LS700-4KP
DLP Projector
User Guide
IMPORTANT: Please read this User Guide to obtain important information on installing
and using your product in a safe manner, as well as registering your product for future
service. Warranty information contained in this User Guide will describe your limited
coverage from ViewSonic Corporation, which is also found on our web site at http://
www.viewsonic.com in English, or in specific languages using the Regional selection
box in the upper right corner of our website. "Antes de operar su equipo lea cu
idadosamente las instrucciones en este manual"
Model No. VS17455

Advertisement

Table of Contents
loading

Related Manuals for ViewSonic LS700-4KP

Summary of Contents for ViewSonic LS700-4KP

  • Page 1 Warranty information contained in this User Guide will describe your limited coverage from ViewSonic Corporation, which is also found on our web site at http:// www.viewsonic.com in English, or in specific languages using the Regional selection box in the upper right corner of our website.
  • Page 2 Compliance Information FCC Statement This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 3 Important Safety Instructions Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this unit near water. Clean with a soft, dry cloth. Do not block any ventilation openings. Install the unit in accordance with the manufacturer’s instructions.
  • Page 4 Declaration of RoHS2 Compliance This product has been designed and manufactured in compliance with Directive 2011/65/EU of the European Parliament and the Council on restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS2 Directive) and is deemed to comply with the maximum concentration values issued by the European Technical Adaptation Committee (TAC) as shown below: Substance Proposed Maximum...
  • Page 5 PS/2, VGA and XGA are registered trademarks of International Business Machines Corporation. Disclaimer: ViewSonic Corporation shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from furnishing this material, or the performance or use of this product.

  • Page 6: Table Of Contents

    Table of Contents Key safety instructions ..1 Perform keystone correction....29 Using the CEC function ......30 Introduction ....... 3 Smart energy-saving ....... 30 Light Source Mode ........31 Projector features ........3 Operations at high altitudes ..... 31 Shipping contents ........
  • Page 7 Copyright information ..62 Copyright ..........62 Disclaimer ..........62 Appendix ......63 IR control table ........63 Address Code .......... 64 RS232 command table ......65...

  • Page 8: Key Safety Instructions

    Key safety instructions Design and testing of your projector have been carried out in compliance with the latest safety standards for information technology (IT) devices. However, it is extremely important for you to follow the instructions provided in this manual and product labels during use to ensure user safety.
  • Page 9 ● Do not block the ventilation holes. If the ventilation holes are seriously obstructed, overheating inside the projector may result in a fire. - Do not place this projector on a blanket, bedding or any other soft surface. - Do not cover this projector with a cloth or any other item. - Do not place flammable items near the projector.

  • Page 10: Introduction

    Introduction Projector features The projector integrates high-performance optical engine projection and a user-friendly design to deliver high reliability and ease of use. The projector offers the following features: ● The color mode provides different options designed for different projectors. ● Compatible with NTSC, PAL, SECAM and HDTV ●...

  • Page 11: Shipping Contents

    Shipping contents Carefully unpack the product and check that you have all of the items shown below. If any of these items are missing, please contact your place of purchase. Standard accessories The supplied accessories will be suitable for your region, and may differ from those illustrated. Projector Power cord VGA cable...

  • Page 12: External Appearance Of The Projector

    External appearance of the projector Front/Rear Side Top/Bottom Warning ● This equipment must be grounded. ● You may add power interruption devices in the fixed wiring or plug in the power cable to a nearby socket for convenience. If failures or errors occur during equipment operations, use the power interruption device to cut the power or unplug the power cable from the socket.

  • Page 13: Device Control And Functions

    Device control and functions Projector Turn the projector power on or off. (Power LED indicator) Please refer to “LED Indicator”. (TEMP LED indicator) Please refer to “LED Indicator”. (LAMP LED indicator) Please refer to “LED Indicator”. Menu/Exit Menu: Displays or exits the on-screen display menu. Exit: Returns to the previous OSD menu, exits and saves the menu settings.
  • Page 14 Remote control 9. 10. Left/Right/ Turn the projector on. Displays the projector’s internal information. Off Turn the projector off. 11. Enter COMP Enter the selected screen to display Select the D-Sub / component display. (OSD) menu item. HDMI 2 13. Setting Select the source of the displayed Open Menu.
  • Page 15 (Mute) 26. Standard Toggles the projector audio between on Standard mode. and off. 27. Sports (Volume) Sports mode. Decrease the volume. 28. User 1 (Volume+) User mode 1. Increase the volume. 29. Movie 23. Contrast Movie mode. Adjust contrast. 30. Eco Mode 24.
  • Page 16 Remote control effective range There are infra-red (IR) remote control sensors located at the front and back of the projector. Hold the remote control and maintain a perpendicular angle within 30 degrees with the IR remote control sensor to achieve normal remote control functions. The distance between the remote control and the sensor should not exceed 8 meters (about 26 feet).
  • Page 17 Replacing the remote control battery To open the battery cover, place the remote control with the backside facing upwards. Press down at the indicated area and then pull the battery lid upwards along the indicated direction. Take out the old batteries (if required) and then place 2 AAA batteries according to the indicated orientation.

  • Page 18: Projector Positioning

    Projector Positioning Choosing a location You may refer to the room layout or personal preference to determine the location of installation. Considerations include size and position of the screen, location of a suitable power outlet, as well as the location and distance between the projector and other equipment.

  • Page 19: Projection Dimension

    Projection Dimension Refer to the chart below to determine the screen size and projection distance. ( c ) (E): Screen (f): lens center Displays an image in 16:9 size on the 16:9 screen (b) Projection distance (d) Vertical offset (a) Screen size (c) Image height Minimum Maximum...

  • Page 20: Connection

    Connection When connecting a signal source to the projector, be sure to: Turn all devices off before making any connections. Use the correct signal cables for each source. Ensure the cables are firmly inserted. In the connections shown below, some cables may not be included within the projector packaging (please refer to “Shipping contents”).

  • Page 21: Connect To The Computer Or Monitor

    Connect to the computer or monitor Connect to the computer Use the VGA cable provided. Plug one end into the D-Sub output jack at the computer end. Connect the other end of the VGA cable to the COMPUTER signal input jack on the projector.

  • Page 22: Connecting To Video Source Devices

    Connecting to Video source devices You can connect the projector to any of the following video source device with an output jack: • HDMI • Video (composite video) Only one of the aforementioned connection methods is required to connect the projector to the video source device.

  • Page 23: Connecting To Hdmi Devices

    Connecting to HDMI devices Use an HDMI cable to establish a connection between the projector and HDMI device. Connect one end of the HDMI cable to the HDMI output jack on the video device. Connect the other end of the cable to the HDMI signal input jack on the projector. In the unlikely event that the projector is connected to a DVD player via the projector’s HDMI input and the projected picture displays wrong colors, please change the color space to YUV.

  • Page 24: Operation

    Operation Activate the projector Plug the power cord into the projector and into a wall socket. Turn on the switch on the wall socket (if available). Press Power to switch on the projector. If this is the first time that you've switched on the projector, please refer to on-screen instructions and select your OSD language and Projection mode.

  • Page 25: Using The Menus

    Using the menus This projector has an on-screen display (OSD) menu function that allows you to change different settings. The following OSD screenshot is for reference only. Actual OSD design may differ. The following is an overview of the OSD menu. Main menu icon...

  • Page 26: Use Basic Settings

    Use basic settings When not connected to the signal source 1. Press the [Setting] key on the remote control and enter the menu. Then press the / key and select “Basic Settings” then press the [Enter] key. 2. Press the / key to select the function table. 3.

  • Page 27: Use Network Setting

    Use Network setting When not connected to the signal source 5. Press the [Setting] key on the remote control and enter the menu. Then press the / key and select “Network Settings” then press the [Enter] key. 6. Press the / key to select the function table. 7.

  • Page 28: Use Advanced Settings

    Use Advanced settings When not connected to the signal source 1. Press the [Setting] key on the remote control and enter the menu. Then press the / key and select “Advanced Settings” then press the [Enter] key. 2. Press the / key to select the function table. 3.

  • Page 29: Use Information

    Use Information When not connected to the signal source 1. Press the [Setting] key on the remote control and enter the menu. Then press the / key and select “Information” then press the [Enter] key. 2. Press the / key to select the function table. 3.

  • Page 30: Use Firmware Upgrade

    Use Firmware upgrade Users can update the firmware by USB, and check the version. 1. Press [Setting] on the remote control and enter the menu. Then press / and select “Software Upgrade ” then press [Enter]. The Firmware update process requires for downloading and copying BIN file to root directory of USB, and then insert it into projector.

  • Page 31: Use Image Settings

    Use Image settings When connected to the signal source 1. Press the [Setting] key on the remote control and enter the menu. Then press the / key and select “Image Setting” then press the [Enter] key. 2. Press the / key to select the function table. 3.

  • Page 32: Use Advanced Settings (In Signal Source Mode)

    Use Advanced settings (in signal source mode) When connected to the signal source 1. Press the [Setting] key on the remote control and enter the menu. Then press the / key and select “Advanced” then press the [Enter] key. 2. Press the / key to select the function table. 3.

  • Page 33: Switching Input Signal

    Switching input signal The projector can be connected to multiple devices at the same time. However, it can only display one full screen at a time. Please press the signal [Source] button on the remote control to search for the available input signals.

  • Page 34: Changing Hdmi Input Settings

    Changing HDMI input settings In the unlikely event that you connect the projector to a device (such as DVD or Bluray player) via the projector’s HDMI input jack, and the projected picture displays the wrong colors, please change the color space settings to one that complies with the color space settings of the output device.

  • Page 35: Adjusting The Projected Image

    Adjusting the projected image Adjusting the projection angle The projector is furnished with an adjustment support peg. The adjustment support peg may be used to adjust projection height and projection angle along the vertical axis. The user may turn the adjustment support peg to make fine adjustments to projection angle and position of the projected image until it reaches the Lift and adjust the feet...

  • Page 36: Perform Keystone Correction

    Perform keystone correction Keystone distortion is a problem where the projected image becomes trapezoidal in shape (keystone distortion) as a result of poor projection angle. To correct this situation, you should adjust projector height and use the following steps to correct the issue manually.

  • Page 37: Using The Cec Function

    Using the CEC function This projector supports the Consumer Electronics Control (CEC), allowing you to connect to HDMI and achieve synchronized power ON/OFF operations. This means that when a device that also supports CEC is connected to the HDMI input jack of the projector, switching off the power of the projector will also automatically switch off the power of the connected device.

  • Page 38: Light Source Mode

    Light Source Mode Light Source Mode Sets the light Source Mode. • Normal: 100% of the light source power • Eco: 80% of the light source power Light Source Hours Display the duration that the light source has been running for (hours). Operations at high altitudes We recommend using the High Altitude Mode when the environment is at 1,500 to 3,000 meters above sea level and the temperature is between 5°C to 25°C.

  • Page 39: Optimize Images In User Mode

    Optimize images in user mode Selecting a picture mode ● The projector is preset with several predefined picture modes. You may choose one of these modes that best fits your operating environment and input signal picture type. ● To select an operation mode that suits your need, please follow the steps described below.

  • Page 40: Fine-Tuning Of Image Quality In User Modes

    Fine-tuning of image quality in user modes You may use several user-defined functions if the projector detects certain signal types. You can make adjustments to these functions based on your needs. Adjusting Brightness Enter Image Setting > Brightness menu and then press /.

  • Page 41: Adjust Gamma

    Adjust Gamma Enter Image Setting > Gamma menu then press / and adjust the value. 1.8 / 2.0 / 2.2 / 2.35 / 2.5 / sRGB / Cubic, respectively, represent the different gray scale curves. This function is only available when the input signal is video. Adjusting Brilliant Color Enter Image Setting >...

  • Page 42: Color Management

    Color Management Only in permanent installations with controlled lighting levels such as boardrooms, lecture theaters, or home theaters, should color management be considered. Color management provides fine color control adjustment to allow for more accurate color reproduction, should you require it. If you have purchased a test disc that contains various color test patterns that can be used to test the color presentation of monitors, TVs, and projectors, any image from the disc can be projected on screen and adjusted using the Color Management menu.

  • Page 43: Fine-Tuning Of Image In User Modes

    Fine-tuning of image in user modes If the projector detects specific types of signals, you can use several customized functions. You can adjust these functions as necessary. Adjusting Digital zoom Enter Image Setting > Digital Zoom menu and press / to adjust the value. Adjust the option to zoom in or out the image.

  • Page 44: Select The Aspect Ratio

    Select the aspect ratio The “Aspect Ratio” is the ratio of the image width against image height. It is 4:3 for most analog TVs and computers, and 16:9 for digital TVs and DVDs. With the emergence of digital signal processing, digital display equipment such as projectors can dynamically stretch the images and display the outputted images with a ratio different from that of the inputted image signals.
  • Page 45 3D functions This projector also comes with 3D functions that offer greater depth and immersion when viewing 3D movies, videos, sports, and games. You will need a pair of 3D glasses when viewing 3D images and videos. If the 3D signal comes from an HDMI 1.4a compatible device, this projector will look for a 3D Sync data signal.
  • Page 46 Control the projector through the local area network This projector supports Crestron software. After correct settings in the wired local area ® network menu are finished, the projector can be managed on the computer with the browser when the computer and the projector are correctly connected to the same local area network.

  • Page 47: Control The Projector With The Web Browser

    If you are in a non-DHCP environment: Repeat the above steps 1-2. Select DHCP and then press / to select Off. Contact your ITS administrator for the setting information about IP address, subnet mask, default gateway and DNS server. Press  to select the item you want to modify and then press [Enter]. Press /...
  • Page 48 You can adjust AMX and SNMP settings on this page. On the AMX device discovery, the controller connected to the AMX of the same network will find the projector when ON is selected. For details of the AMX Device Discovery, please access the AMX website: http://www.amx.com/.
  • Page 49 Please note the input length limits in the following table (including space and other punctuation marks): Type item Input length Maximum character DHCP/Manual (None) IP Address XXX.XXX.XXX.XXX Subnet Mask XXX.XXX.XXX.XXX Network Gateway XXX.XXX.XXX.XXX DNS Server XXX.XXX.XXX.XXX AMX device discovery (None) Network Settings Administrator (None)

  • Page 50: About Crestron E-Control

    About Crestron e-Control ® The Crestron e-Control page provides various virtual buttons to control the projector ® or adjust the projected image. You can press / to display more buttons. The functions of those buttons are identical with those on the OSD menu or remote control.
  • Page 51 iii. You can adjust the wired local area network. iv. After setup has finished, the remote network operation access to the projector is protected with a password. v. After setup has finished, access to the Tools page is protected with a password. To avoid mistakes, please input the English letters and digits in the Tools page.

  • Page 52: Using The Projector Under Standby Mode

    Press “Contact IT Help” button, and then a HELP DESK window will be displayed in the upper right corner of the screen. You can send information to the RoomView™ software administrator / user connected to the same local area network. For details, please access http://www.crestron.com and http://www.crestron.com/ getroomview.

  • Page 53: Switch Off The Projector

    Switch off the projector Press the Power button. A confirmation message will be displayed on screen. The message will disappear if you do not respond within a few seconds. Press the Power Button again, and the projector will be turned off. Wait until the fan is completely stopped and unplug the power cord.

  • Page 54: Menu Operations

    Menu operations Menu system (When not connected to signal source) Please note that the on-screen display (OSD) menu may vary according to the type of signal received. The projector must detect at least one valid signal in order to use the menu items. If no device has been connected to the projector or if no signal has been detected, only a few menu items will be accessible.
  • Page 55 Main menu Sub-menu Options · Light Source Hours · System Version · Memory Information Information · Network Mac Address · IP Address Software upgrade Software Update By USB Firmware · FW Version · Firmware Version Update...
  • Page 56 Menu system (When connected to signal source) Movie/Sports/Gaming/User 1/ Color Mode User 2/Brightest/Standard Brightness 0~100 Contrast -50~50 ·Red gain 0~199 7500K/9300K/User/ Color Temp ·Green gain 0~199 6500K ·Blue gain 0~199 Tint -99~99 Saturation 0~199 Sharpness 0~31 1.8/2.0/2.2/2.35/2.5/ Gamma sRGB/Cubic Brilliant Color 1/2/3/4/5/6/7/8/9/10/Off Image Setting Noise Reduction...
  • Page 57 Description of menu Functions Description Set language of the display screen (OSD) menu. Language Please refer to “Activate the projector” for the details. Mute Audio Volume Audio settings Power On/Off Ring Tone The will be a tone prompt when the projector is powered on or off.
  • Page 58 Functions Description Auto Power Off Please refer to “Setting Auto Power Off” for the details. Sleep Timer Smart Energy Please refer to “Setting the Sleep Timer” for the details. Power Saving Please refer to “Set power saving” for the details. Light Source Mode Please refer to the “Light Source Mode”...
  • Page 59 Functions Description Please refer to “Selecting a picture mode” for the Color Mode details. Brightness Please refer to “Adjusting Brightness” for the details. Contrast Please refer to “Adjusting Contrast” for the details. Please refer to “Selecting a Color Temperature” for the Color Temp details.

  • Page 60: Maintenance

    Maintenance Care of the projector Do not attempt to disassemble any part of the projector. Contact your dealer if you need to replace any parts. Cleaning the lens You can clean the dust-free glass lens if you notice any dirt or dust on its surface. ●...

  • Page 61: Led Indicator

    LED Indicator Projector status Power indicator Temp indicator Lamp indicator Stand-by mode Green Flashing Normally on Green Normal Operations Green Temperature Error Green Red Flashing Orange Temperature Error Green Red Flashing Fan Error 1 Green Red Flashing Green Fan Error 2 Green Red Flashing Green Flashing...

  • Page 62: Troubleshooting

    Troubleshooting Projector is not shutting down Cause Remedy Plug one end of the power cable at the AC inlet of the projector and the other There is no power from the power cable. end in the power outlet. If the power outlet has a switch, make sure that it is switched on.

  • Page 63: Specifications

    Specifications Projector specifications ● All specifications are subject to change without notice. ● Not all projector models are available at your location. Input Terminals VGA input (DB 15 pin) HDMI (v1.4 with audio) Video (RCA) Audio input (3.5mm mini jack) Output Terminals Audio output (3.5mm mini jack) USB-A 5V/1.5A...

  • Page 64: Dimensions

    Dimensions 396.0mm 156.8mm 313.8mm Ceiling mount installation 265.0mm 34.0mm Note: It is recommended to use the M4L8 screw for fixing the projector using the M4 screw hole. (M4/ L8 x 4)

  • Page 65: Timing Chart

    Timing chart Analog RGB Signal Resolution (pixels) Aspect Ratio Refresh rate (Hz) 640x480 SVGA 800x600 1024x768 WXGA 1280x800 16:10 Quad-VGA 1280x960 SXGA 1280x1024 SXGA+ 1400x1050 WXGA+ 1440x900 16:10 UXGA 1600x1200 HDTV (1080p) 1920x1080 16:9...
  • Page 66 HDMI Signal Resolution (pixels) Aspect Ratio Refresh rate (Hz) 640x480 SVGA 800x600 1024x768 1280x768 15:9 1280x800 16:10 WXGA 1360x768 16:9 1366x768 16:9 Quad-VGA 1280x960 SXGA 1280x1024 SXGA+ 1400x1050 WXGA+ 1440x900 16:10 WSXGA+ 1680x1050 16:10 3840x2160 16:9 24/25/30/50/60 HDTV (1080p) 1920x1080 16:9 50/60 HDTV (1080i)
  • Page 67 3D (including HDMI signal) Signal Resolution (pixels) Aspect Ratio Refresh rate (Hz) SVGA 800x600 60*/120 1024x768 60*/120 1280x720 16:9 50*60* WXGA 1280x800 16:9 * 60 Hz signals are supported for side by side, Top and Bottom, and Frame Sequential formats. HDMI 3D Within frame packing formats Signal...
  • Page 68 Composite video Signal Aspect Ratio Refresh rate (Hz) NTSC PAL60...

  • Page 69: Copyright Information

    ViewSonic. Disclaimer ViewSonic does not make any statement or warranty, expressed or implied, for the merchantability and fitness for a particular purpose with respect to any contents within this manual. Additionally, ViewSonic reserves the right to revise and update the contents of this manual without notice.

  • Page 70: Appendix

    Appendix IR control table Format Byte 1 Byte 2 Byte 3 Byte 4 Power ON NEC-F1 Power Off NEC-F1 COMP NEC-F1 HDMI 1 NEC-F1 HDMI 2 NEC-F1 Auto sync NEC-F1 Source NEC-F1 Up/keystone up NEC-F1 Left NEC-F1 Enter NEC-F1 Right NEC-F1 Down/keystone NEC-F1...

  • Page 71: Address Code

    Address Code Code 1 83F4 Code 2 93F4 Code 3 A3F4 Code 4 B3F4 Code 5 C3F4 Code 6 D3F4 Code 7 E3F4 Code 8 F3F4 RS232 command table <Pin assignment for this two end> Description Description RTSZ CTSZ <Interface> RS-232 protocol Baud Rate 115200bps (default)

  • Page 72: Rs232 Command Table

    <RS232 Command List> The below table list all RS232 commands frequently used: No. Function Type Action Command Response The response of Query Read command Power Write 0x06 0x14 0x00 0x04 0x00 0x34 0x11 0x03 0x14 0x00 0x00 0x00 0x14 0x05 0x14 0x00 0x03 0x00 0x00 0x00 0x01 0x00 0x00 0x5D 0x18 Power...
  • Page 73 No. Function Type Action Command Response The response of Query Read command Projector Write Rear Table 0x06 0x14 0x00 0x04 0x00 0x34 0x12 0x03 0x14 0x00 0x00 0x00 0x14 0x05 0x14 0x00 0x03 0x00 0x00 0x00 0x01 Position 0x00 0x01 0x5F 0x18 3D Sync Write...
  • Page 74 No. Function Type Action Command Response The response of Query Read command Horizontal Write Shift Left 0x06 0x14 0x00 0x04 0x00 0x34 0x12 0x03 0x14 0x00 0x00 0x00 0x14 position 0x06 0x00 0x64 Horizontal Read Get Value 0x07 0x14 0x00 0x05 0x00 0x34 0x00 0x05 0x14 0x00 0x03 0x00 0x00 Refer to value mapping table 3.2.1 (1byte) position...
  • Page 75 No. Function Type Action Command Response The response of Query Read command Primary Write 0x06 0x14 0x00 0x04 0x00 0x34 0x12 0x03 0x14 0x00 0x00 0x00 0x14 0x05 0x14 0x00 0x03 0x00 0x00 0x00 0x05 Color 0x10 0x05 0x73 0x1C Primary Read Status...
  • Page 76 No. Function Type Action Command Response The response of Query Read command Volume Write Write Value 0x06 0x14 0x00 0x04 0x00 0x34 0x13 0x03 0x14 0x00 0x00 0x00 0x14 0x2A 0x11 0x9A Volume Read Get Value 0x07 0x14 0x00 0x05 0x00 0x34 0x00 0x05 0x14 0x00 0x03 0x00 0x00 Refer to value mapping table 3.2.1 (1byte) 0x00 0x14 0x03 0x64...
  • Page 77 No. Function Type Action Command Response The response of Query Read command HDMI Read Status 0x07 0x14 0x00 0x05 0x00 0x34 0x00 0x05 0x14 0x00 0x03 0x00 0x00 Format 0x00 0x11 0x28 0x86 0x00 0x00 0x17 HDMI Write Enhanced 0x06 0x14 0x00 0x04 0x00 0x34 0x11 0x03 0x14 0x00 0x00 0x00 0x14 0x05 0x14 0x00 0x03 0x00 0x00 0x00 0x00 Range 0x29 0x00 0x86...
  • Page 78 My Button 0x02 0x14 0x00 0x04 0x00 0x34 0x02 0x03 0x14 0x00 0x00 0x00 0x14 0x04 0x11 0x63 Write AMXB<-SDKClass=VideoProjec response tor><-Make=ViewSonic><-Mode l=PX800HD> Operating Read Get Value 0x07 0x14 0x00 0x05 0x00 0x34 0x00 0x05 0x14 0x00 0x0A 0x00 0x00...
  • Page 79 Error response status：(Only for service debug) : Response : 0x05 0x14 0x00 0x16 0x00 0x00 0x00 ErrorStatus(20 Items) checksum Item 0 ~17: 1 byte. 1． Item 18 : First burn In error minutes， 4 Bytes. 2． Item 19: Lamp Status，1 Byte. 3．...
  • Page 80 Latin America C= http://www.viewsonic.com/ www.viewsonic.com/la/ soporte@viewsonic.com (Mexico) la/soporte/servicio-tecnico Nexus Hightech Solutions, Cincinnati #40 Desp. 1 Col. De los Deportes Mexico D.F. Tel: 55) 6547-6454 55)6547-6484 Other places please refer to http://www.viewsonic.com/la/soporte/servicio-tecnico#mexico Latin America C= http://www.viewsonic.com/ www.viewsonic.com/la/ soporte@viewsonic.com (Peru) la/soporte/servicio-tecnico Macau www.hk.viewsonic.com T= 853 2870 0303 service@hk.viewsonic.com...
  • Page 81 ViewSonic’s standard warranty period is one (1) year for any product model in any Please refer to the ViewSonic website in your country to check the local terms and model variants, and see if the product model in your country is eligible for a longer warranty period.
  • Page 82 There are no warranties, express or implied, which extend beyond the description particular purpose. Exclusion of damages: ViewSonic’s liability is limited to the cost of repair or replacement of the product. ViewSonic shall not be liable for: 1. Damage to other property caused by any defects in the product, damages based business opportunity, loss of goodwill, interference with business relationships, or other commercial loss, even if advised of the possibility of such damages.
  • Page 83 If a product proves to be defective in material or workmanship during the warranty period, ViewSonic will, at its sole option, repair or replace the product with a like product. Replacement product or parts may include remanufactured or refurbished parts or components &...
  • Page 84 Tel: (52) 999-925-1916 Tel: 01(52)95-15-15-22-22 E-Mail: rrrb@sureste.com Fax: 01(52)95-15-13-67-00 E-Mail. gpotai2001@hotmail.com Tijuana: FOR USA SUPPORT: ViewSonic Corporation Av Ferrocarril Sonora #3780 L-C 14035 Pipeline Ave. Chino, CA 91710, USA Col 20 de Noviembre Tel: 800-688-6688 (English); 866-323-8056 (Spanish); Tijuana, Mexico E-Mail: http://www.viewsonic.com...
