- Page 2 Please follow the directions in the attached service guide to check the connections on your ride on. Most times it is a loose plug or switch that causes electric ride’s to stop working. Keep in mind the ride will not operate if the power adaptor/charger cable is plugged into the ride, this is a safety feature to ensure a child does not take off while it’s plugged in and damage it.
- Page 3 1. Pls make sure the power switch is plugged firmly as above picture shown. 2. Pls make sure the forward‐reverse switch is plugged firmly as above picture shown. 1 of 3...
- Page 4 3. Pls make sure the pedal switch is plugged firmly. 4. Open the seat, then the internal wire will be as the picture shown. 5. Connect the red wire of battery to the positive teminal. 6. The fuse connection 2 of 3...
- Page 5 7. Check the wiring of motor box 3 of 3...
