- Page 1 D.I.Y L.E.D CUBE 4X4X4 Level: Intermediate AK-125...
- Page 2 TABLE OF CONTENTS Parts List ..............................2 Soldering Guide (Part A) ..........................3 Soldering Guide (Part B) ........................... 5 Soldering Guide Without Recommend Products ..................8 Appendix ..............................9 PARTS LIST Please make sure that the following pieces are included in your kit Components PCB Reference Number Quantity...
- Page 3 SOLDERING GUIDE (PART A) 1. Turn on the soldering iron to 360º F - 370º F (182º C - 188º C) using Tin-Lead 60/40 solder. 2. Flip the board on its bottom side and then place the IC socket on the board where the white rectangle marked U10 can be seen.
- Page 4 SOLDERING GUIDE (PART B) There are two methods that can be used to solder the LED Arrays together; The recommended one will be shown as it is an easier way of ensuring a proper arrangement of the LED arrays in a cube shape. Recommended Method: 1.
- Page 5 Figure 2: The soldering of the LED pins (middle to middle – outers to outers) 5. Once the outer pins on one side are connected to each other, turn the whole structure to the right and begin soldering the outer pins on the other side. Once finished, you should get a solid structure just like the one in Figure 3.
- Page 6 6. Repeat the same steps as before in order to create three more columns. 7. Now, begin soldering four rows of LEDs on the PCB where the following reference numbers are printed: (P03, P33), (P07, P37), (P02, P32), (P06, P36), (P01, P31), (P05, P35), (P00, P27, P30),...
- Page 7 9. Now, begin soldering the outer pins of the bottom row of the LED columns to the outer pins of the LEDs that are already soldered on the board. 10. Now, the non-soldered middle pins of each column of LED must be soldered to the non- soldered middle pins of their neighboring column, two by two just like a bridge.
- Page 8 The lead under the negative sign is the negative lead and it must be inserted in the board with the white shaded region. You can download the manual from abra-electronics.com and search for AK-125. Vous pouvez télécharger le Manuel sur abra-electronics.com et cherchez pour AK-125.
