Owner's Manual
TC-260
SERVICE BODIES
Proudly built in the USA
TruckCraft Corporation
Chambersburg, PA
1-800-755-3867
Rev 02/2018
Copyright 2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TC-260 and is the answer not in the manual?

Questions and answers

Related Manuals for TruckCraft TC-260

Summary of Contents for TruckCraft TC-260

  • Page 1 Owner’s Manual TC-260 SERVICE BODIES Proudly built in the USA TruckCraft Corporation Chambersburg, PA 1-800-755-3867 Rev 02/2018 Copyright 2018...

  • Page 2: Table Of Contents

    TruckCraft Corporation Tel. (800) 755-3867 5751 Molly Pitcher Hwy South Fax. (717) 375-2975 Chambersburg, PA 17202 E-Mail: sales@truckcraft.com Web: www.truckcraft.com TC-260 Service Bodies Table of Contents Page # Warranty 3 & 4 Warranty Registration Operator Safety Warnings Service Body Options •...
  • Page 3 All repairs must be authorized be TruckCraft prior to any work being completed. If after inspection TruckCraft determines the product is defective in material or workmanship as claimed.

  • Page 4: Warranty 3

    TruckCraft’s obligations are limited to those expressed in this warranty and TruckCraft shall not be liable to the purchaser or any third party for any direct or indirect, incidental or consequential damage or loss. Some states do not allow limitations on how long an implied warranty lasts or exclusions or limitations of incidental or consequential damages, so the above limitations or exclusions may not apply to you.

  • Page 5: Warranty Registration

    Service Body will give you many years of outstanding service. To provide you with the superior support that you deserve, we request that you register your warranty with us. To register your warranty, please complete this form and mail or fax it to TruckCraft within 30 days of purchase.

  • Page 6: Operator Safety Warnings

    Fax. (717) 375-2975 Chambersburg, PA 17202 E-Mail: sales@truckcraft.com TC-260 Service Bodies Web: www.truckcraft.com Operator Safety Warnings ALWAYS store the remote control in a location that assures that no object can come in contact with the LOCK & UNLOCK button unintentionally.

  • Page 7: Service Body Options

    Web: www.truckcraft.com Service Body Options The TC-260 was designed to give the customer a wide range of body options for the SRW pickups with a 60CA. and a weight of the unit is 697 lbs. The three main body configurations are, A/B, A/A &...

  • Page 8: A/B Body (D1-08597)

    TruckCraft Corporation Tel. (800) 755-3867 5751 Molly Pitcher Hwy South Fax. (717) 375-2975 Chambersburg, PA 17202 E-Mail: sales@truckcraft.com TC-260 Service Bodies Web: www.truckcraft.com A/B BODY (D1-08597) Copyright 2018 TruckCraft Corporation Revised 02/2018 Page 8...

  • Page 9: A/A Body (D1-08613)

    TruckCraft Corporation Tel. (800) 755-3867 5751 Molly Pitcher Hwy South Fax. (717) 375-2975 Chambersburg, PA 17202 E-Mail: sales@truckcraft.com TC-260 Service Bodies Web: www.truckcraft.com A/A BODY (D1-08613) Copyright 2018 TruckCraft Corporation Revised 02/2018 Page 9...

  • Page 10: B/B Body (D1-08841)

    TruckCraft Corporation Tel. (800) 755-3867 5751 Molly Pitcher Hwy South Fax. (717) 375-2975 Chambersburg, PA 17202 E-Mail: sales@truckcraft.com TC-260 Service Bodies Web: www.truckcraft.com B/B BODY (D1-08841) Copyright 2018 TruckCraft Corporation Revised 02/2018 Page 10...

  • Page 11: Service Body Mounting / Installation Kits

    (FORD, GM & RAM). Also, we have mounting kits to fit up to all three manufacturers for both bumpers. This will give our distributor s an easier method of installing our bodies. Listed below is the Mounting and Bumper Kits for the TC-260 Service Bodies. MTG KIT (2017 FORD) (D2-08617)
  • Page 12 TruckCraft Corporation Tel. (800) 755-3867 5751 Molly Pitcher Hwy South Fax. (717) 375-2975 Chambersburg, PA 17202 E-Mail: sales@truckcraft.com TC-260 Service Bodies Web: www.truckcraft.com MTG KIT (2017 FORD) (D2-08617) Page 2 Copyright 2018 TruckCraft Corporation Revised 02/2018 Page 12...

  • Page 13: D2-08769 Mtg Kit (2016 Ford)

    TruckCraft Corporation Tel. (800) 755-3867 5751 Molly Pitcher Hwy South Fax. (717) 375-2975 Chambersburg, PA 17202 E-Mail: sales@truckcraft.com TC-260 Service Bodies Web: www.truckcraft.com MTG KIT (2016 FORD) (D2-08769) Copyright 2018 TruckCraft Corporation Revised 02/2018 Page 13...

  • Page 14: D2-08774 Mtg Kit (Gm)

    TruckCraft Corporation Tel. (800) 755-3867 5751 Molly Pitcher Hwy South Fax. (717) 375-2975 Chambersburg, PA 17202 E-Mail: sales@truckcraft.com TC-260 Service Bodies Web: www.truckcraft.com MTG KIT (RAM) (D2-08774) Copyright 2018 TruckCraft Corporation Revised 02/2018 Page 14...

  • Page 15: D2-08773 Mtg Kit (Ram)

    TruckCraft Corporation Tel. (800) 755-3867 5751 Molly Pitcher Hwy South Fax. (717) 375-2975 Chambersburg, PA 17202 E-Mail: sales@truckcraft.com TC-260 Service Bodies Web: www.truckcraft.com MTG KIT (GM) (D2-08773) Copyright 2018 TruckCraft Corporation Revised 02/2018 Page 15...

  • Page 16: D2-08618 Step Bumper Kit (2017 Ford)

    Fax. (717) 375-2975 Chambersburg, PA 17202 E-Mail: sales@truckcraft.com TC-260 Service Bodies Web: www.truckcraft.com OPTIONAL: V-NOTCH STEP BUMPER KIT Description: Each A/B, A/A and B/B body configuration has the option to have a Bumper kit for the following (FORD, DODGE & GM) models.

  • Page 17: D2-08775 Step Bumper Kit (2016 Ford)

    TruckCraft Corporation Tel. (800) 755-3867 5751 Molly Pitcher Hwy South Fax. (717) 375-2975 Chambersburg, PA 17202 E-Mail: sales@truckcraft.com TC-260 Service Bodies Web: www.truckcraft.com STEP BUMPER KIT (D2-08775) 2016 FORD Copyright 2018 TruckCraft Corporation Revised 02/2018 Page 17...

  • Page 18: D2-08776 Step Bumper Kit (Ram)

    TruckCraft Corporation Tel. (800) 755-3867 5751 Molly Pitcher Hwy South Fax. (717) 375-2975 Chambersburg, PA 17202 E-Mail: sales@truckcraft.com TC-260 Service Bodies Web: www.truckcraft.com STEP BUMPER KIT (D2-08776) GM Copyright 2018 TruckCraft Corporation Revised 02/2018 Page 18...

  • Page 19: D2-08777 Step Bumper Kit (Gm)

    TruckCraft Corporation Tel. (800) 755-3867 5751 Molly Pitcher Hwy South Fax. (717) 375-2975 Chambersburg, PA 17202 E-Mail: sales@truckcraft.com TC-260 Service Bodies Web: www.truckcraft.com STEP BUMPER (D2-08777) RAM Copyright 2018 TruckCraft Corporation Revised 02/2018 Page 19...

  • Page 20: Tc-260 Product Specifications

    TruckCraft Corporation Tel. (800) 755-3867 5751 Molly Pitcher Hwy South Fax. (717) 375-2975 Chambersburg, PA 17202 E-Mail: sales@truckcraft.com TC-260 Service Bodies Web: www.truckcraft.com TC-260 Product Specifications SERVICE BODY TC-260 Whatever the chassis manufacturer Capacity recommends & minus 697 lbs. for the service...

  • Page 21: Optional Keyless Entry & Led Lighting

    NOTE: TruckCraft also offers a field installation kit for Keyless Entry & Lighting on the TC-260 service body. A six-lock kit (D2-07790) is available for the A-A Body configuration.

  • Page 22: Keyless/Electrical Wiring Kit (D2-07791)

    TruckCraft Corporation Tel. (800) 755-3867 5751 Molly Pitcher Hwy South Fax. (717) 375-2975 Chambersburg, PA 17202 E-Mail: sales@truckcraft.com TC-260 Service Bodies Web: www.truckcraft.com Keyless/Electrical Wiring Kit (D2-07791) For A-B Body W/ 7 Locks Copyright 2018 TruckCraft Corporation Revised 02/2018 Page 22...

  • Page 23: Keyless/Electrical Wiring Kit (D2-07800)

    TruckCraft Corporation Tel. (800) 755-3867 5751 Molly Pitcher Hwy South Fax. (717) 375-2975 Chambersburg, PA 17202 E-Mail: sales@truckcraft.com TC-260 Service Bodies Web: www.truckcraft.com Keyless/Electrical Wiring Kit (D2-02800) For B-B Body W/ 8 Locks Copyright 2018 TruckCraft Corporation Revised 02/2018 Page 23...

  • Page 24: Keyless Wire Harness Pigtail Assy For B-B Body (D2-08845)

    Tel. (800) 755-3867 5751 Molly Pitcher Hwy South Fax. (717) 375-2975 Chambersburg, PA 17202 E-Mail: sales@truckcraft.com TC-260 Service Bodies Web: www.truckcraft.com (D2-08845) Keyless Wire Harness Pigtail Assy for B-B Body W/ 8 Locks Copyright 2018 TruckCraft Corporation Revised 02/2018 Page 24...

  • Page 25: Keyless/Electrical Wiring Inst'l (D1-07927)

    TruckCraft Corporation Tel. (800) 755-3867 5751 Molly Pitcher Hwy South Fax. (717) 375-2975 Chambersburg, PA 17202 E-Mail: sales@truckcraft.com TC-260 Service Bodies Web: www.truckcraft.com Keyless/Electrical Wiring Inst’l (D1-07927) Copyright 2018 TruckCraft Corporation Revised 02/2018 Page 25...

  • Page 26: D2-08423 A/B Wiring Layout

    TruckCraft Corporation Tel. (800) 755-3867 5751 Molly Pitcher Hwy South Fax. (717) 375-2975 Chambersburg, PA 17202 E-Mail: sales@truckcraft.com TC-260 Service Bodies Web: www.truckcraft.com LED Lighting For A/B BODY (D2-08423) Copyright 2018 TruckCraft Corporation Revised 02/2018 Page 26...

  • Page 27: D2-08424 A/A Wiring Layout

    TruckCraft Corporation Tel. (800) 755-3867 5751 Molly Pitcher Hwy South Fax. (717) 375-2975 Chambersburg, PA 17202 E-Mail: sales@truckcraft.com TC-260 Service Bodies Web: www.truckcraft.com LED Lighting For A/A BODY (D2-08424) Copyright 2018 TruckCraft Corporation Revised 02/2018 Page 27...

  • Page 28: D2-08425 B/B Wiring Layout

    TruckCraft Corporation Tel. (800) 755-3867 5751 Molly Pitcher Hwy South Fax. (717) 375-2975 Chambersburg, PA 17202 E-Mail: sales@truckcraft.com TC-260 Service Bodies Web: www.truckcraft.com LED Lighting For B/B BODY (D2-08425) Copyright 2018 TruckCraft Corporation Revised 02/2018 Page 28...

  • Page 29: Overall Key Product Dimensions (D3-08598)

    TruckCraft Corporation Tel. (800) 755-3867 5751 Molly Pitcher Hwy South Fax. (717) 375-2975 Chambersburg, PA 17202 E-Mail: sales@truckcraft.com TC-260 Service Bodies Web: www.truckcraft.com Overall Key Product Dimensions – TC-260 Copyright 2018 TruckCraft Corporation Revised 02/2018 Page 29...

  • Page 30: Major Product Components 30

    Tel. (800) 755-3867 5751 Molly Pitcher Hwy South Fax. (717) 375-2975 Chambersburg, PA 17202 E-Mail: sales@truckcraft.com TC-260 Service Bodies Web: www.truckcraft.com Major Product Components Keyless Entry Latch W/ Cover Gas Spring Door Strut Location of Keyless/Elect. Box (Pass. Side) Location of Light Cover (Upper Corner)
  • Page 31 Tel. (800) 755-3867 5751 Molly Pitcher Hwy South Fax. (717) 375-2975 Chambersburg, PA 17202 E-Mail: sales@truckcraft.com TC-260 Service Bodies Web: www.truckcraft.com Service Body Trays Horizontal Door Cables Horizontal Double Lock Door For 7 & 8 Locks Copyright 2018 TruckCraft Corporation...

  • Page 32: General Maintenance Instructions

    Fax. (717) 375-2975 Chambersburg, PA 17202 E-Mail: sales@truckcraft.com TC-260 Service Bodies Web: www.truckcraft.com General Maintenance Instructions ALWAYS wash your service body after any after major storm in the winter months to remove the road chemicals and salt. This will help in keeping your unit from being stained. If possible, a good wax should be used on your service body to help keep it looking good and protect the aluminum finish.
