Booth BAR3 Product Manual

Shelf mounted beer coolers
Hide thumbs Also See for BAR3:

Advertisement

Quick Links

Product Manual
BAR3
Shelf Mounted Beer Coolers
Part Number 3B6694 Issue C

Advertisement

loading
Need help?

Need help?

Do you have a question about the BAR3 and is the answer not in the manual?

Questions and answers

Related Manuals for Booth BAR3

Summary of Contents for Booth BAR3

  • Page 1 Product Manual BAR3 Shelf Mounted Beer Coolers Part Number 3B6694 Issue C...

  • Page 2: Table Of Contents

    Schematics Introduction The BAR3 is an ice bath cooler designed to provide chilled product in a dispense application. The system uses a bath water recirculation system and python to generate and maintain optimum drink temperature at the point of dispense.

  • Page 3: Specification & Installation

    Specification and Installation Specification BAR300 Dimensions Compressor 570mm(W) Tecumseh 450mm(D) THB4422Y 280mm(H) Dry Weight 24kg This product contains R134a Refrigerant gas with a GWP of 1430 in an hermetically sealed system Wet Weight 39kg Supply 230Vac/50Hz Refrigerant R134a 145g Rated Input 400W Climatic Class Rated Current...
  • Page 4 Specification and Installation  Connect the dispense python to the ‘Recirculation’ Flow and Return.  Connect the product to the stainless steel product coil.  BAR3H - For details on how to install Tube in Tube/Scope dispense, please contact Brandels at http://www.brandels.co.uk/.

  • Page 5: Model Numbering Convention

    Model Numbering Convention Unit number BAR3(Z) ( Y ) ( X ) ( W ) Key: Refrigerant Type Pump Type Module Type Deck Number of coils - - - Coil type and number of coils repeated as necessary Reference Part #...

  • Page 6: Schematics

    Schematic BAR3H & BAR300 Eliwell Wiring Schematic...
  • Page 7 Schematic BAR3H & BAR300 DFX Wiring Schematic...
  • Page 8 Schematic BAR3H & BAR300 Mechanical Wiring Schematic...

  • Page 9: Fault Finding

    Fault Finding Prior to any fault finding, please ensure all connections to the chiller are sound and that the incoming supply is turned on. Also ensure that all electrical connections to the chiller and in the chiller are secure and in good condition, the power is on and that the chiller has had adequate time to reach operating temperature NOTE: Isolate from mains before removing any panels Water supply...

  • Page 10: Spare Parts

    Spare Parts BAR300 Spares 1A5362 1A5361 Eliwell Control Module Mechanical 1A6310 Control Module DFX Control Module Pump 1B5514 Refer to table Cooling Fan on Page 5...
  • Page 11 Spare Parts BAR3H Spares 3B6090 Coaxial Elbow INSU77 1A5362 Polar Clean Eliwell Control Module Elbow 1A6310 DFX Control Module 1A5361 Mechanical Control Module 1B5514 Pump Cooling Fan Refer to table on Page 5...

  • Page 12: Removal, Transportation

    It is illegal to simply scrap a refrigeration unit. Before a unit can be scrapped it must first have the gas removed by a specialist using specialist equipment. Please contact Booth Dispensers Ltd., who will be happy to provide a quotation for disposal.
