- Page 1 INSTRUCTION MANUAL Angle Grinder GA7063 GA7063R GA9063 GA9063R DOUBLE INSULATION Read before use.
-
Page 2: Specifications
) : 91 dB(A) Sound power level (L ) : 102 dB (A) Uncertainty (K) : 3 dB(A) Wear safety glasses. Model GA7063R Sound pressure level (L ) : 91 dB(A) Sound power level (L ) : 102 dB (A) -
Page 3: Ec Declaration Of Conformity
Work mode: surface grinding with anti vibration side grip SAFETY WARNINGS Vibration emission (a ) : 6.5 m/s h, AG Uncertainty (K) : 1.5 m/s Work mode: disc sanding with normal side grip General power tool safety warnings Vibration emission (a ) : 2.5 m/s h, DS Uncertainty (K) : 1.5 m/s... -
Page 4: Grinder Safety Warnings
Use personal protective equipment. Always Service wear eye protection. Protective equipment such Have your power tool serviced by a qualified as a dust mask, non-skid safety shoes, hard hat or repair person using only identical replacement hearing protection used for appropriate conditions parts. - Page 5 Wear personal protective equipment. Maintain a firm grip on the power tool and Depending on application, use face shield, position your body and arm to allow you to safety goggles or safety glasses. As appro- resist kickback forces. Always use auxiliary priate, wear dust mask, hearing protectors, handle, if provided, for maximum control over gloves and workshop apron capable of stop-...
- Page 6 Do not position your body in line with and Before using the tool on an actual workpiece, behind the rotating wheel. When the wheel, at let it run for a while. Watch for vibration or the point of operation, is moving away from your wobbling that could indicate poor installation body, the possible kickback may propel the spin- or a poorly balanced wheel.
-
Page 7: Functional Description
"OFF" position when without pressing in the lock-off button. This can released. cause switch breakage. Indication lamp Only for model GA7063R / GA9063R ► 1. Switch trigger 2. Lock lever ► 1. Indication lamp 7 ENGLISH... - Page 8 Only for model GA7063R / GA9063R the closed side of the guard always points toward The tool does not start with the switch being lock-on the operator.
- Page 9 ► 1. Wheel guard 2. Bearing box 3. Screw 4. Lever ► 1. Lock nut 2. Depressed center wheel 3. Inner flange 4. Mounting part Pull the lever in direction of the arrow. Then tighten the wheel guard with fastening the screw. Be sure to tighten To tighten the lock nut, press the shaft lock firmly so the screw securely.
-
Page 10: Operation
Follow instructions for depressed center wheel but also OPERATION use back up pad over wheel. See order of assembly on accessories page in this manual. Super flange WARNING: It should never be necessary to force the tool. The weight of the tool applies ade- quate pressure. - Page 11 For Australia and New Zealand Operation with abrasive cut-off / diamond wheel ø45 Optional accessory ø78 WARNING: When using an abrasive cut-off / diamond wheel, be sure to use only the special wheel guard designed for use with cut-off wheels. (In some European countries, when using a diamond wheel, the ordinary guard can be used.
-
Page 12: Maintenance
It may lead to premature breakage. ► 1. Screw To maintain product SAFETY and RELIABILITY, repairs, any other maintenance or adjustment should be performed by Makita Authorized or Factory Service Centers, always using Makita replacement parts. 12 ENGLISH... -
Page 13: Optional Accessories
The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for its stated purpose. If you need any assistance for more details regarding these accessories, ask your local Makita Service Center. Side grip... - Page 16 Makita Europe N.V. Jan-Baptist Vinkstraat 2, 3070 Kortenberg, Belgium Makita Corporation 3-11-8, Sumiyoshi-cho, Anjo, Aichi 446-8502 Japan 885566A225 www.makita.com 20161124...
