- Page 1 SERVICE MANUAL Cursor ® Single Stage Turbocharger Tier 4B (final) and Stage IV Engine See the following page for engine model numbers Part number 47869981 English May 2015 Replaces part numbers 47607266, 47607276, 47607286, 47607296...
- Page 2 SERVICE MANUAL F3HFE613A*B003 , F3HFE613B*B001 , F3HFE613B*B002 , F3HFE613D*B001 , F3HFE613D*B002 , F3HFE613G*B001 , F3HFE613G*B002 47869981 01/05/2015 Find manuals at https://best-manuals.com...
- Page 3 Contents INTRODUCTION Engine..................10 [10.001] Engine and crankcase ............. 10.1 [10.101] Cylinder heads .
- Page 4 [55.301] Alternator ................55.8 [55.988] Selective Catalytic Reduction (SCR) electrical system .
- Page 5 47869981 01/05/2015 Find manuals at https://best-manuals.com...
- Page 6 INTRODUCTION 47869981 01/05/2015 Find manuals at https://best-manuals.com...
-
Page 7: Table Of Contents
Contents INTRODUCTION Foreword - Important notice regarding equipment servicing ........3 Safety rules . -
Page 8: Foreword - Important Notice Regarding Equipment Servicing
Specifications, descriptions, and illustrative material herein are as accurate as known at time of publication but are subject to change without notice. In case of questions, refer to your CNH Sales and Service Networks. 47869981 01/05/2015... -
Page 9: Safety Rules
INTRODUCTION Safety rules Personal safety This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible death or injury. Throughout this manual and on machine decals, you will find the signal words DANGER, WARNING, and CAUTION followed by special instructions. -
Page 10: Safety Rules - Ecology And The Environment
CNH strongly recommends that you return all used batteries to a CNH dealer, who will dispose of the used batteries or recycle the used batteries properly. In some countries, this is a legal requirement. -
Page 11: Torque - Minimum Tightening Torques For Normal Assembly
INTRODUCTION Torque - Minimum tightening torques for normal assembly METRIC NON-FLANGED HARDWARE NOM. LOCKNUT LOCKNUT SIZE CL.8 CL.10 CLASS 8.8 BOLT and CLASS 10.9 BOLT and W/CL8.8 W/CL10.9 CLASS 8 NUT CLASS 10 NUT BOLT BOLT PLATED PLATED UNPLATED UNPLATED W/ZnCr W/ZnCr 2.2 N·m (19 lb... - Page 12 INTRODUCTION METRIC FLANGED HARDWARE NOM. CLASS 8.8 BOLT and CLASS 10.9 BOLT and LOCKNUT LOCKNUT SIZE CLASS 8 NUT CLASS 10 NUT CL.8 CL.10 W/CL8.8 W/CL10.9 BOLT BOLT PLATED PLATED UNPLATED UNPLATED W/ZnCr W/ZnCr 2.4 N·m (21 lb 3.2 N·m (28 lb 3.5 N·m (31 lb 4.6 N·m (41 lb 2.2 N·m (19 lb...
- Page 13 INTRODUCTION 1. Manufacturer's Identification 2. Property Class 3. Clock Marking of Property Class and Manufacturer's Identification (Optional), i.e. marks 60 ° apart indicate Class 10 properties, and marks 120 ° apart indicate Class 8. INCH NON-FLANGED HARDWARE LOCKNUT LOCKNUT NOMINAL SAE GRADE 5 BOLT SAE GRADE 8 BOLT GrB W/ Gr5...
- Page 14 INTRODUCTION INCH FLANGED HARDWARE NOM- LOCKNUT LOCKNUT SAE GRADE 5 BOLT and SAE GRADE 8 BOLT and INAL GrF W/ Gr5 GrG W/ Gr8 SIZE BOLT BOLT UNPLATED PLATED UNPLATED PLATED or PLATED W/ZnCr or PLATED W/ZnCr SILVER GOLD SILVER GOLD 12 N·m (106 lb 13 N·m (115 lb...
- Page 15 INTRODUCTION Inch Lock Nuts, All Metal (Three optional methods) 20090268 Grade Identification Grade Corner Marking Method (1) Flats Marking Method (2) Clock Marking Method (3) Grade A No Notches No Mark No Marks Grade B One Circumferential Notch Letter B Three Marks Grade C Two Circumferential Notches...
-
Page 16: Basic Instructions - Shop And Assembly
Only use CNH Original Parts or CNH Original Parts. Only genuine spare parts guarantee the same quality, duration, and safety as original parts, as they are the same parts that are assembled during standard production. Only CNH Original Parts or CNH Original Parts can offer this guarantee. - Page 17 W0111A Special tools The special tools that CNH suggests and illustrate in this manual have been specifically researched and designed for use with CNH machines. The special tools are essential for reliable repair operations. The special tools are accurately built and rigorously tested to offer efficient and long-lasting operation.
- Page 18 SERVICE MANUAL Engine F3HFE613A*B003 , F3HFE613B*B001 , F3HFE613B*B002 , F3HFE613D*B001 , F3HFE613D*B002 , F3HFE613G*B001 , F3HFE613G*B002 47869981 01/05/2015...
- Page 19 Contents Engine - 10 [10.001] Engine and crankcase ............. . . 10.1 [10.101] Cylinder heads .
- Page 20 Engine - 10 Engine and crankcase - 001 F3HFE613A*B003 , F3HFE613B*B001 , F3HFE613B*B002 , F3HFE613D*B001 , F3HFE613D*B002 , F3HFE613G*B001 , F3HFE613G*B002 47869981 01/05/2015 10.1 [10.001] / 1...
- Page 21 Contents Engine - 10 Engine and crankcase - 001 TECHNICAL DATA Engine Service limits ................3 SERVICE Engine Service instruction - Finding Top Dead Center (TDC) .
- Page 22 Engine - Engine and crankcase Engine - Service limits Engine specifications 16.5 : 1 Compression Ratio Bore 135 mm (5.3 in) Stroke 150 mm (5.9 in) Displacement 12880 cm³ Turbocharging Inter-cooled, Direct injection Turbocharger type Holset HE551 Lubrication Forced by gear pump, relief valve single action Oil Pressure (Warm engine) - Idling...
- Page 23 Engine - Engine and crankcase - Intermediate ring 1.470 - 1.500 mm (0.058 - 0.059 in) - Oil control ring 4.970 - 4.990 mm (0.196 - 0.196 in) Clearance between piston rings and grooves - Combustion ring 0.100 - 0.120 mm (0.004 - 0.005 in) - Intermediate ring 0.050 - 0.100 mm (0.002 - 0.004 in) - Oil control ring...
- Page 24 Engine - Engine and crankcase Main journal, thrust bearing 47.95 - 48.00 mm (1.888 - 1.890 in) Main bearing housing, thrust bearing 40.94 - 40.99 mm (1.612 - 1.614 in) Thrust bearing thickness 3.38 - 3.43 mm (0.133 - 0.135 in) Crankshaft end play 0.10 - 0.30 mm (0.0039 - 0.0118 in) Main journals and crankpins...
- Page 25 Engine - Engine and crankcase - Injector 46.000 - 46.016 mm (1.8110 - 1.8117 in) Bushing outside diameter for rocker arms - Intake 45.090 - 45.130 mm (1.7752 - 1.7768 in) - Exhaust 59.100 - 59.140 mm (2.3268 - 2.3283 in) - Injector 46.066 - 46.091 mm (1.8136 - 1.8146 in) Bushing inside diameter for rocker arms...
- Page 26 Engine - Engine and crankcase Engine - Service instruction - Finding Top Dead Center (TDC) For engines with a full flywheel housing 1. Using the tool 380000137, turn the engine flywheel (1) in the direction of normal rotation until you see the hole with two reference marks (3) through the inspection window at the bottom of the housing.
- Page 27 Engine - Engine and crankcase 4. The exact position of piston number one at TDC is ob- tained when the tool 380000150 (1) can be inserted through the hole (2) of the flywheel speed sensor and engage the hole (3) in the engine flywheel (4). 5.
- Page 28 Engine - Engine and crankcase Crankcase Liner - Measure Prior operation: Crankcase Liner - Remove (10.001) 1. The internal diameter of the cylinder liner is checked for ovalization, taper, and wear, using a bore dial (1) centesimal gauge (2) previously set to ring gauge (3), which has a diameter of 135 mm (5.315 in).
- Page 29 Engine - Engine and crankcase 3. Upon finding a maximum wear value greater than 0.150 mm (0.006 in) or maximum ovalization value greater than 0.100 mm (0.004 in) as compared to the values in the following table, you need to replace the cylinder liner.
- Page 30 Engine - Engine and crankcase NHIL13ENG1312FA Crankcase Assembly With Cylinder Liners LINERDATA Main Cylinder Liner Data 47869981 01/05/2015 10.1 [10.001] / 11...
- Page 31 This as a preview PDF file from best-manuals.com Download full PDF manual at best-manuals.com...
