Page 3
All rights are reserved. No part of this document may be photocopied or reproduced without the prior written consent of StoneFly. The information contained in this document is subject to change without notice. StoneFly shall not be liable for errors contained herein or for consequential damages in connection with the furnishing, performance, or use of this material.
Introduction This document is aimed for system administrators who would like to know how to get started with StoneFly Unified Scale Out – High Availability (USO-HA) Appliance. It describes initial steps for launching the appliance. The StoneFly USO-HA appliance provides a powerful Storage solution that can Scale Out Storage capacity while scaling up performance.
Page 7
StoneFly USO-HA Setup Guide Introduction The StoneFly USO-HA can be configured with the following StoneFly HA RAID Storage Expansion Arrays: 12-bay / 2U 12Gb SAS HA RAID Storage Expansion Array (12 x 3.5” SAS drives) 16-bay / 3U 12Gb SAS HA RAID Storage Expansion Array (16 x 3.5” SAS drives) ...
Risk of system damage or a loss of data 1.1.2 System diagram and description The figure below is a network interconnection diagram for the StoneFly USO-HA appliance. It consists of two StoneFly Converged Storage Concentrator (SC) cluster nodes. The diagram also includes shared a StoneFly HA RAID Storage Expansion Array with dual active-active hardware RAID controllers with failover and failback.
Initial Installation 2.1 Mounting the Equipment The USO-HA appliance is comprised of at least two StoneFly Converged SCs and one HA RAID Storage Expansion Array. Depending on which model you purchased, the interconnects between the SCs and the HA RAID Storage Expansion Array will be either SAS or FC. The SAS cables connecting the SCs with the HA RAID Storage Expansion Arrays and optional HA Expansion Units are short.
Page 12
Initial Installation Identifying the Sections of the Rack Rails The StoneFly appliance chassis package includes two rack rail assemblies in the rack mounting kit. Each assembly consists of three sections: an inner rail that secures directly to the chassis, an outer rail that secures to the rack, and a middle rail which extends from the outer rail.
Modules came installed within the enclosure need not be removed. Follow the instructions provided in the StoneFly Getting Started Guide. When the system is in operation Module and drive bays must not be empty! They must have a dummy cover / plate in place...
Page 24
Chapter-3: Cabling Connections & Power Up...
AFTER all of the data/network connections have been made. Spanning Tree Protocol (STP) must be disabled on your network switch when using bonded data ports on the StoneFly USO-HA appliance. Note: Follow the labels for each port as marked on your appliance(s).
Page 26
Cabling Connections & Power Up SAS Interconnects - Multipath Connections (Optional Upgrade) If you have purchased the optional StoneFly Multipathing Kit, then you will be able to connect each SC to both RAID controllers on the HA RAID Storage Expansion Array.
4.2 Configuring IPMI KVM The Intelligent Platform Management Interface (IPMI) KVM configuration allows for Remote Management and Power Control of the StoneFly USO-HA system. This configuration is optional to perform, but recommended. To configure the IPMI module, connect a keyboard and monitor to the system. Power on the system and press the Del key to enter the BIOS setup.
Page 49
GUI becomes available once the CLI is closed. At this point, it should be possible to login to the web GUI for the StoneFly USO appliance by browsing to the management IP address that you just configured in the last step. Once logged in, you should configure the SAN data network settings.
