- Page 1 Workshop Service Manual 9222VE Planter 9222 VE September 2018 North America 4283623M1 4205 River Green Parkway, Duluth GA 30096 USA © AGCO 2018 English...
- Page 2 CALIFORNIA Proposition 65 Warning WARNING: Diesel engine exhaust and some of its constituents are known to the State of California to cause cancer, birth defects, or other reproductive harm. WARNING: Battery posts, terminals and related accessories contain lead and lead compounds, chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm.
-
Page 3: Table Of Contents
Table of contents 9222VE Planter 1 General ..............1-1 . - Page 4 12 row marker cylinder ......... . . 3-17 9222VE Planter 4283623M1 Find manuals at https://best-manuals.com...
- Page 5 Examine the lighting ..........4-14 9222VE Planter 4283623M1 Find manuals at https://best-manuals.com...
- Page 6 ............6-22 9222VE Planter 4283623M1 Find manuals at https://best-manuals.com...
- Page 7 Remove the roller chains ....... . 7-18 9222VE Planter 4283623M1...
- Page 8 ..............Index-1 9222VE Planter 4283623M1 Find manuals at https://best-manuals.com...
-
Page 9: General
Hydraulic system specifications ........1-23 9222VE Planter 4283623M1 Find manuals at https://best-manuals.com... - Page 10 ........... . . 1-26 9222VE Planter 4283623M1 Find manuals at https://best-manuals.com...
-
Page 11: General Information
Use leak proof containers when draining fluids. Do not use food or beverage containers to collect waste fluids, as food or beverage container(s) may mislead someone into drinking from them. 9222VE Planter 4283623M1... - Page 12 Air conditioning refrigerants escaping into the air can damage the Earth's atmosphere. Government regulations may require a certified air conditioning service center to recover and recycle used air conditioning refrigerants. Inquire with local environmental or recycling center on the proper way to recycle or dispose waste. 9222VE Planter 4283623M1...
-
Page 13: Safety
Do not remove the safety signs. Replace safety signs that you cannot read, are damaged, or are missing. Clean the machine surface with a weak soap and water solution before you replace the safety signs. Replacement safety signs are available from your dealer. 9222VE Planter 4283623M1... -
Page 14: A Word To The Operator
'over the counter' drugs, get medical advice about the safe operation of machines. CAUTION: If attachments or implements used with this machine have a different operator manual, see that operator manual for other important safety instructions. 9222VE Planter 4283623M1... -
Page 15: The Service Manual
The tractor must have enough weight and braking capacity, especially when operating on roads and terrain that is not even. Use a tractor of recommended size and weight to tow the machine. GUID-E77631FB-0DC0-4637-9090-88018315176E-high.jpg [High] Fig. 4 9222VE Planter 4283623M1... -
Page 16: Personal Protective Equipment
Do not put on loose clothing, jewelry, watches, or other items that can tangle in parts that move. Tie up long hair that can also tangle in moving parts. GUID-1AEEBD1D-C71B-432C-9D23-52467D7C0BBF-high.jpg [High] Fig. 6 9222VE Planter 4283623M1... -
Page 17: Seat Instructions
Stop the machine before doing service to the machine. Do not operate the machine with the drive shaft shields open or removed. Keep away from the components that turn. GUID-CEB32148-1F4C-457C-ADF7-595DFC51AC25-high.jpg [High] Fig. 9 Make sure guards that turn are free. 9222VE Planter 4283623M1... -
Page 18: Exhaust Warning
Always read and follow all manufacturers instructions before you open chemical containers. Read and follow instructions each time you use a chemical. 1-10 9222VE Planter 4283623M1... -
Page 19: Travel On Public Roads
Install the marker lockup pins before transporting or parking the machine. Install the wheel cylinder lockup channels before transporting or parking the machine. Vertical fold models: Always install the wing lockup pins before transporting or parking the machine. 9222VE Planter 1-11 4283623M1... -
Page 20: Maintenance
Discs have sharp edges, be careful when you do work around the discs. Do not do the servicing, examine or adjust chains or belts while the engine is in operation. GUID-7D1C9640-D737-4F38-8886-F1D2280DF613-high.jpg [High] Fig. 15 1-12 9222VE Planter 4283623M1... -
Page 21: Fire Prevention And First Aid
Unusual noises can indicate a worn out component that can cause too much heat. If flame cutting, welding, arc welding, or grinding is to be done on the machine or attachments, clear 9222VE Planter 1-13 4283623M1... -
Page 22: High Pressure Leaks
Remove all pressure before you loosen hydraulic lines. Lower equipment in the up position, close the accumulator valve, and stop the engine. Tighten all connections before you apply pressure. GUID-9A83C5CD-95EC-445B-A3A7-1DCF8FACFE45-high.jpg [High] Fig. 21 1-14 9222VE Planter 4283623M1... -
Page 23: Tire Safety
The manufacturer will not accept responsibility for installation of unapproved parts and/or accessories and damages as a result of their usage. GUID-FA132350-A260-454E-8B83-2C8533C34BC4-high.jpg [High] Fig. 23 9222VE Planter 1-15 4283623M1... -
Page 24: Cylinder Stops
GUID-4BC91F48-787D-49E5-A107-B96B4EB2538B-high.jpg [High] Fig. 24 Install the wheel lift cylinder stops (1) in the storage position when not in operation. Install the pin through each wheel lift cylinder stop. GUID-E5C8EE23-9BDC-47A0-8824-FBEFD2260454-high.jpg [High] Fig. 25 1-16 9222VE Planter 4283623M1... -
Page 25: Transport Locks
The marker lockup valve (1) is in the closed position. GUID-6E3748E9-B8D5-4412-8314-0E5C3F8F31FA-high.jpg [High] Fig. 27 To operate markers, turn marker lockout valves to the operate (open) position. The marker lockup valve (1) is in the open position. GUID-DFAAD8A7-73CB-47F9-9D87-D0F795796705-high.jpg [High] Fig. 28 9222VE Planter 1-17 4283623M1... -
Page 26: Transport Pins
• Transport the machine • Service the machine • Fold the machine • Store the machine GUID-61B119E5-BBBE-4510-B229-9671B641FA79-high.jpg [High] Fig. 30 During field operation, store the top link (1) on the tongue hose cover. GUID-134DE67A-5495-4D3D-9D7D-CAAB48A45270-high.jpg [High] Fig. 31 1-18 9222VE Planter 4283623M1... -
Page 27: Machine Identification
GUID-A8D431C7-AF67-4D07-9A1D-EACD2D764C87-high.jpg [High] Fig. 32 GUID-8EAAEACD-2871-4FC9-AAFB-3C27FF39E5A3 [V4] 1.5.2 Serial number description Description of the serial number for model years 2017 and up. GUID-8D382D5F-9E99-42DE-A5BE-97EC9A41FFB6-high.jpg [High] Fig. 33 Beginning symbol Brand code World manufacturer code Model identifier (model number) 9222VE Planter 1-19 4283623M1... - Page 28 1. General Check letter (0 or used if model identifier is Plant code five digits) Family code Model year code (F=2015, G=2016, H=2017 , Unit number of the year and on) (10) End symbol 1-20 9222VE Planter 4283623M1...
-
Page 29: Main Machine Components
1. General GUID-DD7AED04-FB58-4B9F-947B-286780A3121F [V1] 1.6 Main machine components GUID-F6C568C4-CD51-4A10-9864-ABEB8E21BF92-high.jpg [High] Fig. 34 Hopper 200 gal tank Closing wheels Hitch Seed meter PDM module Row unit Vacuum Blower 9222VE Planter 1-21 4283623M1... -
Page 30: Specifications
9.1 m (30 ft) Overall operating width 5 m (16 ft 4 in) Transport width 3.1 m (10 ft 1 in) Transport height 5.5 m (18 ft) Overall length 3.9 m (12 ft 10 in) Hitch length 1-22 9222VE Planter 4283623M1... - Page 31 This as a preview PDF file from best-manuals.com Download full PDF manual at best-manuals.com...
