30 TON, 35 TON & 40 TON VERTICAL/HORIZONTAL LOG SPLITTER Operation Manual Model #s BWMLS30 (30 Ton), BWMLS35 (35 Ton), BWMLS40 (40 Ton) This safety symbol identifies important safety measures throughout this manual. Failure to follow this information may result in serious injury or death.
Contents SAFETY INFORMATION Intended use ��������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� Personal protective equipment ���������������������������������������������������������������������������������������������������������������������������������������������������������������������� Safety decals �������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� General safety ����������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� Preparation of the log ������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� Work area ���������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� Operation of the log splitter ������������������������������������������������������������������������������������������������������������������������������������������������������������������������������ Repairs and maintenance ��������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� Hydraulic safety �������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� Fire prevention ����������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� Towing safety ��������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������...
Safety Information WARNING: Read and understand the complete operation manual before assembling or using this product! Failure to comprehend and comply with warnings, cautions and instructions for assembly and operation could result in serious injury or death. WARNING DO NOT permit children to operate this equipment at any time� DO NOT permit others that have not read and understood the complete operation manual to operate this equipment�...
Safety Information SAFETY DECALS Make sure all safety warning decals are attached and in readable condition� Replace missing or defaced decals� Call 1300 454 585 for replacements� Pinch Point Decal Part # BWMLS187 Operator Zone Decal Part # BWMLS186 Hydraulic Fluid Decal Operation Decal Part # BWMLS188 Part # BWMLS185...
Safety Information GENERAL SAFETY Failure to follow warnings, cautions, assembly and operation instructions in the Operation Manual may result in serious injury or death. READ THE OPERATION MANUAL BEFORE USE DANGER DO NOT permit children to operate this equipment at any time� Do not permit ...
Safety Information OPERATION OF THE LOG SPLITTER Operate the log splitter from within the operation zone as shown in the diagrams below. The operator has the safest and most efficient access to the control valve and the beam in these locations� Failure to operate the log splitter in this position can result in serious injury or DANGER death.
Safety Information REPAIRS AND MAINTENANCE DO NOT operate the log splitter when it is in poor mechanical condition or in need of repair. Frequently check that all nuts, bolts, screws, hydraulic fittings and hose clamps are tight� DO NOT alter the log splitter in any manner� Any alteration will void the warranty ...
Safety Information FIRE PREVENTION DO NOT operate the log splitter near an open flame or spark. Hydraulic oil and fuel are flammable and can explode. DO NOT fill the fuel tank while the engine is hot or running. Allow the engine to ...
2 - Tank and Engine Assembly Step 1.1 Remove plastic wrap on crate. Step 1.2 Remove restraining bolts from the beam. Use a 13mm wrench / socket wrench to remove the two hex bolts that are securing the beam to the crate bottom (right).
Page 12
1 - Unpacking the Container Step 1.5 Use a 13mm wrench / socket wrench to remove the two hex bolts that secure the Briggs & Stratton engine to the crate bottom (right). Step 1.6 Remove tank and engine assembly from crate� REMOVE BOLTS�...
Page 13
2 - Tank and Engine Assembly Step 2.1 Remove engine bolts from tank. Step 2.2 Place engine on tank� Step 2.3 Secure engine on tank in 4 places with hex bolt (5), flat washer and locking hex nut (7). Step 2.4 Attach suction line tube to pump�...
Page 14
2 - Tank and Wheel Assembly Step 3.1 Remove disposable spindle covers and wheel bearing covers. Step 3.2 Slide wheel/tyre assembly on to the spindle with valve stem of tyre facing outwards� Step 3.3 Install the flat washer onto the spindle. Step 3.4 HUB CAP TOOL (7) IS Thread the slotted castle nut...
Page 15
3 - Tank and Tongue Assembly Step 4.1 Attach the tongue and stand assembly with hex bolt (3), to the tank and engine assembly flat washer (4), lock washer and hex nut in two places� Tighten securely using 19mm socket wrench.
Page 16
5 - Beam Bracket Assembly Step 5.1 Attach the beam lock bracket to the beam and cylinder assembly with hex bolt (4), flat washer (5), lock washer and hex nut in two places� Tighten securely using 19mm socket wrench. Step 5.2 Attach the pivot bracket to the beam and cylinder assembly...
6 - Beam and Tank Assembly Step 6.1 Rotate the jack stand attached to the side of the tongue assembly downwards into position by releasing the pin and then securing the release pin� Step 6.2 Remove the retaining clip and hitch pin from the assembled unit (below).
7 - Hydraulic Line Connection Step 7.1 Hold hydraulic hose above the level of the hydraulic tank to prevent fluid leakage and remove the end caps. Step 7.2 Apply Teflon tape or pipe sealant on to the hose fitting threads. Install the ends of the two hydraulic hoses to the valve (as shown in detail drawing below).
Page 19
8 - Log Catcher Installation Step 8.1 Rotate beam and cylinder assembly down from upright position and lock in place with the release pin� Step 8.2 Install the log catcher assembly with hex bolts (2), flat washer (3), lock washer (4), hex nut and button screw in two places�...
Operating Instructions WARNING: Read and understand the complete operation manual before assembling or using this product! Failure to comprehend and comply with warnings, cautions and instructions for assembly and operation could result in serious injury or death. DANGER DO NOT permit children to operate this equipment at any time� DO NOT permit others that have not read and understood the complete operation manual to operate this equipment�...
Operating Instructions STARTING INSTRUCTIONS NOTE: Refer to the engine owner’s manual for complete information on starting, maintenance and troubleshooting� 1� Move the fuel valve lever to the ON position� 2� To start a cold engine, move the choke lever to the CLOSE position� To restart a warm engine, leave the choke lever in the OPEN position�...
Operating Instructions Store manuals in the manual cannister attached to the tongue of the log splitter or file in a safe place for future reference. NOTE: For operation in wooded areas, obtain a spark arrestor for the exhaust system� See the engine operating and maintenance manual and check with your authorised service centre�...
Page 24
Tank Parts No. Part No. Description Qty. No. Part No. Description Qty. BWMLS150 Tank with decals (30 ton) 10 BWMLS156 Hydraulic oil filter BWMLS197 Tank with decals (35/40 ton) BWMLS119 Hex bolt, M8 x 1.25 x 45mm, G8.8 11 BWMLS157 Hose clamp, 15/16”...
Page 28
Please call our customer service team on 1300 454 585 for any warranty issues or repairs� Record the information below for future reference. Model No: Date of purchase: Serial No: Place of purchase: Specifications Part No. BWMLS30 BWMLS35 BWMLS40 Maximum splitting force 30 Tons 35 Tons 40 Tons Engine 6�5hp Briggs &...
