VISTA
400
Instructions For Use
Squeeze the yellow bar &
Step on yellow pedals to close
push down/pull up to activate
and open legs to go around
pneumatic stand assist.
chairs & ambulate.
Pull yellow levers to adjust
Adjustable seat pad
clamp. Turn to loosen and
configurations.
tighten adjustable shin pad.
REMOVABLE FOOT PLATE
Removable footplate for
AMBULATION.
800.255.3126 | wyeastmedical.com
51924-R01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VISTA 400 and is the answer not in the manual?

Questions and answers

Summary of Contents for WY'EAST MEDICAL VISTA 400

  • Page 1 VISTA Instructions For Use Squeeze the yellow bar & Step on yellow pedals to close push down/pull up to activate and open legs to go around pneumatic stand assist. chairs & ambulate. Pull yellow levers to adjust Adjustable seat pad clamp.
  • Page 2 All Yellow Areas on Equipment VISTA QUICK REFERENCE GUIDE Are Adjustable READ USERS MANUAL BEFORE OPERATING Position Standing Aid to Patient Transport Patient Open Legs and Seats As Needed UNLOCK WHEELS Position Patient’s Feet in Footrest Adjust Sitting Height LOCK WHEELS Position Seats Under Patient and Have Patient Sit Position Shin Support Against Shins...
  • Page 3 VISTA Operator ’s Manual OPERATOR’S MANUAL VISTA NON-POWERED STAND AID Model No. 51871 51928 R03 Vista Non-Powered Stand Aid 800.255.3126 | wyeastmedical.com Operator’s Manual Page 1 of 17...
  • Page 4 VISTA Operator ’s Manual WARRANTY Wy’East Medical Corporation (Wy’East) warrants to the original user the Vista Non-Powered Stand Aid manufactured by the company is free from defects in material and workmanship under normal use and service. The term of warranty from the date of product receipt is for a period of two (2) years on mechanical lift components, one (1) year on electronic components, and one (1) year for the battery.
  • Page 5: Table Of Contents

    VISTA Operator ’s Manual Contents HOW TO USE THIS MANUAL: _________________________________________________ 4 DEFINITIONS: ______________________________________________________________ 4 SAFETY CONSIDERATIONS FOR ALL PROCEDURES: ____________________________ 6 PRIOR TO FIRST USE: _______________________________________________________ 6 FEATURES: ________________________________________________________________ 7 Install/Uninstall Footrest: __________________________________________________ 7 Shin Guard Cam Lever: ___________________________________________________ 7 Shin Guard Adjustment Toward/Away from Patient: ____________________________ 7 Shin Guard Adjustment Up/Down: __________________________________________ 7 Seat Position: Up ________________________________________________________ 8...
  • Page 6: How To Use This Manual

    VISTA Operator ’s Manual Consistent with our policy of continuing product improvement, WY’EAST MEDICAL CORPORATION reserves the right to change these specifications without notice or obligation. INTRODUCTION HOW TO USE THIS MANUAL: This manual is designed to familiarize you with the operation of the Vista Non-Powered Stand Aid. Read it thoroughly before using or servicing the equipment.
  • Page 7 VISTA Operator ’s Manual Your Vista Non-Powered Stand Aid is designed for assisting patients with weight bearing ability to stand and transfer. • Bed to Chair transfer. • Wheelchair repositioning. • Easy access for wheelchair. • Total adjustability for convenience and usability. •...
  • Page 8: Safety Considerations For All Procedures

    VISTA Operator ’s Manual SAFETY CONSIDERATIONS FOR ALL PROCEDURES: 1. The Vista is designed to be used ONLY on level surfaces. 2. ALWAYS lock the wheels while positioning the patient. 3. Prior to using the Vista for transfer, the patient must be assessed by a qualified professional to determine the suitability of using the Vista with that patient.
  • Page 9: Features

    VISTA Operator ’s Manual FEATURES: Install/Uninstall Footrest: To remove the footrest, lift up by holding the yellow cross bar and handle (see Fig.1). a. Raise the footrest 2 inches vertically. b. Remove as shown. Figure 1 Shin Guard Cam Lever: 1.
  • Page 10: Seat Position: Up

    VISTA Operator ’s Manual FEATURES: Seat Position: Up To move seat up, pull up and rotate seat as shown. Seat Position: Out To move seat out, push up on yellow knuckle and rotate seat as shown. Seat Position: Up and Out To move seat up and out, follow the instructions for the two previous features.
  • Page 11: Seat Height Adjustment

    VISTA Operator ’s Manual FEATURES: Seat Height Adjustment: To lower or raise the seat height, squeeze the yellow lever and pull up or push down on the handlebar. NOTE: Adding weight on the seat pads can aid in height adjustment. Legs Open/Close Function: 1.
  • Page 12: Operating The Vista Non-Powered Stand Aid

    VISTA Operator ’s Manual OPERATING THE VISTA NON-POWERED STAND AID: 1. ENSURE patient is able to sit in an upright posture and the Vista is able to be positioned in front of the patient as shown (Fig. 3). 2. Move the SEATS out and OPEN the LEGS of the Vista to an appropriate width to maneuver the Vista around a chair or wheelchair (Fig.
  • Page 13 VISTA Operator ’s Manual 9. Instruct the patient to stand up (Fig. 5). 10. Position the seats under the patient and have them sit (Fig. 6). 11. Adjust SEAT height by squeezing the yellow lever and moving the handlebar up or down (Fig. 7). Figure 5 Figure 6 Figure 7...
  • Page 14: Technical Specifications

    VISTA Operator ’s Manual TECHNICAL SPECIFICATIONS: PARAMETER SPEC • SWL 400 lbs • Device Part Number 51871 • Unit of Measure 1 Each • Total Weight 92 lbs • Weight Loose Parts (Footrest) 12 lbs • Wheels Diameter, Front 3” •...
  • Page 15: Periodic Maintenance

    VISTA Operator ’s Manual PERIODIC MAINTENANCE: The following scheduled maintenance and inspections will help to ensure trouble-free operation of your Vista Non-Powered Stand Aid. Not recommended for use in shower. Do not pressure-wash the unit. ONCE A MONTH • Check for loose or missing nuts and bolts. •...
  • Page 16: Factory Assistance

    VISTA Operator ’s Manual FACTORY ASSISTANCE: Expected lifetime: 8-10 years REPLACEMENT ITEMS: To order replacement parts, contact Wy’East Medical Customer Service. Include the following information with your request: 1. Serial and Model numbers of your Vista Non-Powered Stand Aid. 2. Purchase date, if available. 3.
  • Page 17: Replacement Parts

    VISTA Operator ’s Manual REPLACEMENT PARTS: This manual provides maintenance and service information for the Vista Non-Powered Stand Aid. If replacement parts are required, contact WY’EAST MEDICAL with the serial number of your Vista Non-Powered Stand Aid to ensure the accuracy of replacement parts. 51854 51670 51899...
  • Page 18: Notes

    VISTA Operator ’s Manual NOTES: 51928 R03 Vista Non-Powered Stand Aid 800.255.3126 | wyeastmedical.com Operator’s Manual Page 16 of 17...
  • Page 19: Contact Information

    VISTA Operator ’s Manual CONTACT INFORMATION For questions or information regarding other Wy’East Medical products, contact: Wy’East Medical Corporation 16700 SE 120th Ave. Clackamas, OR 97015, USA (503) 657-3101 (800) 255-3126 wyeastmedical.com info@wyeastmed.com 51928 R03 Vista Non-Powered Stand Aid 800.255.3126 | wyeastmedical.com Operator’s Manual Page 17 of 17...
