ASSEMBLY PREPARATION To ensure ease of product assembly, please take time to verify the size and quantities of all required assembly hard- ware. Use the itemized parts listing and hardware chart for reference. The product assembly process has been documented in easy to follow steps. Please read all assembly instructions carefully.
Page 3
AS-Main Frame Set DS-Front Stabilizer Set CS-Rear Stabilizer Set GS-Console Set E-Handle Bar...
Page 4
G2-Right Pedal G1-Left Pedal J7-Console Pivot Bushing J9-Nut Cap J2-Bolt M10 x 55mm J8-Hex Head Screw J4-Nut J3-Flat Washer J5-Flat Washer J6-Flat Washer...
Page 5
Step 1. Use the 6mm Allen wrench to remove 2x Bolts M8x12mm (B1) and disassemble the Packaging Tube (B) from the Main Frame Set (AS). The Packaging Tube (B) is used for packaging purposes only and won’t be needed again during/after the assembly. Step 2.
Page 6
Step 3. Slightly loosen the Knob (A11) and then insert the Handlebar (E) to the Main Frame Set-(AS). Secure the Console Set(GS) onto the Handle Bar (E) with 1x Hex Head Screw (J8), 2x Flat Washer (J6), 2x Flat Washer (J5), 1x Nut (J4) and 2x Console Pivot Bushing (J7). Finally, put on2x Nut Cap (J9).
Page 7
Step 5. Press the Lever (A14) and pull upwards the seat post to desired height.
PARTS LIST NAME CIFICATION Q'TY NAME SPECIFICATION Q'TY Main Frame Spring Washer Retractable Sleeve Screw M5×10mm Square Inner Sleeve-L Aluminum Sleeve Square Inner Sleeve-R Magnet Base Double-Head Screw Φ8×65mm Ring Magnet Aluminum Plate Round Steel Rod Φ6×50mm Screw M4×25mm Screw M6×8mm Flywheel Shaft Screw...
Page 10
PARTS LIST NAME SPECIFICATION Q'TY NAME SPECIFICATION Q'TY Idler Pulley Shaft Φ10×30mm Magnet Base Φ10×50mm Screw M8×40mm Idler Pulley Sleeve Spring Washer Clip Flat Washer Φ10×2T×Φ20 Screw Φ10×1T×Φ20 Flat Washer Screw M4×8mm Bearing 6300 Powder metallurgy Drive Belt Disc-PJ Φ180 Magnet Φ5×3T Drive Belt Pulley-PJ...
