Summary of Contents for Emprex LXA-42A200
-
Page 2: Table Of Contents
... 2 AFETY RECAUTIONS INTRODUCTION YOUR TELEVISION ... 5 UPPLIED CCESSORIES TV C ... 6 ONTROL UNCTIONS ETTING P THE EMOTE ONTROL ... 8 EMOTE ONTROL UNCTIONS ... 9 NPUTS AND UTPUTS OSD MENU – MAIN MENU ...12 ICTURE ...14 IDEO ...16... -
Page 3: Before Using This Product
POTENTIAL ELECTRICAL SHOCK OR FIRE HAZARD. In order to prevent potential danger, please observe the following instructions when installing, operating and cleaning the product. To ensure your safety and prolong the service life of your LCD TV product, please read the following precautions carefully before using the product. - Page 4 AC outlet, and request a qualified service person to perform repairs. When the power cord or plug is damaged. When a liquid is spilled on the product or when objects have fallen into the product. When the product has been exposed to rain or water. When the product does not operate properly as described in the operating instructions.
- Page 5 18. Do not use this apparatus near water---for example, near a bathtub, washbowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, and the like. Do not use immediately after moving from a low temperature to high temperature environment, as this causes condensation, which may result in fire, electric shock, or other hazards.
-
Page 6: Introduction Your Television
Introduction Your Television Supplied Accessories The following items come with your LCD TV:... -
Page 7: Tv Control Functions
Press this button to turn the power on/standby. Press this button to display the OSD menu. It contains all the options to MENU configure your TV's settings. Video input selection. Press this button to display the menu for input SOURCE selection mode. -
Page 8: Setting Up The Remote Control
Setting Up the Remote Control Open the lid of your remote control battery compartment on the back of the remote control. Insert two AA batteries. Use the (+) and (-) marks to guide you. The (+) marks on your batteries correspond to the (+) marks on the compartment. -
Page 9: Remote Control Functions
SOUND Call out sound mode menu and adjust the audio mode Volume UP To confirm that what you choosed EXIT Exit the menu TV/AV Input source selection FAV CH- Favorite program DOWN FAV CH+ Favorite program UP FAV ON/OFF Favorite program on/off CANCEL Remove the teletext &... -
Page 10: Inputs And Outputs
Your LCD TV has five types of video connections. You should capitalize on the best connection available from your LCD TV to get the best display quality. For example, if you have a progressive DVD player that supports a component video connection, you should connect the DVD player to your LCD TV using component video connections instead of composite video or S-video connections. -
Page 11: Osd Menu - Main Menu
1.1 Overview Menu Structure and Navigation Use the following keys to navigate through the main menu: Press the MENU key to invoke the main menu as shown. Use P-/P+ keys to select the main menu icon, the focused icon will be shown as a depressed button. Press the V-/V+ keys to go to the corresponding menu. - Page 12 Menu Icon Description Search Menu To adjust the TV search, including: Auto program, Search, Program Edit and Favorite Prog. Video Menu To adjust the video settings, including: Video mode, Color Temp, Contrast, Brightness, Colour, Sharpness, Hue and DNR. Audio Menu To adjust the audio settings, including: Audio mode, DynamicBass, Voice, AVC, Balance, Treble and Bass.
-
Page 13: Picture Menu
Picture Menu Using the SEARCH menu Press MENU and then use P-/P+ to select the search menu.(Input must be TV) 2 Press V+/ key to access the submenu 3 Use the P-/P+ to choose the Auto programme, search, Program edit, Favorite prog... - Page 14 Press MENU to return main menu Manual search In TV mode, select Manual search option and press V-/V+ to search programs within higher or lower frequency. Press to stop or press MENU to return previous menu during the searching process.
-
Page 15: Video Menu
Press V+/ to access the programme edit item Press V-/V+, P-/P+ to select program Press the Red button to delete selected program Press the Green button to copy selected program Press the Yellow button to move selected program Press the Blue button to skip selected program Press MENU to return previous menu Favorite Prog. -
Page 16: Color Temp
Press V+/ to access the color temp item Press P-/P+ repeatedly to choose Cool, Normal, Warm mode Press to return previous menu Press MENU to return main men Contrast Press V+/ to access the contrast item Press V-/V+ repeatedly to adjust the picture’s contrast Press to return previous menu Press MENU to return main men... -
Page 17: Audio Menu
This option is for adjust the back light 3 Audio Menu Using the Audio menu Press MENU and then use P-/P+ to select the Audio menu Press V+/ to access the submenu Use the P-/P+ to choose the Audio mode, DynamicBass, Voice, AVC, Balance, Treble, Bass Make the selections and settings as described in the following chapter You can exit the menu by pressing the EXIT button Basic Operation... - Page 18 Press to return previous menu Press MENU to return main menu This function is for controlling volume automatically Press V+/ to access the AVC item Press P-/P+ repeatedly to select AVC On/Off Press to return previous menu Press MENU to return main menu Balance Press V+/ to access the Balance mode...
-
Page 19: Using The Time Menu
On time item Press V-/V+ repeatedly to turn On time on or off. If selected on, Press V+/ adjustment then press P-/P+ to adjust the Clock value When you turn on TV next time Press to return previous menu... -
Page 20: Setting
Press V+/ to access the keypad lock item Press P-/P+ repeatedly to choose lock or unlock, When the keypad lock are locked you can not control the TV by press buttons on TV Press to return previous menu Press MENU to return main menu... -
Page 21: Basic Operation
Press V+/ to access the Blue Screen item Press P-/P+ repeatedly to set the blue screen to On or Off when there is No signal input Press to return previous menu Press MENU to return main menu OSD Transparent Press V+/ to access the OSD transparent item Press P-/P+ repeatedly to change OSD transparent Press... - Page 22 Manual config. (This is for VGA input only) Press V+/ to access the Manual config item Press P -/P+ to choose phase, Clock, H-position, V-position items Press V-/V+ to adjust picture’s horizontal position and vertical position Press to return previous menu Press MENU to return main menu VGA Mode (This is for VGA input only) This is for PC mode t...
-
Page 23: Pip
You can exit the menu by pressing the EXIT button Basic Operation Input Press V+/ to access the Input item Press P-/P+ to choose TV, AV, SCART1AV, SCART2AV, S-Video, YPbPr, VGA, HDMI1, HDMI2, HDMI3, SCART2YC Press to return previous menu Press MENU to return main menu... - Page 24 Press MENU to return main menu PIP Input Press V+/ to access the PIP Input item Press P-/P+ to select the PIP input source from TV, AV, SCART1AV, SCART2AV when you access the PIP mode Press to return previous menu Press MENU to return main menu Win.size...
-
Page 25: General Specifications
General Specifications Screen Size Resolution LCD Panel Display Color Aspect Ratio Video in S-VIDEO in Y / Pb/Cb / Pr/Cr Input/Output SCART in RGB Video + Audio in HDMI in Antenna input Audio Built-in speaker Color Temperature Compatibility Progressive Scan 3-2 pull down Color system SDTV/HDTV... -
Page 26: Rgb Frequency Table
The table below shows the frequency ranges supported by the LCD TV. It supports from VGA to XGA.If you are connecting your PC to the LCD TV via the RGB port, please use the following table in order to setup your PC’s VGA output for maximum optimization.
