CKD9908 O/M.QXD
1/29/01
Thank You....................
for purchasing this Emerson AM/FM Stereo Clock Radio with Compact Disc
Player. In addition to waking to a buzzer alarm, or your favorite AM or FM Stereo
stations, you can also wake to the music of your favorite artists on compact disc.
There are dual alarms that can be set and used independently, a sleep to music
timer that controls both the radio and the CD player, and a Sure Alarm battery
back up system that will wake you to radio or buzzer, even if the power is out at
the wake up time. The large green LED display shows the time, alarm settings,
and CD track numbers, and it can be seen from anywhere in your room. The two
3" dynamic speakers provide excellent sound for such a compact unit. All major
controls are right on the top panel for simple, user-friendly operation.
Please read this manual completely to familiarize yourself with all the features of
your new CD clock radio, and save this manual for future reference. Your
warranty is on the back page of this manual.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE
THIS UNIT TO RAIN OR MOISTURE.
The serial number of your unit can be found on the bottom of the cabinet. We
suggest that you record the serial number in the space provided below in case
this information is ever needed at a future date.
Model Number:
Serial Number _______________________________________
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
2:43 PM
Page 1
CKD9908
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
DANGEROUS VOLTAGE
Uninsulated Dangerous Voltage, that may be of sufficient
magnitude to constitute a risk of electric shock to persons is
present within this product's enclosure.
ATTENTION
The Owner's Manual contains important operating and
maintenance instructions.
For your safety, it is necessary to refer to the manual.
DANGER:
Invisible and hazardous laser radiation when open and
interlock failed or defeated. Avoid direct exposure to beam.
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Emerson CKD9908
Summary of Contents for Emerson CKD9908
- Page 1 2:43 PM Thank You... for purchasing this Emerson AM/FM Stereo Clock Radio with Compact Disc Player. In addition to waking to a buzzer alarm, or your favorite AM or FM Stereo stations, you can also wake to the music of your favorite artists on compact disc.
-
Page 2: Safety Precautions
CKD9908 O/M.QXD 1/29/01 2:43 PM Page 2 SAFETY PRECAUTIONS FCC WARNING: This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the instruction manual. The user could lose the authority to operate this equipment if an unauthorized change or modification is made. -
Page 3: Location Of Controls
CKD9908 O/M.QXD 1/29/01 2:43 PM LOCATION OF CONTROLS 1. CD Compartment Door 2. WAKE (MUSIC/BUZZER) Switch 3. ALARM1 (OFF/ON) Switch 4. Battery Compartment (bottom of unit) 5. ALARM2 (OFF/ON) Switch 6. ALM.1 SET Button 7. ALM.2 SET Button 8. SLEEP Indicator 9. -
Page 4: Installation
CKD9908 O/M.QXD 1/29/01 2:43 PM Unravel the AC cord and connect it to a conveniently located AC outlet having 120V and 60Hz only. The Clock Display will illuminate and “12:00” will appear in the display. NOTE: If the AC plug does not fit into a nonpolarized outlet, do not file or cut the wide blade. -
Page 5: Operation
CKD9908 O/M.QXD 1/29/01 2:43 PM TO SET OR RESET THE ACTUAL TIME Press and hold the CLOCK button and the time will blink in the Display. AM (TIME) LED INDICATOR In the upper left corner of the Display is the AM LED indicator. When the AM LED indicator is lit, the actual or alarm time shown in the Display is AM hours. -
Page 6: Function Switch
CKD9908 O/M.QXD 1/29/01 2:43 PM TO SET THE ALARM TO WAKE TO RADIO Set the alarm time as previously instructed. Turn the unit on and slide the FUNCTION switch ST. or AM position. Select a radio station and make sure the VOLUME is set as desired. -
Page 7: To Set The Alarm To Wake To Buzzer
CKD9908 O/M.QXD 1/29/01 2:43 PM TO SET THE ALARM TO WAKE TO BUZZER Set the alarm time as previously instructed. Slide the desired ALARM switch (ALARM1 or ALARM2) ON position. Slide the WAKE switch to the BUZZER position. TO SHUT THE ALARM OFF... -
Page 8: Listening To The Radio
CKD9908 O/M.QXD 1/29/01 2:43 PM LISTENING TO THE RADIO Press the POWER button the unit on (the POWER indicator will light). Slide the FUNCTION switch to the desired band (FM. ST or AM). Hints for Better Reception FM - Make sure the FM Antenna wire is uncoiled and extended to its full length. - Page 9 CKD9908 O/M.QXD 1/29/01 2:43 PM PLAYING COMPACT DISCS - NORMAL PLAYBACK Remove the paper card from the CD Compartment before inserting a CD. Press the POWER button the unit on (the POWER indicator will light). Slide the FUNCTION switch to the CD position.
-
Page 10: To Begin Playback From A Specific Track
CKD9908 O/M.QXD 1/29/01 2:43 PM CD PAUSE CONTROL During CD playback, if you wish to pause the disc momentarily, press the PLAY/PAUSE ( ) button again. Playback stops but the disc continues to spin and the track number flashes in the Display. - Page 11 CKD9908 O/M.QXD 1/29/01 2:43 PM FORWARD/REVERSE SKIP TRACK AND HIGH-SPEED MUSIC SEARCH During playback, press SKIP/Search ( ) button once to advance the player to the beginning of the next track. Press the SKIP/Search ) button repeatedly to advance the player to higher number tracks.
-
Page 12: Repeat Playback
CKD9908 O/M.QXD 1/29/01 2:43 PM REPEAT PLAYBACK To repeat a single track, press the REPEAT Button once. The Repeat indicator will blink. Press the SKIP/Search ( ) or ( to select the specific track that you wish to repeat. When the desired track... - Page 13 CKD9908 O/M.QXD 1/29/01 2:43 PM TO PROGRAM THE MEMORY (UP TO 20 TRACKS) Programming is the ability to preselect the order in which a series of tracks will be played. Turn the unit on and slide the FUNCTION switch to the CD position.
-
Page 14: To Activate The Sleep Function
CKD9908 O/M.QXD 1/29/01 2:43 PM TO ACTIVATE THE SLEEP FUNCTION Tune the desired radio station or insert a CD as previously instructed. Page 14 OPERATION Press the SLEEP button twice, “90” will appear on the display and the SLEEP indicator will light indicating the unit will play for 90 minutes and then shut off. -
Page 15: Care And Maintenance
CKD9908 O/M.QXD 1/29/01 2:43 PM CARE AND MAINTENANCE Caring for Compact Discs • Treat the disc carefully. Handle the disc only by its edges. Never allow your fingers to come in contact with the shiny, unprinted side of the disc. -
Page 16: Troubleshooting Guide
CKD9908 O/M.QXD 1/29/01 2:43 PM TROUBLESHOOTING GUIDE If you experience a problem with this unit, check the chart below before calling for service. SYMPTOM Unit will not AC cord not turn on. connected. Disc will not play. CD compartment not closed. - Page 17 CKD9908 O/M.QXD 1/29/01 2:43 PM Page 17 CARE AND MAINTENANCE If the cabinet becomes dusty, wipe it with a soft cloth. If the cabinet becomes smudged or dirty, clean it with a soft, slightly dampened cloth. Never allow water or any liquid to get inside the cabinet. Never use any abrasive cleaners or cleaning pads as these will damage the finish of your radio.
-
Page 18: Limited Warranty
CKD9908 O/M.QXD 1/29/01 2:43 PM What does this warranty cover? Any manufacturing defects in original material, including original parts and workmanship, under normal use and conditions. For how long? For a period of ninety (90) days from the date of original purchase in the U.S. - Page 19 CKD9908 O/M.QXD 1/29/01 2:43 PM Page 19 ® EMERSON PART NO.: 16-2810 011-01 Printed in China...
- Page 20 CKD9908 O/M.QXD 1/29/01 2:43 PM Page 20 ® STEREO CLOCK RADIO COMPACT DISC PLAYER OWNER’S MANUAL CKD9908 Visit our web site at www.emersonradio.com...
