- Page 1 PPK KIT FOR DJI DRONES Av. Paulo VI, 184, Sala 01 • Sumaré • CEP 01262-010 • São Paulo, SP • Brazil +55 11 4800-3157 • www.guandalinibr.com...
- Page 2 PPK SOLUTION • Up to 3cm in XYZ • No/less GCP > saves countless hours and labor costs...
- Page 3 BATTERY • Our PPK solution has your own battery • Mean consumption of PPK: 200mA • LiPo 2S 700mah 25C battery • +2 hours • Keep our PPK kit on while changing your drone battery!
- Page 4 PLAN AND FLY WITH YOUR FAVORITE APP...
-
Page 5: How It Works
HOW IT WORKS? DRONE WITH PPK REFERENCE LOGGING STATION RAW DATA NOTHING IN REAL TIME! -
Page 6: After Flight
AFTER FLIGHT Download recorded data RAW DATA... - Page 7 PPK1 AT YOUR COMPANNY YOUR SOLUTION Reach M+ PPK for drone with GNSS antenna PPK solution for you/customer Software for geotag...
- Page 8 PPK2 AT YOUR COMPANNY YOUR SOLUTION Reach M2 PPK for drone PPK solution for you/customer Multi-band GNSS antenna Software for geotag...
- Page 9 KIT PPK1: compatible drones MAVIC 2 PRO MATRICE 200 & 210 PHANTOM 4 ADV&PRO • NOT INCLUDED • Emlid Reach M+ • DJI drones...
- Page 10 KIT PPK2: compatible drones MAVIC 2 PRO MATRICE 200 & 210 PHANTOM 4 ADV&PRO • NOT INCLUDED • Emlid Reach M2 • Multi-band GNSS antena • DJI drones...
- Page 11 HOW TO GET READY TO USE • STEP 1: Buy Guandalini PPK kit • STEP 2: Buy Emlid itens for your PPK kit • STEP 3: Mount Emlid itens on your PPK kit • You can do it by yourself following our step by step •...
- Page 12 STEP 1: Buy Guandalini PPK kit • Mail our sales team on: gppk@guandalinibr.com You can have more info by: • Accessing our website on International PPK kits: www.guandalinibr.com/produtos_subcategoria.cfm?id=83...
- Page 13 STEP 2: Buy Emlid itens for your PPK kit • Access Emlid store: www.emlid.com • Choose your product • Reach M+ • Reach M2 and Multi-band GNSS antena...
- Page 14 STEP 3: Mount Emlid itens on your PPK kit REMOVE REACH FROM CASE ADESIVE TAPE ON REACH ALUMINIUM TAPE ON REACH REMOVE 4 SCREWS TO OPEN PPK BOX PHANTOM 4 ADV&PRO MATRICE MAVIC 2 PRO PUT REACH INTO PPK BOX AND TIGHT SCREWS...
- Page 15 STEP 4: Mount PPK kit on your drone DRONE DRONE WITH PPK...
- Page 16 GUANDALINI PPK SOFTWARE: inputs • PPK model • Coordinate system • Base file • Base cordinates • Drone file • Images...
- Page 17 GUANDALINI PPK SOFTWARE: outputs 1. TAKE-OFF COORDINATE POINT 2. GOOGLE EARTH VIEW Image position 3b. IMAGE 3a. GEOTAG Adjusted Images coordinates coordinates UTM, GEOGRÁFICA, LOCAL...
- Page 18 IMAGES PROCESSING OPTION 1: load image w/ adjusted coordinates...
- Page 19 IMAGES PROCESSING OPTION 2: load original image + geotag LOAD IMAGENS LOAD GEOTAG Approximated coordinates Adjusted coordinates...
-
Page 20: Image Processing
IMAGE PROCESSING how? Third party softwares (AGISOFT, PIX4D, etc) LOAD IMAGES Approximated coordinates IMAGES LOAD GEOTAG Adjusted coordinates Adjusted coordinates IMAGES GCP TAKE-OFF Adjusted coordinates GOOD ACCURACY IN DTM/DSM... - Page 21 KIT PPK1 + PHANTOM 4 ADV & PRO...
- Page 22 KIT PPK2 + PHANTOM 4 ADV & PRO...
- Page 23 KIT PPK1 + MAVIC 2 PRO...
- Page 24 KIT PPK2 + MAVIC 2 PRO...
- Page 25 KIT PPK1 + MATRICE 200 & 210...
- Page 26 KIT PPK2 + MATRICE 200 & 210...
- Page 27 Any question? Please fell free to contact us! E-mail: gppk@guandalinibr.com Site: www.guandalinibr.com Phone: +55 11 4800 3157 Whatsapp: +55 11 93358 5080...
