Reeva UBESO601SS User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

User Manual for your
UBESO601SS
NOTE
: This User Instruction Manual contains important
information, including safety & installation points, which will
enable you to get the most out of your appliance. Please keep it
in a safe place so that it is easily available for future reference; for
you or any person not familiar with the operation of the appliance.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UBESO601SS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Reeva UBESO601SS

Summary of Contents for Reeva UBESO601SS

  • Page 1 User Manual for your UBESO601SS NOTE : This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference; for...

  • Page 2: Table Of Contents

    Contents Environmental note Important safety information 4 - 6 Specifications 7 - 9 Product and aperture dimensions Product specifications Standard accessories Electrical details Cooling fan Control panel Selecting a cooking function and temperature 9 - 13 Before first use Selecting an oven function Oven functions Thermostat control knob Oven operating light...

  • Page 3: Environmental Note

    Environmental note o The packaging materials that the manufacturer uses are environmentally friendly and can be recycled. o Please discard all packaging material with due regard for the environment.

  • Page 4: Important Safety Information

    IMPORTANT SAFETY INFORMATION Your safety is of the utmost importance to us. Please make sure that you read this instruction booklet before attempting to install or use the appliance. If you are unsure of any of the information contained in this booklet, please contact the Customer Care Department.
  • Page 5 o This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Child Safety o We strongly recommend that babies and young children are prevented from being near to the appliance and not allowed to...
  • Page 6 o IMPORTANT: The appliance must be disconnected from the mains before following the cleaning procedure. Installation This appliance must be correctly installed by a suitably qualified person, strictly in accordance with the manufacturer’s instructions. o The manufacturer declines any responsibility for injury or damage, to person or property, as a result of improper use or installation of this appliance.

  • Page 7: Specifications

    Specifications Product Dimensions Aperture Dimensions Height: 595 mm 600 mm Width: 595 mm 560 mm Depth: 530 mm 560 mm (min) Product specifications o 4 oven functions o Oven net/gross capacity: 62/70 liters o Energy efficiency class: A o Cooling fan o Double-glazed removable door o Removable inner door glass o Mark resistant coating...

  • Page 8: Electrical Details

    o Handle Electrical details Rated Voltage: 220-240 Vac, 50 Hz Supply Connection: 10A (double pole switched fused outlet with 3mm contact gap) Rated max power: 2.20 kW Mains Supply Lead: 3 x 1.0mm² Oven Light Bulb: 25 W/300°C screw type pygmy Cooling fan o A tangential cooling fan is fitted inside of this appliance, to make the internal temperature of the oven stable and the external...

  • Page 9: Selecting A Cooking Function And Temperature

    Selecting a cooking function and temperature IMPORTANT: Make sure that you have sent your oven into manual operation mode before selecting an oven function and temperature. Before first use o To remove any residue from the oven that may have been left from the manufacturing process, you should select the fan oven function and set the thermostat to its maximum temperature setting.

  • Page 10: Oven Functions

    Oven functions OVEN LIGHT: Separate light control which allows the light to be switched on, even when the oven is not cooking. CONVENTIONAL OVEN: This method of cooking provides traditional cooking, with heat from the top and lower elements. This function is suitable for roasting and baking on one shelf level only.

  • Page 11: Cooking Guidelines

    cycle on and off throughout the cooking time. You should not place food inside the cavity, until the correct cooking temperature has been reached. Cooking guidelines o Please refer to the information given on food packaging for guidance on cooking temperatures and times. Once familiar with the performance of your appliance, temperatures and times can be varied to suit personal preference.

  • Page 12: Warnings

    Warnings o Keep the oven door closed when using any of the cooking functions, including the grill functions. o Do not use aluminium foil to cover the grill pan or heat items wrapped in aluminium foil under the grill. The high reflectivity of the foil could potentially damage the grill element.

  • Page 13: Cleaning And Maintenance

    shelf into the oven, lift the front of the shelf slightly to bypass the stops and allow the oven shelf to slide fully into the racks. o To remove the oven shelf, gently pull the oven shelf outwards. When the shelf stops, lift the front slightly to bypass the safety stops and then completely withdraw the oven shelf from the oven.

  • Page 14: Replacing The Oven Bulb

    o We would recommend that an appropriate stainless steel cleaner and polish is regularly used on the stainless steel surfaces of this appliance. o If you use any form of oven cleaner on your appliance, then you must check with the manufacturer of the cleaner that it is suitable for use on your appliance.

  • Page 15: Removing The Oven Door For Cleaning

    Removing the oven door for cleaning To facilitate the cleaning of the inside of the oven and the outer frame of the oven, the door can be removed as follows:- o The hinges (A) have two movable bolts on them (B). o If you raise both of the movable bolts (B), then the hinges (A) are released from the oven housing.

  • Page 16: Removing The Inner Door Glass For Cleaning

    Removing the inner door glass for cleaning o Do not use any abrasive cleaner that could cause damage. o Remember that if the surface of the glass panel becomes scratched, this could lead to a dangerous failure. o To facilitate cleaning, the inner door glass can be lifted out. o Unscrew the bracket latch that is in the corner of the top of the door.

  • Page 17: Electrical Connection

    Electrical connection Before connecting the appliance, make sure that the supply voltage marked on the rating plate corresponds with your mains supply voltage. WARNING: THIS APPLIANCE MUST BE EARTHED. o This appliance should be wired into a 10A double pole switched fused spur outlet, having 3 mm contact separation and placed in an easily accessible position adjacent to the appliance.

  • Page 18: Installing The Oven Into The Kitchen Cabinet

    o If the mains supply cable is damaged, then it must be replaced by an appropriate replacement which can be obtained from the Spares Department. Installing the oven into the kitchen cabinet Positioning the appliance o Ensure that the aperture that you will be fitting the oven into is of the size given in the above diagram.

  • Page 19: Ventilation Requirements

    Ventilation requirements (Figure shows the ventilation and cut-out requirements for the installation of the appliance into a standard kitchen unit). (Figure shows the ventilation and cut-out requirements for the installation of the appliance into a tall housing unit). o Ensure that the oven has been securely fixed into the housing unit.

  • Page 20: My Appliance Isn't Working Correctly

    My appliance isn’t working correctly o The oven isn’t coming on. * Check that the oven is in manual operation mode. * Check that you have selected a cooking function and a cooking temperature. o There appears to be no power to the oven and grill. * Check that the appliance has been connected to the electrical mains supply correctly.
  • Page 21 o I am getting condensation in my oven * Steam and condensation is a natural by product of cooking any food with high water content, such as frozen food, chicken etc. * You may get condensation in the oven cavity and forming between the oven door glasses.
