MANUAL AND DOCUMENTATION
GUANDALINI
PPK
ASSEMBLY MANUAL FOR KIT PPK ON
DJI MAVIC 2 PRO
São Paulo, 03rd March, 2021
Revisão nº 4
Manual developed by Guandalini Equipamentos Topográficos Technical Team

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PPK and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GUANDALINI PPK

Summary of Contents for GUANDALINI PPK

  • Page 1 MANUAL AND DOCUMENTATION GUANDALINI ASSEMBLY MANUAL FOR KIT PPK ON DJI MAVIC 2 PRO São Paulo, 03rd March, 2021 Revisão nº 4 Manual developed by Guandalini Equipamentos Topográficos Technical Team...

  • Page 2: Table Of Contents

    2.2.1. CHARGER IMAX B3 ..................7 2.2.2. AC/DC ADAPTER CHARGER ............... 10 2.3. HOW TO MEASURE THE BATTERY CHARGE OF THE PPK KIT ......11 2.3.1. LIPO BATTERY METER ................11 CONFIGURATION DJI GO ..................14 FLIGHT PROCEDURES ....................17 4.1.

  • Page 3: Kit Ppk

    The PPK kit is developed by the engineering team at Guandalini Equipamentos Topograficos and can be integrated into your MAVIC 2 PRO. The kit consists of the Reach M + card, an adapted GNSS antenna and the Guandalini PPK software (Figure 1). Figure 1 - Guandalini PPK Kit In Figure 2, observe the result of the flight with a height of 80m.

  • Page 4: Assembling The Kit Ppk On Mavic 2 Pro

    2. ASSEMBLING THE KIT PPK ON MAVIC 2 PRO 2.1. DRONE MOUNTING 2.1.1. STEP 1 With the KIT PPK GUANDALINI in hands, remove the control module from the foam cradle, shown in Figure 3. Figure 3 – Control Module Guandalini PPK. 2.1.2. STEP 2 Insert the part with the light sensor into the front right leg of your MAVIC 2 PRO.

  • Page 5: Step 3

    ASSEMBLY MANUAL FOR KIT PPK ON DJI MAVIC 2 PRO Figure 4 – Insert the light sensor Figure 5 - Positioning of the light sensor on the drone 2.1.3. STEP 3 Position the control module on the top of the drone, paying attention to the light sensor cable that goes behind the MAVIC 2 PRO's right arm.

  • Page 6: Step 4

    ASSEMBLY MANUAL FOR KIT PPK ON DJI MAVIC 2 PRO Figure 6 - Indication of the positioning of the control module on MAVIC 2 PRO. Figure 7 – Light sensor cable guide 2.1.4. STEP 4 Remove the battery from the foam cradle and place it in the control module with the cables to the left.

  • Page 7: How To Charge Battery From The Ppk Kit

    Figure 8 - Positioning the battery on the control module. Figure 9 - Equipment ready for flight. 2.2. HOW TO CHARGE BATTERY FROM THE PPK KIT 2.2.1. CHARGER IMAX B3 For battery recharge, a charger is included (Figure 10Figure 10).
  • Page 8 ASSEMBLY MANUAL FOR KIT PPK ON DJI MAVIC 2 PRO Figure 10 - Charger included with the PPK Kit ATTENTION!!! 1. Remove the battery from the charging procedure kit; 2. The charger must only be connected to the outlet if the battery is connected;...
  • Page 9 ASSEMBLY MANUAL FOR KIT PPK ON DJI MAVIC 2 PRO 1. Connect the battery to the charger (Figure 11) 2. Connect the charger to the power plug Figure 11 - Connecting the battery to the charger. When connecting the battery to the charger, the ‘cell 1’ and ‘cell 2’ lights will light red and the ‘cell 3’...

  • Page 10: Ac/Dc Adapter Charger

    DJI MAVIC 2 PRO 2.2.2. AC/DC ADAPTER CHARGER The new kits PPK are shipped with this battery charger (Figure 13). Figure 13 - AC/DC adapter charger. This charger has a status LED. When the battery is being charged, the LED lights red;...

  • Page 11: How To Measure The Battery Charge Of The Ppk Kit

    ASSEMBLY MANUAL FOR KIT PPK ON DJI MAVIC 2 PRO 2.3. HOW TO MEASURE THE BATTERY CHARGE OF THE PPK Figure 15 - Battery life graph and LED colors. The battery level is indicated by the color of the LED located above the control module.
  • Page 12 ASSEMBLY MANUAL FOR KIT PPK ON DJI MAVIC 2 PRO This meter displays the total battery voltage (Figure 17) and the voltage in each cell (Figure 18 and Figure 19). To identify which voltage the display will show: 'ALL' (Figure 17 A) for the battery voltage, ‘-1-‘...
  • Page 13 ASSEMBLY MANUAL FOR KIT PPK ON DJI MAVIC 2 PRO Figure 19 - A) Cell voltage indicator; B) Cell voltage 2 The Table 1 shows the relationship between voltage and battery charge percentage. VOLTAGE (V) BATTERY CHARGE (%) 100% Table 1 – Relationship between voltage and battery charge Av.

  • Page 14: Configuration Dji Go

    ASSEMBLY MANUAL FOR KIT PPK ON DJI MAVIC 2 PRO 3. CONFIGURATION DJI GO For the correct operation of the PPK Kit developed by Guandalini, two configurations are required on the DJI GO 4. Download the DJI GO 4 app (Figure 20).
  • Page 15 ASSEMBLY MANUAL FOR KIT PPK ON DJI MAVIC 2 PRO Figure 23 - Advanced Settings Figure 24 - Advanced Settings – “Turn on Head LEDs” It is now necessary to enable the setting so that the LEDs will automatically turn off when capturing photos.
  • Page 16 ASSEMBLY MANUAL FOR KIT PPK ON DJI MAVIC 2 PRO Figure 25 - DJI GO 4 Screen Figure 26 - Camera Settings Figure 27 - Advanced Camera Settings Av. Paulo VI, 2140 (new n 372) • Sumaré • CEP 01262-010 • São Paulo • SP...

  • Page 17: Flight Procedures

    If the drone is positioned 500 meters from the base, it must be at least 10 minutes with the PPK kit on before taking off. It is important that the takeoff is made from a point of known coordinates and that this point is visible to be used as a control.

  • Page 18: How To Connect The Control Module

    ASSEMBLY MANUAL FOR KIT PPK ON DJI MAVIC 2 PRO Figure 28 - Drone positioned with the optical center of the camera in the center of the control point. 4.3. HOW TO CONNECT THE CONTROL MODULE First, it is necessary to place the battery in the control module and secure it as shown in the Figure 29.

  • Page 19: Initializing The System

    ASSEMBLY MANUAL FOR KIT PPK ON DJI MAVIC 2 PRO Figure 29 - A) Place to put the battery; B) Proper allocation of the battery on the control module The Figure 30 shows the battery power cable connected to the control module.
  • Page 20 ASSEMBLY MANUAL FOR KIT PPK ON DJI MAVIC 2 PRO Figure 31 - Boot Status LED After 4 minutes of equipment initialization, the LED will flash for 1 minute. It is suggested that at this time connect the drone, so that it marks the home point. When the LED goes out, start the flight.

  • Page 21: Shutting Down The System

    ASSEMBLY MANUAL FOR KIT PPK ON DJI MAVIC 2 PRO When connecting the drone or changing batteries, approach as shown in the Figure 33. Figure 33 - Correct way to approach the drone during a boot 4.5. SHUTTING DOWN THE SYSTEM To turn off the Reach M + after the flight, disconnect the plug as shown in the Figure 34.
