- Page 1 20 LCD TV User Guide Auto Tune POWER D1/D2/D3 SCART S-VIDEO COMP. SOURCE FAV. V-CHIP C.C. INDEX Sub-Page HOLD PAGE+ PAGE- ZOOM MUTE DISP VOL- MENU VOL+ SLEEP EXIT CH RTN...
-
Page 2: Federal Communications Commission Statement
3. Connect the equipment into an outlet on a circuit which is different from what the receiver is connected to. 4. Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the manufacturer responsible for compliance could void the user authority to operate the equipment. -
Page 3: Warnings And Precautions
Warnings and Precautions To prevent any injuries, the following safety precautions should be observed in the installation, use, servicing and maintenance of this equipment. Before operating this equipment, please read this manual completely, and keep it nearby for future reference. This symbol is intended to alert the user to avoid the risk of electric shock. - Page 4 ▪ Remove the plug from the wall outlet, if the equipment will not be used for a long period of time. ▪ Do not place, use or handle this equipment near water. ▪ Never expose the equipment to liquid, rain, or moisture. Seek for service if any of the above is spilled into the equipment.
-
Page 5: Antenna Safety Instructions
Outdoor If an outdoor antenna is connected, follow the precautions below: ▪ An outdoor antenna should not be located in any area where it could come in contact with overhead power lines, or any other electric light or power circuits. ▪... -
Page 6: Table Of Contents
Information Menu ... 35 Restoring the factory setting ... 35 Customizing the V-CHIP Settings (For U.S TV system only) ... 36 Customizing the Closed Caption Settings (For U.S TV system only) ... 39 TROUBLESHOOTING ... 41 SPECIFICATION ... 42 Troubleshooting and Specifications... - Page 7 Chapter 1 Introducing the LCD TV...
-
Page 8: Chapter 1 Introducing The Lcd Tv
Chapter 1 Introducing the LCD TV Various Audio/Video terminals for external equipment connection ▪ 1 set of composite A/V terminals ▪ 1 S-VIDEO terminal ▪ 1 set of component Video input terminals ▪ 1 VGA input terminal ▪ 3 sets of Audio input terminals Digital Noise Reduction ▪... -
Page 9: Package Contents
LCD TV Power Cord User Guide These items are all you need to set up and operate the LCD TV in its basic configuration. Most devices (VCRs, DVD players etc.) come with the necessary cables for connection. If you want to set up a complex system, you may need to purchase extra cables, connectors etc. -
Page 10: Setting Your Lcd Tv
Use a supplied antenna cable to connect the VHF/UHF signal to the LCD TV’s ANT. terminal (refer to page11). Connect the DC plug of the AC-DC adapter to the DC 12V socket at the back of the TV. Connect the AC-DC adapter and its power cord. Connect the power cord to wall outlet. ... -
Page 11: Your Lcd Tv
OSD mode. MENU Press once to display the OSD (on screen display), press again to turn the OSD off. Chapter 1 Introducing the LCD TV Your LCD TV SOURCE Chooses from different input signal sources. - Page 12 COMPONENT(YCbCr) Connects to the Component(YCbCr) video and audio output jacks on external video equipment. ANT. Connects to a television antenna via a TV RF signal cable. DC IN Connects to a wall outlet via the included - AC-DC power adapter.
-
Page 13: Your Remote Control
Sets the LCD TV sleep time. The one/two digit numbers by pressing this button. Effective range: The remote can control the LCD TV from up to 5m away, if pointed directly at the receiver. Chapter 1 Introducing the LCD TV Your Remote Control... -
Page 14: Chapter 2 Installing The Lcd Tv
Connecting a TV Cable or Antenna Antenna Connection The antenna requirements for good color TV reception are more important than those for a black & white TV reception. For this reason, a good quality outdoor antenna is strongly recommended. The following is a brief explanation of the type of connection that is provided with the various antenna systems. - Page 15 A. Combination VHF/UHF antenna B. Separate VHF and/or UHF antennas Chapter 2 Installing the LCD TV VHF/UHF Antenna 300/75-ohm adapter (not included) VHF/UHF Antenna 300-ohm twin- lead cable 75-ohm coaxial cable Antenna Combiner 300-ohm twin- (not included) lead cable 75-ohm...
- Page 16 Use of this TV for other than private viewing of programs broadcasted on UHF, VHF or transmitted by cable companies for the use of the general public may require authorization from the broadcast/cable company, and/ or program owner.
- Page 17 Use a supplied antenna cable to connect the VHF/UHF signal to the LCD TV’s ANT. terminal. Connect the DC plug of the AC-DC adapter to the DC 12V socket at the back of the TV. Connect the AC-DC adapter and its power cord. Connect the power cord to wall outlet. ...
-
Page 18: Connecting A Vcr
METHOD A: Use an audio cable to connect the VCR’s audio output jacks to the LCD TV’s audio inputs. Use an S-Video cable to connect the VCR’s S-video output jack to the LCD TV’s S-video input jack. METHOD B: Use a composite cable to connect the VCR’s composite video/audio jacks to the LCD TV’s... -
Page 19: Connecting A Dvd Player
LCD TV’s audio input jacks. METHOD B: Use an audio cable to connect the DVD’s audio output jacks to the LCD TV’s audio inputs. Use an S-Video cable to connect the DVD’s S-video output jack to the LCD TV’s S-video input jack. - Page 20 METHOD A: Use an audio cable to connect the TV Cable Box’s audio output jacks to the LCD TV’s audio inputs. Use an S-Video cable to connect the TV Cable Box’s S-video output jack to the LCD TV’s S-video input jack.
-
Page 21: Connecting A Tv Cable Box And Satellite Receiver
Press the button on the remote to turn on the LCD TV. To watch programs via satellite receiver, press the YCbCr button on the remote. To watch TV via TV cable box, press the S-VIDEO the remote... -
Page 22: Connecting A Video Camara
Connecting a Video Camara METHOD A: Use an audio cable to connect the video camera’s audio output jacks to the LCD TV’s audio inputs. Use an S-Video cable to connect the VCR’s S-video output jack to the LCD TV’s S-video input jack. -
Page 23: Connecting A Two Vcrs
Use a composite cable to connect the TV’s composite video/audio input jacks. Connect all AC power sources, before turning the LCD TV’s power switch on. Press the button on the remote to turn on your LCD TV. -
Page 24: Connecting A Pc
Use a D-SUB cable to connect the PC’s D-SUB output jack to the LCD TV’s VGA input jack. Connect all AC power sources, before turning on the power switch of the LCD TV or other connected equipment. ... - Page 25 Chapter 3 Using the LCD TV...
-
Page 26: Chapter 3 Using The Features
Press the DISPLAY button to display information such as the channel and channel label. Press the DISPLAY button again to hide the information. If the LCD TV does not display any picture, check all the connections. Watching Your LCD Chapter 3 Using the LCD TV... -
Page 27: Operating The Menu
Press the button to turn the LCD TV on. To select the signal source, press the MENU button on the remote control. The main menu will appear on the screen. If the signal source is video singal, the menu displays:... - Page 28 R GAIN G GAIN B GAIN COLOR MODE : EXIT : SELECT to change the value of VOL- VOL+ Chapter 3 Using the LCD TV : ADJUST ( SOFT ) ( STEREO ) : ADJUST ( COOL ) : ADJUST...
-
Page 29: Setting Up The Channel List
Automatically scans and stores all the TV channels With the LCD TV connected to a television programming source, press the TV button on the remote control. Press the MENU button on the remote control to display the Main menu, and use to select the CHANNEL SETTING, and press ►. - Page 30 To add the hided channels, please repeat steps 1-3 and use OFF option. Hided channels can only be accessed with the 0-9 buttons. to select the YES option. VOL- VOL+ VOL- Chapter 3 Using the LCD TV to select the VOL+...
- Page 31 : EXIT : SELECT : ADJUST To add more channle to your favorites list, repeat steps 2-3. The favorite chanels feature lets you set up ten favorite channels. Chapter 3 Using the LCD TV ...
-
Page 32: Customizing The Picture Settings
Customizing the Picture Settings Press the button to turn the LCD TV on. Press the MENU button to display the Main Menu : MAIN MEMU VIDEO ADJUST AUDIO ADJUST SYSTEM SETTING CHANNEL SETTING CLOSED CAPTION V-CHIP BLOACK FACTORY PRESET... -
Page 33: Customizing The Audio Settings
MUTE Controls the mono/stereo mode, and allows the speakers to play high- SOUND MODE fidelity stereo sound from a different source than the TV program currently being viewed. STEREO: Use separate audio tracks for left and right speakers, if DUAL: MONO: Use a single audio track for left and right speakers. -
Page 34: Customizing The Picture Color Settings
Customizing the Picture Color Settings Press the button to turn the LCD TV on. If the signal source is PC singal, press the MENU button to display the Main Menu : MAIN MEMU VIDEO ADJUST AUDIO ADJUST COLOR ADJUST... -
Page 35: Customizing The System Settings
LANGUAGE Allows selection of the language used on all the on-screen menus. Allows selection of the time that elapses before the TV shuts off SLEEP TIME automatically: Off/10-120 minutes. Allows selection of the time that elapses before the TV turns on WAKE UP TIME automatically: off/0.5-23.5 hrs... -
Page 36: Information Menu
Press the button to turn the LCD TV on. If the signal source is PC singal, press the MENU button to display the Main Menu : MAIN MEMU VIDEO ADJUST AUDIO ADJUST COLOR ADJUST INFORMATION FACTORY PRESET : EXIT... -
Page 37: Customizing The V-Chip Settings (For U.s Tv System Only)
Customizing the V-CHIP Settings (For U.S TV system only) The US has 2 rating system for viewing content: Movie bloacking(MPAA) and TV Blocking. The TV Blocking conjuncts with the V-CHIP to help parents block inappropriate programs from their children. The Movie bloacking(MPAA) is used for original movies rated by the Motion Picture Association of America(MPAA) as broadcasted on cable TV and not edited for television. - Page 38 : To block programs by both content and age. to select the rating you want and press CONTENT-BASED button to select BLOCK or UNBLOCK. VOL- VOL+ Chapter 3 Using the LCD TV ...
- Page 39 STATUS MPAA TV QUIDELINES NEW PASSWORD : EXIT : SELECT : ADJUST Press the VOL+-buttons to enter a new four-digit password. Chapter 3 Using the LCD TV , then press ►. NEW PASSWORD...
-
Page 40: Customizing The Closed Caption Settings (For U.s Tv System Only)
Customizing the Closed Caption Settings (For U.S TV system only) Allows selection of the closed caption modes: CC1 /CC2 : Displays a printed version of the dialog or sound effects of the program. TEXT1/TEXT2: Displays station information presented using either half or the whole screen. - Page 41 Troubleshooting and Specifications...
-
Page 42: Troubleshooting
The batteries in the remote control may be exhausted. Replace the batteries. No picture, no sound Check the interface cable between TV and antenna/cable TV. Press the button on the remote. Press the button on the remote, then press other input source button to select the connected video sources. -
Page 43: Specification
TROUBLESHOOTING Panel System Display Resolution Television System Antenna Input AV IN AV OUT YCbCr AUDIO IN AUDIO OUT SPEAKER OUT POWER SOURCE (Power consumption(Max)) DIMENSION WEIGHT Troubleshooting and Specifications SPECIFICATION 20 inch 800 pixels(horizontal) x 600 pixels (vertical) NTSC 75 Ω unbalanced 5 W x 2 580 mm (W) x 620 mm (H) x 285 mm (D) 11 KG...
