Summary of Contents for Brickcom OB-200Np-S
- Page 1 Megapixel Network Camera Easy Installation Guide OB-200Np-S...
-
Page 2: Safety Instruction
Preface Thank you for purchasing our product. If there are any questions, or requests, please do not hesitate to contact Every effort has been made to ensure the accuracy and validity of this Guide. Any update of this Guide is subject to change without notice. -
Page 3: Installation Steps
Installation Steps [Note]: The installation surface must be thick enough and can bear weight at least 8 times of the camera and the bracket. Models with brackets support ceiling mount and wall mount. Please get the accessories ready before installation. 55.6 4-¢5.0 66.9... - Page 4 2. Connect cables and power on. Different sub models have different connector interface. Take the model with the most connectors as example, and the tag meanings are explained in the picture: RS-485 Port Connect to surveillance keyboard or alarm expander Connect cables as indicated ALARM OUT Cut off terminal and connect...
- Page 5 2. Device Activation When using the device for the first time, run IPCSearch: it will search devices in LAN automatically and display the list of device IP address, gateway and etc. If the network provides DHCP service, DHCP server will assign IP for the camera automatically. ·...
- Page 6 3. Modify device IP address Click “Modify Params” and set the network parameters. When configuring a static IP for the camera, please check “Custom device address (Close DHCP)” and fill the Ethernet parameter. During the modification, the user name (admin) and the password set before activation should be entered. After configuration, the camera will reboot automatically.
- Page 7 2) After login, download and install the plug-in. Close browser during installation. 3) Re-login to the web client and view live video directly. [Note]: Interface of different models may differ. Please subject it to the actual product. Please refer to the Help file for detailed explanation.
- Page 8 Appendix Cable Identification Group Remarks Color White/Green RS-485 Serial Port A RS485_A Group RS-485 Serial Port B RS485_B White/Yellow ALARM_OUT 1A Alarm Output 1, regardless White/Orange of positive and negative ALARM_OUT 1B White/Brown Alarm Input Grounding White/Red ALARM_IN_GND White/Black Alarm Input 1 ALARM_IN 1 Light Green Audio Grounding...
- Page 9 V5 20190716...
