- Page 1 Dolly Max INSTRUCTION MANUAL For Technical Support, Call 770-974-0021 888-SAWTRAX (888-729-8729) Watch a video of configuring and moving a load at: https://vimeo.com/197531705...
- Page 2 PARTS OF THE DOLLY MAX Page 2...
- Page 3 When unpacking, CHECK TO MAKE SURE THAT THE DOLLY IS INTACT / UNDAMAGED and that all ordered parts are included. If any parts are missing or broken, please call Saw Trax Manufacturing as soon as possible at 770-974-0021. IMPORTANT WARNINGS AND SAFETY PRECAUTIONS 1.
- Page 4 IMPORTANT WARNINGS AND SAFETY PRECAUTIONS (Continued) SUGGESTIONS FOR SAFEST AND EASIEST USE Plan and prepare for the job before attempting to load the dolly • Be sure the Dolly can handle your load's weight and size (base model: 700 lbs. max); do not overload dolly •...
- Page 5 OPERATING THE DOLLY MAX 1. The Dolly Max uses positionable posts to configure the dolly the way you need it. There are 10 vertical post positions on top and 6 horizontal post position to increase surface area. The horizontal post have 4 possible positions in the front/back and 2 positions on the sides.
-
Page 6: Helpful Features
3. The Dolly Max has large 12.25" foam filled tires which never go flat and allow the dolly to maneuver over various surfaces. Push with foam filled tires forward. HELPFUL FEATURES Weight Capacity Upgrade The standard Dolly Max comes with two front locking casters. - Page 7 ASSEMBLY (Foam Filled Tire Installation) Required Materials 12.25 in. Foam Filled All-Terrain Tire Axle – 26 in. with 4 drilled holes 5/8 in. Flat Axle Washer Cotter Pin Required Tools Swivel Board, Channel Lock Pliers (2) 1. Insert Axle into axle hole on either side of Cart Body and one (1) 12.25 in. Foam Filled All-Terrain Tire.
- Page 8 4. Repeat steps 2 and 3 for the remaining Blue Locking Swivel Caster. Revised 07/31/2020. For information on the compatibility of the Dolly Max with any products introduced after this date, contact Saw Trax. Dolly Max Instruction Manual © SAW TRAX MFG. 2020...
-
Page 9: Warranty And Service
Saw Trax Mfg., Inc. sells through distributors. The specifications listed in Saw Trax Mfg., Inc. printed materials and on the official Saw Trax Mfg, Inc. website are given as general information and are not binding. Saw Trax Mfg, Inc. reserves the right to effect at any time, without prior notice, those alterations to parts, fittings, and accessory equipment which they may deem necessary for any reason whatsoever.
