Xebex Fitness ABMG-3 Assembly Instructions & Owner's Manual

Xebex Fitness ABMG-3 Assembly Instructions & Owner's Manual

Air bike

Advertisement

Quick Links

A
SSEMBLY
:
I
MPORTANT
READ ALL ASSEMBLY INSTRUCTIONS AND SAFETY PRECAUTIONS BEFO RE USING THIS PRODUCT. REFERENCE ALL
SAFETY GUIDELINES AND WARNING LABELS. RETAIN PRODUCT LITERATURE FOR FUTURE REFERENCE.
S
:
A
FETY
PR
OPERLY WARM UP AND STRETCH BEFORE EXERCISING. IF YOU FEEL PAIN OR DIZZINESS AT ANY TIME WHILE
EXERCISING , STOP IMMEDIATELY AND CONSULT YOUR PHYSICIAN.
I
NSTRUCTIONS
AIR BIKE ABMG-3
/ O
M
WNERS
ANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the ABMG-3 and is the answer not in the manual?

Questions and answers

Summary of Contents for Xebex Fitness ABMG-3

  • Page 1 AIR BIKE ABMG-3 SSEMBLY NSTRUCTIONS WNERS ANUAL MPORTANT READ ALL ASSEMBLY INSTRUCTIONS AND SAFETY PRECAUTIONS BEFO RE USING THIS PRODUCT. REFERENCE ALL SAFETY GUIDELINES AND WARNING LABELS. RETAIN PRODUCT LITERATURE FOR FUTURE REFERENCE. FETY OPERLY WARM UP AND STRETCH BEFORE EXERCISING. IF YOU FEEL PAIN OR DIZZINESS AT ANY TIME WHILE...
  • Page 2 SSEMBLY NTRO SSEMBLY REPARATION SSEMBLY REPARATION To ensure ease of product assembly, please take time to verify the size and quantities of all required assembly hardware. Use the itemized parts listing and hardware chart for reference. The product assembly process has been documented in easy to follow stages. Please read all assembly instructions carefully.
  • Page 3 SSEMBLY ARTS ISTING SSEMBLY ARTS ISTING ITEM# DESCRIPTION Q'TY BASE FRAME ASSEMBLY FRONT STABILIZER ASSEMBLY REAR FRONT STABILIZER ASSEMBLY SENSOR CABLE CONSOLE CONSOLE MAST ADJUSTABLE SEAT SLIDER SEAT POST SEAT SEAT SLIDER ADJUSTABLE KNOB CONNECTING ARM (PREINSTALLED) LEFT PIVOT ARM ASSEMBLY RIGHT PIVOT ARM ASSEMBLY FOOT REST LEFT PEDAL...
  • Page 4 XPLODED Assembly Parts NOTE NOTE : THE EXPLODED PARTS VIEW IS SHOWN FOR REFERENCE ONLY. SOME ITEMS MAY BE PREASSEMBLED. : THE EXPLODED PARTS VIEW IS SHOWN FOR REFERENCE ONLY. SOME ITEMS MAY BE PREASSEMBLED. PLEASE REFER TO THE INDIVIDUAL ASSEMBLY STAGE INSTRUCTIONS FOR DETAILED PARTS ORIENTATION. PLEASE REFER TO THE INDIVIDUAL ASSEMBLY STAGE INSTRUCTIONS FOR DETAILED PARTS ORIENTATION.
  • Page 5 SSEMBLY NSTRUCTION SSEMBLY TAGE Attach Stabilizers to the Main Base Assembly Hardware Required: Button Head Allen Bolt Qty. 4 Washer Qty. 4 Spring Washer Qty. 4 Assembly Description: A) Assemble the Front Stabilizer Assembly (#2) to the Main Base Assembly (#1) using 2-Button Head Allen Bolt (#22), 2-Spring Washers (#23), and 2-Washers (#24).
  • Page 6 SSEMBLY NSTRUCTION SSEMBLY STAGE Attach Console Mast & Mount Computer on the Main Base Assembly Hardware Required: Button Head Allen Bolt Qty. 2 Spring Washer Qty. 2 Washer Qty. 2 Assembly Description: A) Slide the Computer Mast (#6) onto the corresponding mounting area of the Base Frame Assembly. Secure the mast to the base frame using 2-Button Head Allen Bolts (#22), 2-Spring Washers (#23) ,and 2-Washers (#24).
  • Page 7 SSEMBLY NSTRUCTION SSEMBLY TAGE Attach Seat Slider and Seat to Main Base Assembly Assembly Hardware Required: (*Assembly hardware may be pre-installed) Flat Washer * Qty. 3 Nylon Nut M8 * Qty. 3 Assembly Description: A) Insert the Adjustable Seat Slider (#7) into the u-channel of the Seat Support Post (#8). Secure the seat slider assembly in place using the 1-Seat Adjustment Knob (#10).
  • Page 8 SSEMBLY NSTRUCTION SSEMBLY STAGE Attach Pivot Arms to the Main Base Assembly Hardware Required: Flat Washer Qty. 2 Pivot Bolt M8 Qty. 2 Nylon Nut M8 Qty. 2 Assembly Description: A) Install the Pivot Arms (#16 & #17) by threading the (preinstalled) pivot shaft into the corresponding pivot-boss of the Base Frame Assembly (#1).
  • Page 9 SSEMBLY NSTRUCTION SSEMBLY STAGE Attach Pedals & Foot Rest to the Main Base Assembly Assembly Description: Assembly Note: The right and left pedals are appropriately marked (R) and (L). The threading orientation on the left pedal is reversed from the threading orientation on the right pedal. To avoid stripping of the threads on the pedals or crank arms, make sure to follow the proper assembly orientation.
  • Page 10: Basic Troubleshooting Tips

    ROUBLESHOOTING BASIC TROUBLESHOOTING TIPS BASIC TROUBLESHOOTING TIPS PROBLEM DESCRIPTION SUGGESTED SOLUTION NO DISPLAY CHECK BATTERY ORIENTATION: + / - CHECK BATTERY VOLTAGE: (2) AA BATTERIES 1.5 VOLTS EACH CHECK CABLE CONNECTIONS: MAKE SURE CONNECTIONS ARE SECURE AND IN THE CORRECT ORIENTATION. CHECK CABLE ASSEMBLIES FOR DAMAGE: PINCH POINTS &...
  • Page 11: Maintenance

    REVENTATIVE AINTENANCE QUIPMENT AINTENANCE QUIPMENT AINTENANCE Use a dampened soft-cloth to wipe equipment free of perspiration after each use. Avoid getting excessive moisture on computer or electronic components. Do not use abrasive cleaners or petroleum-based solvents to clean equipment. Do not remove drive train shrouds or attempt any technical service on equipment without consulting an authorized service representative.
  • Page 12 XEBEX AIR BIKE Maintenance Information Service Daily Monthly Quarterly Annually Clean/Dry Frame & Console w/ mild soap and cloth Inspect Unit for Noise or loose components Ensure Unit is level-Adjust Stabilizer Feet Tighten Crank & Bell Crank Bolts, Tighten Pedals Tighten Seat Bolts Tighten Handlebars Check and Tighten Linkage Arm Pivot points...
  • Page 13 XEBEX AIR BIKE Maintenance Information 4. Linkage Arm Check (Monthly): Tighten the linkage bolts and nuts using a 6mm Allen wrench and 13mm wrench. Tighten these parts snug, but do not over tighten or keep tightening. Note: There will be little play in these linkages after tightening, but this is normal.
  • Page 15 Part List PART DESCRIPTION PART# PART DESCRIPTION PART# LEFT CHAINGUARD FRAME FRONT STABILIZER SPOKE PROTECTOR LEFT REAR STABILIZER WHEEL CAGE RIGHT SENSOR CABLE WHEEL CAGE LEFT 46T SPROCKET COMPUTER HEX BOLT M5*10L COMPUTER POST CRANK BOLT SEAT TRACK SENSOR STOPPER SEAT POST SCREW M4*16L SEAT...
