Summary of Contents for Water Tech Pool Blaster CX-1

  • Page 2: Table Of Contents

    Contents OPERATOR’S MANUAL Dear Valued Water Tech Customer, Thank you for choosing Water Tech’s innovative new swimming pool cleaner, the CX-1. The CX-1 has been designed to be completely “user friendly” beginning with its “Hands-Free” launch into your pool. Simply place the cleaner at poolside, press one button and the CX-1 will climb into the pool by itself and get to work.

  • Page 3: Warnings & Cautions

    1. This product contains Li-Ion batteries. Do NOT abuse this product. If you suspect any damage to the batteries, do NOT attempt to charge the robot, contact Water Tech Customer Service. 2. Do NOT store the CX-1 near heat or an open flame.

  • Page 4: Package Contents

    Package Contents Pool Blaster CX-1 Charger Hook * The hook attaches to your standard size pool pole to help you retrieve the unit from your pool.

  • Page 5: Specifications

    Specifications CX-1 Specifications Cleaning Coverage (sq. ft./hr.)....3542 sq. ft./hr. Minimal Operation Depth........16 in. Maximum Operation Depth........15 ft. Run Time..........Up to 4 Hours. Charging Time..........6-8 Hours. Cleaning Width............18.0”. Suction Power........Up to 7200 gal. /hr. Unit Size..........19.85 x 18.0 x 11.0”. Unit Weight............21 lbs. Shipping Weight...........27 lbs.

  • Page 6: Knowing Your Unit

    Knowing Your Unit Full Unit - Rear Full Unit Full Unit - Bottom Bottom - Cover Closed Bottom - Filter Bag - Cover Filter Bag with Cover...

  • Page 7: Knowing The Control Panel / Smart Features

    Knowing The Control Panel On the next page, you will find more detail on how each mode and cycle works. *Note: When your CX-1 is in sleep mode, only the Battery LEDs (and ON/OFF LED for “Weekly” Mode) will stay ON. Smart Features No matter which modes are chosen, these smart features are included into the software: •...

  • Page 8: Select Cleaning Cycle

    a. Select Cleaning Cycle You can program the CX-1 to run continuously or in intervals over a week long period. 1-Day Cleaning Cycle • 1-Day: The CX-1 will run continuously for up to 2 hours and then go into sleep mode. If 2 hours is not enough, you can wake the robot from the sleep mode to start another 2-hour cycle.

  • Page 9: Weekly Mode Running Schedule / Select Cleaning Mode

    Weekly Cycle Running Schedule Weekly cycle runs your robot every day for a full week. Starting from when you first turn it on, the robot will clean approximately 60 minutes. Then at the same time every day for the remainder of the week, the robot will run for approximately 30 minutes. b.

  • Page 10: Prepare The Cleaner For Use

    Prepare the Cleaner for Use a. Charging your cleaner CHARGING TIME: 6-8 HOURS Be sure to charge in a dry, shaded area. The robot cannot be charged while in the pool. But the robot can be charged immediately after removing from the pool. Just make sure that the pins of the robot’s charging jack are dry before plugging in the charger.
  • Page 11 LED will turn solid. It is common for 1 LED to turn solid before the other. If one or both LEDs are not flashing or do not turn solid, contact Water Tech Customer Service. If the CX-1 is charging with the Power (ON/OFF) Button turned ON, the “1-Day”, “Weekly”, and “ON/...

  • Page 12: Filter Bag Mounting

    Prepare the Cleaner for Use b. Filter Bag mounting Closed Cover Unlocked Cover To remove the Filter Bag, flip the CX-1 You will feel the knob “snap” as the lock upside-down and turn the knob on the is undone. Note that the locks will move bottom counter-clockwise.
  • Page 13 Lock Cover Filter Bag & Cover (In) Re-insert the filter bag with the cover on Turn the knob clock-wise to lock the top. Make sure you lock the bag under cover. You will hear a “snap” again as the the two locking tabs (Illustrated above as cover locks.

  • Page 14: Start Cleaning

    Start Cleaning Aim at the pool When the CX-1 is done charging, it’s Aim the CX-1 at the pool (place robot roughly important that you DO NOT submerge the 3 ft. from the edge of the pool). CX-1 in water without replacing the rubber For above ground pools, drop the robot in the pool after plug covering the charging jack.

  • Page 15: Retrieval After Use

    Retrieval After Use Warning! Risk of Drowning! NOT a life saving device. Never allow children or persons who cannot swim to use this product. This product is designed Cleaner can stay in the pool for up to be used around a residential swimming to 7 continuous days, even with pool and a person who cannot swim can drown if they accidentally fall into the pool...

  • Page 16: Owner Performed Maintenance

    Owner Performed Maintenance a. Filter Bag Always remove and clean the filter bag after every use. Do not store the unit with a dirty filter. b. Filter Screen Check the filter screen (Highlighted in red above) for any debris that may have escaped the filter bag.

  • Page 17: Cleaning Bottom Cover

    c. Cleaning bottom cover 1. Press outward on the bottom cover so 2. While still pressing outward, lift the the valve mount can fit around triangular valve mount up and out of the bottom tabs (shown circled above). cover. Rinse out the valve mounts and bottom cover.

  • Page 18: Impeller Maintenance

    CAUTION: Make sure the unit is turned OFF before performing maintenance to impellers! d. Impeller Maintenance 1. It is important to routinely check for 2. Look down at the unit from the debris trapped in the impeller. The top and check for debris around the “Floor Only”...
  • Page 19 CAUTION: Make sure the unit is turned OFF before performing maintenance to impellers! 5. Check inside for any debris and 6. Reassembling Covers: Insert the tab remove the debris by hand. of the cover into the slot on the top of the unit.

  • Page 20: Long Term Storage

    • Don’t leave the CX-1 plugged into the charger. • At the start of the next season, charge the robot and make sure BOTH BATTERY LEDs start flashing while charging. If one or both LEDs are not flashing, contact Water Tech Customer Service.

  • Page 21: Calibration Procedure

    CX-1 Calibration Procedure Only follow the instructions below if instructed to by Water Tech or the Troubleshooting / FAQs section. Make sure that the batteries are FULLY CHARGED and the unit is OUT OF WATER before calibrating. Calibration Procedure: Read all instructions before attempting to calibrate robot.
  • Page 22 5. The pump will turn ON immediately after pressing the button. a. If the pump does not turn ON. Turn the robot OFF and try again. 6. Once the pump turns OFF, the robot has been calibrated. It is now OK to turn the robot OFF or place it by the pool and it will automatically turn ON within 5 seconds.

  • Page 23: Troubleshooting

    • Do NOT purchase an aftermarket solution, and do NOT return your robot • Water Tech is willing to provide a free part that may help prevent this issue. Please contact Water Tech Customer Service to receive a free part.

  • Page 24: Faqs

    • Robot appears to be driving in circles or driving back and forth over the same area. 1. Robot may need calibration. • See page 20 for calibration instructions. 2. If the problem persists, contact Water Tech Customer Service regarding a “Control Box” or “ Pump Motor” issue. • Robot is stuck upside-down in pool.
  • Page 25 • No, the robot has safety features to prevent it from turning ON while charging. If the robot does turn ON during charging, contact Water Tech Customer Service. • DO NOT ATTEMPT TO SUBMERGE THE ROBOT IN WATER WHILE IT IS CHARGING! •...
  • Page 26 • Turn the robot OFF and back ON using the Power (ON/OFF) Button. • Refer to page 10 for more information. • If this problem continues to occur, contact Water Tech Customer Service. • How does the CX-1 drive itself into the pool? •...
  • Page 27 CX-1 FAQs • Once the pool has been properly cleaned after opening, it is safe to use the CX-1. • If my robot is in sleep mode and I clean my bag, what will happen? • When the robot is in sleep mode, it is safe to remove it from the pool. After cleaning the filter bag, the robot can be placed pool side and it will drive itself back into the pool when it wakes up.
  • Page 28 10 Alvin Ct., Suite 111 East Brunswick, NJ 08816 - USA Tel: 732-967-9888 US, Canada & International Fax: 732-967-0070 US & International www.WaterTechCorp.com Register at www.watertechcorp.com/register CX-1 VIP CUSTOMER SERVICE Tel: 732-967-9888 EXT. 250 Email: robotvip@watertechcorp.com Rev.: 7212021...
