INSTRUCTION AND PARTS BOOK NO. 10-18-11
HEAVY DUTY MANURE SPREADERS
MODEL: 3465
operate this Spreader until you have read
DO NOT
this book
repair or clean this Spreader while PTO is
NEVER
engaged
Manufactured in DORCHESTER, WISCONSIN by
MEYER'S EQUIPMENT
MFG. CORP.
Part Numbers E00017-E2415
Page 1
MODEL: 3465

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3465 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Meyer's 3465

Summary of Contents for Meyer's 3465

  • Page 1 INSTRUCTION AND PARTS BOOK NO. 10-18-11 HEAVY DUTY MANURE SPREADERS MODEL: 3465 operate this Spreader until you have read DO NOT this book repair or clean this Spreader while PTO is NEVER engaged Manufactured in DORCHESTER, WISCONSIN by MEYER’S EQUIPMENT MFG.

  • Page 2: Introduction

    This supercedes all previous published instructions. At the front of this manual is a Product Registration and Inspection Certificate. Be sure your dealer has completed this certificate and forwarded a copy to the manufacturer to validate the manufacturer’s warranty. Page 2 MODEL: 3465...

  • Page 3: Table Of Contents

    E00344-05 540 RPM Beater Drive Gear Box ........................... 42 5490-0686 540 RPM Beater Drive Gear Box Complete ......................44 Upper Beater Drive ................................... 46 Model 3465 Apron Drive Gearbox ............................48 Removable CV Telescoping Universal Joint Assembly With Over Running Automatic Clutch & Guard, Trailer To Tractor............................50 Removable CV Telescoping Universal Joint Assembly with Over Running Automatic Clutch &...

  • Page 4: Safety

    CAUTION: IF ANY SAFETY SIGN BECOMES UNREADABLE FOR ANY REASON, THE SIGN MUST BE REPLACED WITH A NEW SIGN. IF THE SPREADER IS REPAINTED, ALL SAFETY SIGNS MUST BE RE- PLACED. CONTACT YOUR DEALER OR MEYER’S EQUIPMENT MANUFACTURING CORP. IF YOU RE- QUIRE ANY SHIELD OR SIGNS FOR REPLACEMENT. Page 4 MODEL: 3465...
  • Page 5 CAUTION: IF ANY SAFETY SIGN BECOMES UNREADABLE FOR ANY REASON, THE SIGN MUST BE REPLACED WITH A NEW SIGN. IF THE SPREADER IS REPAINTED, ALL SAFETY SIGNS MUST BE RE- PLACED. CONTACT YOUR DEALER OR MEYER’S EQUIPMENT MANUFACTURING CORP. IF YOU REQUIRE ANY SHIELD OR SIGNS FOR REPLACEMENT. Page 5 MODEL: 3465...

  • Page 6: Safety Signs

    CAUTION: IF ANY SAFETY SIGN BECOMES UNREADABLE FOR ANY REASON, THE SIGN MUST BE REPLACED WITH A NEW SIGN. IF THE SPREADER IS REPAINTED, ALL SAFETY SIGNS MUST BE REPLACED. CONTACT YOUR DEALER OR MEYER’S EQUIPMENT MANUFACTURING CORP. IF YOU REQUIRE ANY SHIELD OR SIGNS FOR RE- PLACEMENT. Page 6 MODEL: 3465...
  • Page 7 CAUTION: IF ANY SAFETY SIGN BECOMES UNREADABLE FOR ANY REASON, THE SIGN MUST BE REPLACED WITH A NEW SIGN. IF THE SPREADER IS REPAINTED, ALL SAFETY SIGNS MUST BE RE- PLACED. CONTACT YOUR DEALER OR MEYER’S EQUIPMENT MANUFACTURING CORP. IF YOU REQUIRE ANY SHIELD OR SIGNS FOR REPLACEMENT. Page 7 MODEL: 3465...

  • Page 8: Manure Spreader Safety

    From The Hydraulic System Before Connecting Or Disconnecting The Lines Or Making Repairs. Check All Hoses And Fittings Before Start-up And Periodically During Operation. Never Make Any Alterations Or Modifications To This Equipment • FAILURE TO HEED MAY RESULT IN SERIOUS PERSONAL INJURY OR DEATH Page 8 MODEL: 3465...
  • Page 9 NATIONAL SAFETY COUNCIL BEFORE ATTEMPTING TO OPERATE YOUR NEW SPREADER BE SURE TO READ THIS OWNERS MANUAL AND FAMILIARIZE YOURSELF WITH THE MACHINE!! OBSERVE THE PRECAUTIONS IN THIS MANUAL FOR SAFE OPERATION OF THIS MACHINE!! Page 9 MODEL: 3465...

  • Page 10: Pre-Operation

    If the implement (Figure 2, lower view) is attached to a tractor with an offset in the drawbar, be certain it is in the down position to prevent damage to the IID guarding or the IID telescoping members. FIGURE 1. TRACTOR DRAWBAR & PTO SPECIFICATION Page 10 MODEL: 3465...

  • Page 11: Tractor Size Requirements

    “control hose” described above. This system ERATION. has a motorized flow control valve on the spreader and an electric control box placed on the tractor is used to control this valve. See Fig- ure 4. Page 11 MODEL: 3465...

  • Page 12: Set Up For Open Or Closed Center Hydraulic Operation

    Electric Control Installation manually adjustable, the ball Valve must be open. This is not a tractor lever operated system. 1. Locate the controller on the tractor where it is ac- cessible to operate. Page 12 MODEL: 3465...

  • Page 13: Transporting

    This will include lighting and brake requirements in addition to traffic rules. You may also be required to install a safety chain on the spreader. FIGURE 7. SUGGESTED SAFETY CHAIN INST ALL AT ION Page 13 MODEL: 3465...

  • Page 14: Operation

    Page 14 MODEL: 3465...

  • Page 15: Unloading

    3. For solid manure, start the apron at a slow rate of injury. speed. 4. Start the apron drive with the tractor hydraulic spool valve lever. Page 15 MODEL: 3465...

  • Page 16: Maintenance, Adjustments & Lubrication

    2. Shut off the tractor engine, remove the ignition key WHEELS: Check after first hour of towing and periodi- and take it with you. cally thereafter. The 3465 wheel studs should be 3. Wait for all movement to stop. torqued to 170 foot pounds.

  • Page 17: Lubrication

    Maintain oil level in apron drive reducer at check level plug, accessible at left, rear side. When required, refill with SAE 85-140 Moly Fortified gear lube or Syn- thetic SAE 75-90 gear lube. Figure 11. FIGURE 10. FIGURE 11. FIGURE 12. FIGURE 13. Page 17 MODEL: 3465...
  • Page 18 Special attention should be paid to lubricating the constant velocity PTO drive shaft assembly. See illus- tration above. Figure 15. Grease the over running clutch 3-4 pumps every 8 hours. Figure 15. FIGURE 15. PTO LUBRICAT ION Page 18 MODEL: 3465...

  • Page 19: Cleaning And Storage

    4. This is a good time to inspect all adjustments and check for parts that need repair or replacement. Per- forming these tasks now will guarantee that the spreader is ready for use at the beginning of the next season. Page 19 MODEL: 3465...

  • Page 20: Repair Parts

    REPAIR PARTS MAIN FRAME & BOX PARTS Model 3465 Page 20 MODEL: 3465...
  • Page 21 MAIN FRAME & BOX PARTS Model 3465 PART NO. DESCRIPTION E00017-04 Door, Main Gear Case E00016 Lock Assembly E21651 Top Cover, Main Gear Case Shield E21652 Back Cover, Main Gear Case Shield E21645-09 Side Shaft Shield (Back) E21646-09 Side Shaft Shield (Front)

  • Page 22: Hydraulic End Gate & Related Parts

    HYDRAULIC END GATE & RELATED PARTS Model 3465 Page 22 MODEL: 3465...
  • Page 23 HYDRAULIC END GATE & RELATED PARTS Model 3465 PART NO. DESCRIPTION 3465 E00034-96-04 Gate, End Only E00037-96 Belt, Side End Gate REF. Cylinder, End Gate (See separate listing) E00038-96 Belt, Bottom End Gate E21742 End Gate Insert Page 23 MODEL: 3465...

  • Page 24: Jack Assembly

    JACK ASSEMBLY Model 3465 Page 24 MODEL: 3465...
  • Page 25 JACK ASSEMBLY Model 3465 PART NO. DESCRIPTION 3465 E00053-11 Jack Assembly E00057-11 Weld on Mount E20228 Page 25 MODEL: 3465...

  • Page 26: End Gate Hydraulic Piping

    END GATE HYDRAULIC PIPING Model 3465 HydEndGateParts-3465 Page 26 MODEL: 3465...
  • Page 27 END GATE HYDRAULIC PIPING Model 3465 PART NO. DESCRIPTION E00090-07 Cylinder, End Gate Hydraulic - 3” x 10” E00109 Cylinder Seal Kit 639572 E00110 Wiper Seal 1125-6 E00067-04 Male JIC To Male ORB, 90° Adapter - 6801-8-8 E00068-04 Hose, Hydraulic, 6M3K-6G-8FJX90S-6G-8FJX-53”...

  • Page 28: Axles, Wheels, Spindles And Related Parts

    AXLES, WHEELS, SPINDLES AND RELATED PARTS Model 3465 TandemParts-3465 Page 28 MODEL: 3465...
  • Page 29 AXLES, WHEELS, SPINDLES AND RELATED PARTS Model 3465 11/07 QTY. PART NO. DESCRIPTION 3465 E00120-08 Arm Assembly, Drilled For 3” Spindle E00146-00 Spindle, Stress Proof 3” x 20 E00147 Seal, Hub, CR29968 E00148 Bearing, Inside Wheel, 387-A5 E00151 Hub, 758...

  • Page 30: Side Drive Train

    SIDE DRIVE TRAIN Model 3465 LineShaftParts-3465.tif Page 30 MODEL: 3465...
  • Page 31 SIDE DRIVE TRAIN Model 3465 PART NO. DESCRIPTION 3465 REF. Gear Box, Beater Drive (see Separate Listing) E01181 Key, 3/8” x 3/8” x 1-5/8” Long E00197-04 Coupler With Chain 6018 E00198 Guard, Shaft - (13-7/8" Lg) E00199 Shaft, Side - (214-1/2" Lg) E20628 Shaft, Side - (190-3/8"...

  • Page 32: Apron & Related Parts

    APRON & RELATED PARTS FOR STANDARD 67P11 & OPTIONAL 667XH PINTLE CHAIN Model 3465 Page 32 MODEL: 3465...
  • Page 33 APRON & RELATED PARTS FOR STANDARD 67P11 & OPTIONAL 667XH PINTLE CHAIN Model 3465 PART NO. DESCRIPTION E00222-11 Apron - Complete #67P11 E02027 Link, T-Bar #67P11 E00225-10 Slat with Links 28" for 67P11 Chain only E00231-11 Shaft, Apron 2-3/8" Dia. 76-5/8" - For 67P11 Chain only E00231-11P Shaft, Apron 2-3/8"...

  • Page 34: Lube Bank

    LUBE BANK Model 3465 Page 34 MODEL: 3465...
  • Page 35 LUBE BANK Model 3465 DOUBLE SINGLE PART NO. CONVEYOR CONVEYOR DESCRIPTION QTY. QTY. E20730 Zerk, 1/8NPT Str E20731 BF Connector 1/4Tx1/8MPT E20732 Elbow, 1/8x90 Blk, Street E20733-06 Nipple, Sch 40, 1/8NPTx3 Blk, 4” E22448 Elbow, 1/8” 90° Blk E22449 Tube, Outside - 34”...

  • Page 36: Beaters & Related Parts

    BEATERS & RELATED PARTS Model 3465 See Page 46 for Current Upper Beater Drive Parts. Page 36 MODEL: 3465...
  • Page 37 BEATERS & RELATED PARTS Model 3465 PART NO. DESCRIPTION 3465 E00260-07 Beater, Upper Only, For 2” Dia. Shaft (SN 5346508+) E00260 Beater, Upper Only, For 1 1/2” Dia. Shaft (SN 5346507-) E00261-07 Bearing Assembly, 4 Bolt SCJ 2” E00261 Bearing Assembly, RCJ-1 1/2”...

  • Page 38: Front Drive Train

    FRONT DRIVE TRAIN Model 3465 Page 38 MODEL: 3465...
  • Page 39 FRONT DRIVE TRAIN Model 3465 PART NO. DESCRIPTION 3465 E00304-00 Shield, Front E00016 Lock Assembly E20934 Eye Bolt E00301-04 Shield, Front Drive Shaft E20932 Key, 3/8” x 2” E00295-09 Shaft, Front Drive 1-3/4” x 17-1/4” Lg SP REF. Collar E00298-09 Bearing Assembly, RAK 1-3/4”...

  • Page 40: Beater Drive Train

    BEATER DRIVE TRAIN Model 3465 BeaterDrive-3600-3465 Page 40 MODEL: 3465...
  • Page 41 BEATER DRIVE TRAIN Model 3465 PART NO. DESCRIPTION 3465 E00311-00 Tension Adjuster 1/2” Bore, Rubber E00307-04 Tension Arm E00316 Key 3/8"x2" Gear Box, Beater Drive (see separate listing) Motor, Hydraulic (see separate listing) Gear Box, Apron Drive (see separate listing) E210391-04 80SF20 - 1-3/8”...

  • Page 42: E00344-05 540 Rpm Beater Drive Gear Box

    E00344-05 540 RPM BEATER DRIVE GEAR BOX Used from 12/1/04 to ? First Serial No. 293425 Last Serial No. ? Model 3465 Page 42 MODEL: 3465...
  • Page 43 E00344-05 540 RPM BEATER DRIVE GEAR BOX Used from 12/1/04 to ? First Serial No. 293425 Last Serial No. ? Model 3465 QTY. PART NO. DESCRIPTION 3465 E21242-W Housing 70-00015 E01302 End Cap A40 -15 E01316 Stamping Cover K155 E01914...

  • Page 44: 5490-0686 540 Rpm Beater Drive Gear Box Complete

    5490-0686 540 RPM BEATER DRIVE GEAR BOX COMPLETE (WILL REPLACE E00344-05 GEAR BOX AT A LATER DATE.) Model 3465 Page 44 MODEL: 3465...
  • Page 45 5490-0686 540 RPM BEATER DRIVE GEAR BOX COMPLETE (WILL REPLACE E00344-05 GEAR BOX AT A LATER DATE.) Model 3465 QTY. PART NO. DESCRIPTION 3465 70-06130 Machined Housing E01302 End Cap A40 -15 11-20439 Screw, 5/16 - 18 X 3/4 11-20439...

  • Page 46: Upper Beater Drive

    UPPER BEATER DRIVE Model 3465 Page 46 MODEL: 3465...
  • Page 47 UPPER BEATER DRIVE Model 3465 PART NO. DESCRIPTION 3465 E21543 Shield Top, Upper Beater Drive E21544 Shield Back, Upper Beater Drive E21545 Shield Front, Upper Beater Drive E21546 Shield Door, Upper Beater Drive E21547 Hinge, Door Shield E21548 Door Lift...

  • Page 48: Model 3465 Apron Drive Gearbox

    MODEL 3465 APRON DRIVE GEARBOX Page 48 MODEL: 3465...
  • Page 49 MODEL 3465 APRON DRIVE GEARBOX PART NO. DESCRIPTION VB-00061 Complete Gearbox 15410-2.375 VB-00032 Housing 8979 VB-00033-11 15414 VB-00034 Circlip E 95 9066 VB-00035 Gear Z=54 8996 VB-00036 Bearing 6017 9067 VB-00037 Circlip I 130 9069 VB-00038 Pinion Z=12 9009 VB-00039...

  • Page 50: Removable Cv Telescoping Universal Joint Assembly With Over Running Automatic Clutch & Guard, Trailer To Tractor

    REMOVABLE CV TELESCOPING UNIVERSAL JOINT ASSEMBLY WITH OVER RUNNING AUTOMATIC CLUTCH & GUARD, TRAILER TO TRACTOR (Used 12-11-09 And Later) Model 3465, 1 3/4-20 and 1 3/8-21 Spline PART NO. DESCRIPTION 1 3/4-20 1 3/8-21 E00475-10 Joint & Shaft Half Asm W/Guard, 93-25052 E00471-10 Joint &...

  • Page 51: Removable Cv Telescoping Universal Joint Assembly With Over Running Automatic Clutch & Guard, Trailer To Tractor

    E00459-08 Outer Guard, 97-24063 E00472-09 Inner Guard, 96-24396 VB-00071 Safety Sign, 13-10022 E00473-09 Yoke, Tube & Slip Sleeve, 98-24396 E00465 35E Cross & Bearing Kit, 03-15303 E00474-09 Automatic Clutch Asm, 38-11213 E00475-09 Hub Clamp Asm, 06-13492 Page 51 MODEL: 3465...

  • Page 52: Standard Hydraulic Apron-Flow Control On Spreader And Optional Electric Control

    STANDARD HYDRAULIC APRON-FLOW CONTROL ON SPREADER AND OPTIONAL ELECTRIC CONTROL Model 3465 Page 52 MODEL: 3465...
  • Page 53 STANDARD HYDRAULIC APRON-FLOW CONTROL ON SPREADER AND OPTIONAL ELECTRIC CONTROL Model 3465 PART NO. DESCRIPTION E00509-04 Motor, Hydraulic - HB, 2-Bolt E00483-09-S Hose Flow Line 8M3K-8G-8FJX90S-8G-8FJX-243” E00484-00 Adapter JIC to O-Ring 6400-8-10 E00485-00 O-Ring Adapter 6403NW0-10-8 E00486-00 Valve, Motor Control CFQ-A-10...

  • Page 54: Optional Tractor Lever Operated Hydraulic Apron

    OPTIONAL TRACTOR LEVER OPERATED HYDRAULIC APRON Model 3465 Page 54 MODEL: 3465...
  • Page 55 OPTIONAL TRACTOR LEVER OPERATED HYDRAULIC APRON Model 3465 PART NO. DESCRIPTION E21456-06 VALVE CONTROLLED FLOW BG-514-12SAE E21450 ADAPTER 6400·8·12 O-RING E23579 O-RING TO JIC 90 DEGREE ADAPTER 6801-8-12 E00483-09 CAP FOR CONVERTING TO OPEN CENTER SYSTEM 304-C-8 E00485-09 ADAPTER TEE 6602-8...

  • Page 56: Chain Oiling Kit

    CHAIN OILING KIT Model 3465 PART NO. DESCRIPTION 3465 E24142 Mounting Bracket, Top Beater Chain E24143 Mounting Bracket, Main Beater Chain E24145 Elbow, Swivel 3/8” O-Ring 6801-6-8 E24146 Quick Coupler 4000-2P E24147 Panel Mount Coupling E24148 Hose Assembly Cylinder 4M3K-6FJX-4MP 50”...

  • Page 57: Standard Highway Lighting With Amber Side Light

    PART NO. DESCRIPTION 54209-006 Dual Light LH w/4-Plug 54209-020 Dual Light RH w/4-Plug 3465-VB750-11 Bracket, Light 002430 Harness With 7 Pin Plug And 4-Flat, 30' 002515 Rear Wishbone Harness, 15' 802651 Red Lens 802650 Amber Lens Page 57 MODEL: 3465...
  • Page 58 This Page Intentionally Blank.
  • Page 59 This Page Intentionally Blank. Page 59 MODEL: 3465...

  • Page 60: Limited Warranty Statement

    LIMITED WARRANTY STATEMENT Meyer’s Equipment Mfg. Corp. warrants each new Meyer’s E.M.C. product to be free from: de- fects in material and workmanship. This warranty is applicable only for the normal service life expectancy of the product or components, not to exceed 12 consecutive months from the date of delivery of the new Meyer’s E.M.C.

This manual is also suitable for:
