User Manual for your
ICON80IX
NOTE
: This User Instruction Manual contains important
information, including safety & installation points, which will
enable you to get the most out of your appliance. Please keep it
in a safe place so that it is easily available for future reference; for
you or any person not familiar with the operation of the appliance.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Reeva ICON80IX
Summary of Contents for Reeva ICON80IX
- Page 1 User Manual for your ICON80IX NOTE : This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference; for...
-
Page 2: Table Of Contents
Contents Environmental note Important safety information 4 - 7 Specifications 8 - 10 Product and aperture dimensions Product specifications Standard accessories Electrical details Cooling fan Control panel Setting and using the oven programmer/timer 10-15 Setting clock (the time of day) Before first use Selecting a cooking function and temperature Setting the minute minder function... -
Page 3: Environmental Note
Environmental note o The packaging materials that the manufacturer uses are environmentally friendly and can be recycled. o Please discard all packaging material with due regard for the environment. -
Page 4: Important Safety Information
IMPORTANT SAFETY INFORMATION Your safety is of the utmost importance to us. Please make sure that you read this instruction booklet before attempting to install or use the appliance. If you are unsure of any of the information contained in this booklet, please contact the Customer Care Department. - Page 5 Warning and safety instructions o This appliance complies with all current European safety legislation. The manufacturer does wish to emphasise that this compliance does not remove the fact that the appliance surfaces will become hot during use and retain heat after operation. o This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given...
- Page 6 o Do not attempt to lift or move cooking appliances by using the oven door or handle, as this may cause damage to the appliance or result in injury to the person lifting the appliance. Cleaning o Cleaning of the oven should be carried out on a regular basis. o Great care should be taken whilst using this appliance and when following the cleaning procedure.
- Page 7 Declaration of conformity This appliance complies with the following European Directives: - 2014/35/EU regarding “low voltage” - 2014/30/EU regarding “electromagnetic disturbances” - Regulation (EC) N° 1935/2004 regarding “materials in contact with food” o The above directives comply with 93/68/EEC regarding CE marking. o The manufacturer declares that the oven is built using certified materials and requires the appliance to be installed in accordance with the standards currently in force.
-
Page 8: Specifications
Specifications Product Dimensions Aperture Dimensions Height: 595 mm 600 mm Width: 595 mm 560 mm Depth: 575 mm 560 mm (min) Product specifications o 10 oven functions o Energy efficiency class: A o Oven net/gross capacity: 80/82 liters o LCD fully programmable timer o Cooling fan o Thermostatically controlled grill o Double-glazed removable door... -
Page 9: Standard Accessories
Standard accessories Accessory Name Picture Quantity Baking tray Grill Handle Screws(ST4x35) Electrical details Rated Voltage: 220-240 Vac, 50/60 Hz Supply Connection: Rated max power : 2.90 kW Mains Supply Lead: 3 x 1.5mm² Oven Light Bulb: 25 W/300°C screw type pygmy Cooling fan o A tangential cooling fan is fitted inside of this appliance, to make the internal temperature of the oven stable and the external... -
Page 10: Control Panel
Control Panel Touch buttons Child lock Clock Timer Temperature Time/Temperature decreasing Time/Temperature increasing Pause/Cancel Confirm/Start Symbol in the display Clock time Cooking duration End cooking time Child lock indicator Timer Setting and using the oven programmer/timer Setting clock (the time of day) o Once you new appliance has been connected to the power supply, the left area of display shows “12:00”... -
Page 11: Before First Use
o If you want to cancel the setting, press the button once. The display will show “12:00” or the original time. Before first use o To remove any residue from the oven that may have been left from the manufacturing process, you should select the fan oven function and set the thermostat to its maximum temperature setting. -
Page 12: Setting The Minute Minder Function
o Press the buttons to select the desired function and the display will show the default temperature. The selected symbol of function will flash, others symbol will be constantly on. o Press the button and use buttons to set the desired temperature of corresponding functions. -
Page 13: Setting The Duration Function
o Press the button once, the symbol and the time digit will flash, you can use to adjust the required cooking time. o Press to start working, display will show cooking duration you set and start count down till time up. The symbol, temperature and the symbol of function will be constantly on. -
Page 14: Child Lock
o When the set cooking finishing time is reached, all display goes off except the clock and the buzzer will sound for 10 times. Child lock o Press the child lock for 3 seconds to activate the function and all touch buttons are locked for unintended use. -
Page 15: Function Introduction
Function introduction Oven functions OVEN LIGHT: Separate light control which allows the light to be switched on, even when the oven is not cooking. Defrosting: This function allows all frozen foods to be rapidly and delicately thawed thanks to the internal fan. Bottom Element: Oven is heated using only the bottom element. -
Page 16: Cooking Guidelines
FAN OVEN: This method of cooking uses the circular element while the heat is distributed by the fan. This results in a faster and more economical cooking process. The fan oven allows food to be cooked simultaneously on different shelves, preventing the transmission of smells and tastes from one dish onto another. -
Page 17: Warnings
o If you are using the fan oven function, then you should follow the information given on the food packaging for this particular mode of cooking. o You should pre-heat the oven and not place food inside of it until the oven operating light has gone off. -
Page 18: Shelf Positions
o During cooking, never place pans or cookware directly onto the bottom of your oven. They should always be placed on the shelves provided. o The internal components of the oven become extremely hot during operation, care should be taken avoid touching them inadvertently. o Important: Be careful when opening the door, to avoid contact with hot parts of the oven and steam. -
Page 19: Cleaning And Maintenance
o When installed correctly, the shelf and tray should be horizontal and not on an angle. Cleaning and maintenance Cleaning operations must only be carried out when the oven is cool. The appliance should be disconnected from your mains supply before commencing cleaning... -
Page 20: Replacing The Oven Bulb
o If you use any form of oven cleaner on your appliance, then you must check with the manufacturer of the cleaner that it is suitable for use on your appliance. o Do not use harsh or abrasive cleaners or sharp metal scrapers to clean the oven door glass since they can scratch the surface which may result in shattering. -
Page 21: Removing The Oven Door For Cleaning
o Replace the bulb with a 25 W/300°C, screw type pygmy. o Do not use any other type of bulb. o Place the lamp cover back into position. Removing the oven door for cleaning To facilitate the cleaning of the inside of the oven and the outer frame of the oven, the door can be removed as follows: The hinges (A) have two movable bolts on them (B). -
Page 22: Removing The Inner Door Glass For Cleaning
o The oven door and door glass should only be cleaned using a damp cloth and a small amount of detergent. The cloth MUST NOT have come into contact with any form of cleaning product or chemical previously. o To refit the door you should slide the hinges back into their slots and open the door fully. -
Page 23: Installation
o After cleaning, insert the glass panel correctly back into the door. Screw the bracket latch back into place. o IMPORTANT: Remember where the panel of glass is removed from so you can reassemble the door correctly. Do not mix the glasses up or rearrange the order. INSTALLATION The installation must be carried out by a suitably qualified person, in accordance with the current... - Page 24 To connect the oven power cord, remove the cover on the terminal block, in order to gain access to the contacts inside. Make the connection, securing the cord in place with the cable clamp provided and then immediately close the terminal block cover again.
-
Page 25: Installing The Oven Into The Kitchen Cabinet
Installing the oven into the kitchen cabinet Positioning the appliance o Ensure that the aperture that you will be fitting the oven into is of the size given in the above diagram. -
Page 26: Ventilation Requirements
o The oven must be fitted into an oven housing with the ventilation cut-outs shown in the “Ventilation requirements” section on the next page. o Ensure that the rear panel of the furniture housing unit has been removed. Ventilation requirements (Figure shows the ventilation and cut-out requirements for the installation of the appliance into a standard kitchen unit). -
Page 27: My Appliance Isn't Working Correctly
(Figure shows the ventilation and cut-out requirements for the installation of the appliance into a tall housing unit). Ensure that the oven has been securely fixed into the housing unit. The fixing of the oven into the housing is made by using four screws. These should be screwed through the oven cabinet and into the housing unit. - Page 28 * Check that the operating instructions for putting the appliance into manual operation mode have been followed. o The grill function works but the main oven does not. * Check that you have selected the correct cooking function. o The grill and top oven element is not working, or cuts out for long periods of time during use.
- Page 29 * Use a covered container, where practical, when cooking to reduce the amount of condensation that forms. IMPORTANT: If your appliance appears not to be operating correctly, then you should disconnect it from your mains supply and then contact the Customer Care Department .
- Page 30 ICON80IX IM 20170725...
