Parts of your select™ sewing machine
24
25
22
23
26
16
17
1 M ain sw itch
2 Connection socket " foot control w ith
main cord"
3 H andw heel release disk
4 H andw heel
5 Carrying handle
6 Bobbin w inder
7 Lid w ith stitches
8 Extra spool pin
9 Spool pin w ith spool cap
10 Take-up lever
11 N eedle thread tension dial
12 Threading path
13 Thread cutter
14 Sew ing lamp (max. 15 w att)
15 Presser foot lifter
4
10
11
12
13
14
9
27 28
15
18
19
16 Removable accessory tray
17 Base plate
18 N eedle plate
19 Stitch length dial
20 Button for " reverse sew ing"
21 Stitch selection
22 N eedle threader (4.0)
23 Thread guide
24 IDT System / Integrated Dual Feed
(4.0/ 3.0)
25 N eedle holder w ith xing
screw
26 Presser foot holder w ith presser foot
27 Stitch w idth dial
28 N eedle position dial
8
7
6
20
21
5
4
3
2
1
