Canon NP-1500 Toner Cartridge
DOC-0173
O
VERVIEW
These instructions cover the recharging of the Canon NP-1500 (Type D), toner cartridges used in the Canon NP-1500 copier.
Although this cartridge looks similar to the PC-850 cartridge, they are not interchangeable. The NP-1500 cartridge has a handle
built into it's shell, and uses a corona wire inside to charge the drum. The PC-850 cartridge has no handle, and uses a PCR.
This cartridge is rated for 8,500 pages at 5% coverage.
This machine has a fairly heavy duty cycle of 10,000 pages/ month, and a copy speed of 12 cpm.
The actual Canon part number for the NP-1500 (Type D) cartridge, is F41-7601-000.
The purpose of this disassembly procedure is to vacuum out toner that will have spilled inside the cartridge during shipping and/
or rough handling, to clean the debris cavity, and to clean and fill the supply chamber with new toner. This disassembly
procedure should also be used to examine the internal parts of the cartridge for possible damage, or wear should the printing of
the cartridge be poor and not correctable by any other means.
NOTE: These Instructions should be read completely before proceeding with the recharge.
R T
EQUIRED OOLS
1. Phillips head screw driver
2. Small Common Screwdriver
3. Toner approved vacuum
4. Needle Nose Pliers
5. Safety goggles and breathing mask
S R
UPPLIES EQUIRED
1. Black Toner 500 Grams
2. Recovery Blade [optional]
3. Cotton Swabs (CT-100)
4. Lint Free Cotton Pads (PW-96)
5. Toner Magnet (TM-1)
