Summary of Contents for Hunter Products TR1002
- Page 2 Please follow the directions in the attached service guide to check the connections on your ride on. Most times it is a loose plug or switch that causes electric ride’s to stop working. Keep in mind the ride will not operate if the power adaptor/charger cable is plugged into the ride, this is a safety feature to ensure a child does not take off while it’s plugged in and damage it.
- Page 3 1. Pls make sure the forward‐stop‐reverse switch is plugged as above picture shown. 2. Open the pedal switch to check if the wiring is connected as pic shown. 1 of 2 1 of 2...
- Page 4 3. The cable diagram inside vehicle 4. Lift the seat, then connect the red wire to the battery 5. The fuse connection 7. How to use the charger connect the vehicle. 6. Disassemble the rear wheels to get the motor box, then check the connection of motor box if it is plugged firmly as above picture shown. 2 of 2 2 of 2...
