- Page 1 Megapixel Network Camera Easy Installation Guide OSD-200Np-S 30X...
-
Page 2: Safety Instruction
I. Preface These instructions are intended to ensure that the user can use the product correctly to avoid danger or property loss. Please read this Guide carefully before using the product, and keep it properly for future reference. If the product cannot work normally or is damaged because the user does not follow the safety instructions, we shall not assume any responsibility. - Page 3 Working Environment Voltage AC24V±10% / Hi-PoE Condition Waterproof, lightning protection, anti-interference Temp. -40℃~70℃ Humidity 10%~95% (Relative, non-condensing) -60m ~ 3000m Altitude Pressure 86kPa ~ 106kPa Daily Maintenance Do not touch the heat component of the device directly to avoid empyrosis. When the lens is contaminated by dust or grease, use cotton cloth or lens clean cloth to wipe it off.
- Page 4 Accessing this device to the internet is at user's own risk, including but not limited to the possible network attack, hacker attack, virus infection and etc. This company will not assume any responsibility for problems of product abnormality and information disclosure caused thereof. We shall provide technical support relating to the products in time.
- Page 5 Components Component Component Component Tail Wire Lens Film Safety Hook Adaptor Dome Housing Hanger Straight Side of D IR Light Buckled Lid Lens IR Light Film Wire Interface AC IN 100~240V 50/60Hz Rubber ring Switch Client [Note]: Power supply of the camera is either PoE or AC24V.
- Page 6 Table 1 Wiring Interface Port Name Function Network port Connect to PoE/DATA port of PSE box ACDC Power_PSE PoE/DATA port to camera, DATA/IN to switch, AC/IN port to power Power supply (AC24V1, red) negative Connect to power supply of AC 24V, regardless of positive and Power supply (PGND, yellow/green) Grounding wire, connect it to reliable grounding point Power supply (AC24V2, black)
- Page 7 IV. AC 24V ire Diameter VS. Transmission Distance The recommended max transmission distance when the wire diameter is certain and the AC 24V voltage loss rate is less than 10% (For devices powered by alternative current, the max allowed voltage loss rate is 10%. For example, the rated power of a device is 100VA and it is installed 28 inch (8m) away from the transformer, the required minimum wire diameter is 0.8000mm.) Distance...
- Page 8 V. Safety Examination Before installation, examine the mounting intensity of the wall surface or ceiling. The thickness of the wall or ceiling can support installing expansion screws. The wall or ceiling can bear the weight as heavy as 8 times of the total weight of the dome camera and the accessories such as the bracket (net weight of dome camera: 4.3 KG).
- Page 9 ½ Base of Bracket Body of Bracket Installation Sticker 1) Paste the installation sticker onto the wall and drill holes according to the 4 hole marks on the sticker for φ12 expansion screws (hole depth ≥70mm). If routing cables from the top, a cable outlet hole is needed on the wall. If routing cables from the side of the device, no need to drill a outlet hole but lead the cables through the U-shaped groove at the side of the base.
- Page 10 4) Fix bracket. Make the holes on the bracket go through the expansion screw bolts on the wall. Put the spacers onto the expansion screw bolts and tighten the nuts. ②Put the spacers onto the expansion ①Insert the expansion screw bolts screw bolts, tighten the nuts and fix into the holes on the bracket and the bracket...
- Page 11 ② Rotate camera by 180° in pan ③ Tighten the anti-off screws ① Align the straight side of D-shaped head of camera to the yellow label on the connector, then push the head till the end of connector Pendent Bracket Mount ①Pendent bracket is for indoor use and usually not used outdoor.
- Page 12 ①Draw holes ②Drill holes and insert ③Fix expansion screw bolts expansion screw bolts and and take down nuts and spacers Cable outlet 2) Route cables according to conditions at the scene, from top or side, and fix the bracket. ④Route cables from top or side ⑤Make the holes on the bracket base go through the expansion screws.
- Page 13 For installation of dome camera and cable connection, refer to Step 6 to 8 of Wall Bracket Mount. Other Mount Method Apart from wall bracket mount and pendent bracket mount, there are other methods such as corner bracket mount and pole bracket mount for installing the dome camera. Their installation steps are shown below (if there is a bracket adaptor, refer to Step 5 of Wall Bracket Mount).
- Page 14 VII. Login to Client 1. Minimum environment requirements: Processor: 3.3 GHz CORE®i2 series or other equivalent processors Ÿ RAM Memory: 4GB or above Ÿ Operating System: Windows XP or newer version Ÿ Browser: IE7.0 and newer version, Firefox, Google Chrome (41 and lower) Ÿ...
- Page 15 3. Modify device IP address Click “Modify Params” and set the network parameters. When configuring a static IP for the camera, please check “Custom device address (Close DHCP)” and fill the Ethernet parameter. During the modification, the user name (admin) and the password set before activation should be entered. After configuration, the camera will reboot automatically.
- Page 16 2) After login, download and install the plug-in. Close browser during installation. 3) Re-login to the web client and view live video directly. [Note]: Interface of different models may differ. Please subject it to the actual product. Please refer to the Help file for detailed explanation.
- Page 17 Appendix: Anti-static, Anti-interference, Anti-thunder, Anti-surge The camera should be grounded, or ESD may damage the electrical parts. In thunder and lightning area, camera should be grounded nearby to release the heavy energy of thunder strike so as to prevent camera from damage. In area with unstable voltage, camera should be grounded to release the heavy energy of electrical surge so as to prevent power source from burning.
- Page 18 Power Cord Earth Lead Resistance≤4Ω Metal Pole PVC Pipe Underground 1.5 m Metal Pole Grounding (without lightning rod) Power Arrester Lightning Rod Signal Arrester Video Arrester 45° The dome camera must be installed within the 45° angle range under the lightning rod Earth Lead Resistance≤4Ω...
- Page 19 V2 20190716...
