Weight (incl. packaging) 0.442 kg / 15.6 oz EKKO EK-1 User Manual - v2.0.6 - June 2016... -
Page 7: Software Update
AERO: Press and hold the preset ‘3’ button and knob button while simultaneously turning the unit on (slide switch set to ‘1’). Tablet/Iphone: After your device has connected with the AERO choose “update”. EKKO EK-1 User Manual - v2.0.6 - June 2016... -
Page 8: Wireless Control - Pairing
5. Effects pedals: repeat step 4) for the rest of the pedals from left to right 6. AERO: Press and hold the AERO knob button for 2 seconds then release it.To confirm syncing turn the AERO off and on. Voilà: Pairing complete! *Eight pedals maximum EKKO EK-1 User Manual - v2.0.6 - June 2016... -
Page 9: Input/Output Setups
INPUT/OUTPUT SETUPS The EKKO EK-1 Delay Pedal offers the following mono/stereo configurations: 1. Mono in/Mono out 2. Ping-pong stereo 3. Dry/wet split 4. Dual mono 1. Mono in/Mono out Connect your instrument to Mono in and the amplifier to Mono out. -
Page 10: Register
If the product is altered or repaired by someone unauthorized by Aalberg Audio the warranty is no longer valid. Stores and distributors must always check products before sending them to Aalberg Audio for repairs. -
Page 11: Compliance & Fcc And Ic Statements
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 15.21: Unauthorized changes or modifications not expressly approved by Aalberg Audio could void the user’s authority to operate the equipment. 15.105(b):... -
Page 12: About Aalberg Audio
EKKO EK-1 Delay Pedal with the AERO AE-1 Wireless Controller. (Below you can see the different development stages (from left to right): “The Coffee Filter”, 2010 –... - Page 13 ™ and © 2016 Aalberg Audio AS. All rights reserved. The information in this manual is subject to changes without further notice. Always visit aalbergaudio.com/support for updated user manuals. EKKO EK-1 User Manual - v2.0.6 - June 2016...
