- Page 1 Safety Dolly/ Shuttle Dolly INSTRUCTION MANUAL For Technical Support, Call 770-974-0021 888-SAWTRAX (888-729-8729) Watch a video of configuring and moving a load at: https://vimeo.com/249200637...
- Page 2 PARTS OF THE yel-Low SAFETY DOLLY Page 2...
- Page 3 When unpacking, CHECK TO MAKE SURE THAT THE DOLLY IS INTACT / UNDAMAGED and that all ordered parts are included. If any parts are missing or broken, please call Saw Trax Manufacturing as soon as possible at 770-974-0021. IMPORTANT WARNINGS AND SAFETY PRECAUTIONS 1.
- Page 4 IMPORTANT WARNINGS AND SAFETY PRECAUTIONS (Continued) SUGGESTIONS FOR SAFEST AND EASIEST USE Plan and prepare for the job before attempting to load the dolly • Be sure the Dolly can handle your load's weight and size (base model: 1000 lbs. max); do not overload dolly •...
- Page 5 OPERATING THE yel-Low SAFETY DOLLY 1. The yel-Low Safety Dolly is extremely easy to use. Place posts into the support holes around the dolly into a configuration that works for you. It is completely customizable. (Optional post lengths available) 2. Positionable posts can also be placed horizontally to give you more base area for longer/wider loads.
-
Page 6: Helpful Features
OPERATING THE yel-Low SAFETY DOLLY (Continued) Simply load up your product and you are ready to go. HELPFUL FEATURES OMNI DIRECTIONAL CASTERS 4-inch omni-directional casters (base model) allow the load to be moved in any direction. This allows for exceptional maneuverability even in the tightest of spaces, around corners and through cluttered walkways. -
Page 7: Optional Upgrades
HELPFUL FEATURES (Continued) These omni-directional casters are protected inside the dolly body on the base model. NO TIPPING OVER The dolly will not fall over if misloaded because of the casters hidden inside the dolly body. Instead of falling over, it just tilts and rests on the bottom sides. - Page 8 BRAKES For stabilization, toggle brake clamps can be mounted to the exterior of low the 4" caster dolly body. Sold in pairs. CORNER PROTECTORS/CONNECTORS Prevents the corners from gouging a wall, especially handy in hotels and office buildings. Also can be used when connecting two or more dollies. DOCK TRANSITION WHEELS Used for taking the low 4"...
- Page 9 FORKLIFT CHANNELS Lift your dollies into trucks and onto shelves. Exclusively for the Raised yel-Low Safety Dolly. (1 Channel per cart. Minimum order of 2) Available in 25" and 30" Channels. *Not applicable to Shuttle Dolly* Call us or visit https://www.sawtrax.com/product/yel-low-safety-dolly/ for more information...
- Page 10 THE SHUTTLE DOLLY This larger version of the yel-Low Safety Dolly has a wider base and increased carrying capabilities. Having a base of 29 in. x 36 in. Base Shuttle THE FULFILLMENT SHUTTLE With the wheelbarrow handles, loads can be transported without touching the product. Instead of turning a loaded dolly around in a confined space, the wheelbarrow handles can be removed and inserted from the other end.
- Page 11 INSTALLING OPTIONAL ADDITIONS (Raised Casters) Required Materials Red Swivel Locking Caster Yellow Caster Support Bracket 5/16in. Carriage Bolt 5/16in. Flat Washer 5/16in. Lock Washer 5/16in. Lock Nut 5/16in. Hex Nut Required Tools Ratchet with Deepwell ½ in. drive socket. Assembly Procedures: 1.
- Page 12 INSTALLING OPTIONAL ADDITIONS (Dock Transition Wheels) Dock Transition Wheels: Used to transition the dolly on uneven surfaces like dock transitons to load trucks. Comes with 2 wheels per opposite ends of the dolly. A 5th red swivel caster will be added to the center of the dolly body.
- Page 13 Figure 1 Figure 2 Figure 3 Revised 08/05/2020. For information on the compatibility of the yel-Low Safety Dolly with any products introduced after this date, contact Saw Trax. yel-Low Safety Dolly Instruction Manual © SAW TRAX MFG. 2020 Page 13...
- Page 14 Saw Trax Mfg., Inc. sells through distributors. The specifications listed in Saw Trax Mfg., Inc. printed materials and on the official Saw Trax Mfg, Inc. website are given as general information and are not binding. Saw Trax Mfg, Inc. reserves the right to effect at any time, without prior notice, those alterations to parts, fittings, and accessory equipment which they may deem necessary for any reason whatsoever.
