INSTRUCTION MANUAL
xSync Board / ELMO Board
EL55R2/EL65R2/EL75R2/EL86R2
Ver.01
Read this manual carefully before using the product.
Store this manual in a safe place in case you need it again.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EL55R2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Elmo EL55R2

  • Page 1 INSTRUCTION MANUAL xSync Board / ELMO Board EL55R2/EL65R2/EL75R2/EL86R2 Ver.01 Read this manual carefully before using the product. Store this manual in a safe place in case you need it again.
  • Page 2: Table Of Contents

    ◆ Screen Description ....... 42 ◆ Home Screen ........ 20 ◆ Popup Display Settings ....44 ◆ Shortcuts of Apps ......21 Using ELMO Timer Function ..45 ◆ Uninstallation of Apps ....22 ◆ Startup .......... 45 ◆ Connection Status Icons on the ◆...
  • Page 3 ◆ Initial Startup ........ 54 Specifications ........ 85 ◆ Basic Operations ......54 Product Specifications ....85 Using ELMO Play ......55 ◆ Startup .......... 55 After-Sales Service ......87 3.10 Using File Manger Function ..56 Product Warranty ......87 ◆...
  • Page 4 ・If the display requires replacement parts, make sure the service technician uses replacement parts specified by ELMO or parts with the same characteristics as the original. ・Ensure that any cables that cross the floor to the display are properly bundled and marked to avoid a trip hazard.
  • Page 5 For additional requirements and other information, refer to the display’s specifications. Federal Communication Commission interference statement Suppliers Declaration of Conformity 47 CFR § 2.1077 Compliance Information Unique Identifier: EL55R2, EL65R2, EL75R2, EL86R2 Responsible Party – U.S. Contact Information ELMO USA CORP. 6851 Jericho Turnpike, Suite 145 Syosset, NY 11791 This device complies with Part 15 of the FCC Rules.
  • Page 6 ・It is prohibited under copyright law to use or copy any part or the whole of this document without our prior written consent. ・ELMO shall not be liable for any claim for damage or loss of earnings or any claim raised by a third person due to the use, malfunction or repair of this product.
  • Page 7: Before Use

    Before Use 1.1 Package Contents The items below are included with this product. If any item is missing, contact the dealer from whom you purchased this product. Display monitor Remote control Touch pen x2 Power cord x3 (3m) Eraser (TypeA/TypeC/TypeBF) USB cable ※TypeB-TypeA (3m) HDMI cable (3m)
  • Page 8: Part Names And Functions

    1.2 Part Names and Functions Front Operating panel Front I/O ports Operating panel Mark Name Function IR receiver IR receiver for the remote control. Power LED To indicate the power status. On: Green Off: Red Power Long press: To turn on or off the power. Short press: To enter or cancel the standby mode.
  • Page 9: Side And Bottom

    OPS slot Handle Handle connection position Power supply socket Side I/O ports AC-IN Main power switch EL55R2・EL65R2:Located to the side of the power supply socket EL75R2・EL86R2:Located in the bottom Bottom I/O ports 12 11 Side I/O ports Name Function LAN(RJ-45)...
  • Page 10: Touch Pen And Eraser

    You can perform touch operations using the supplied Touch pen. With ELMO Note, it is possible to make different settings for the thi ck pen nib and the thin pen nib and draw different lines. Drawn lines can be deleted with the Eraser. (⇒P.28)...
  • Page 11: Remote Control

    To move the selection item up, down, left, and right. Return button To go back to the previous screen. To start the whiteboard app (ELMO Note).(⇒P.25) Whiteboard button 10 Screenshot button To capture the currently displayed screen and save it.
  • Page 12: Preparation

    ◆ Preparation ◼ Inserting batteries 1. Slide and open the cover in the back of the remote control. 2. Insert 2pcs of AAA batteries. Pay attention to the polarity, which is printed inside the remote control. 3. Firmly close the cover. Use manganese AAA batteries for the batteries.
  • Page 13: Installation

    If you want to mount the display monitor on a wall or suspend it from the ceiling, ⚫ ask a specialist for installation work. ELMO is not responsible for any accident or damage caused by improper installation. If you need to move the display monitor after it is attached to the stand, always ⚫...
  • Page 14: Attachment Of The Display Monitor To The Stand

    ◆ Attachment of the Display Monitor to the Stand You can attach the display monitor to the stand. The positions of the screw holes are as shown in the following figure. For the assembly of the stand, refer to the instruction manual of the stand. 55 inch:VESA 400x400 65 inch:VESA 600x400 75 inch:VESA 800x400...
  • Page 15: Turning On Or Off The Power

    Use the power cord usable in your country. ⚫ Turning On the Power Press “-“ on the Main power switch on the bottom. Location of the Main power switch: For EL55R2 and EL65R2: Side For EL75R2 and EL86R2: Bottom Main power switch EL55R2・EL65R2 EL75R2・EL86R2...
  • Page 16: Initial Startup

    ◆ Initial Startup At initial startup, the Settings screen will appear in the order of "Language setting", "Date and time setting", and "Network setting". Settings after "Language setting" can be skipped by tapping "Skip and start immediately" or “Next". To go back to the To go to the next page previous screen To skip all subsequent steps and...
  • Page 17: Turning Off The Power

    Network setting To configure the wired network settings To configure the wireless network (wireless LAN) settings For the Network setting, set either Wireless network or Ethernet. ⚫ Note If you want to set the proxy in the Wireless network settings, or if yo u want to ⚫...
  • Page 18: Standby Mode

    Select “Sure” in the Shutdown confirmation dialog. Select “Cancel” if you want to cancel the shutdown. Press “〇“ on the Main power switch on the bottom. If there is no operation after the Shutdown confirmation dialog is displayed ⚫ Note and the countdown timer reaches zero, the product will automatically shut down.
  • Page 19: Basic Operations

    Basic Operations 2.1 Touch Operations You can perform touch operations with your finger or the supplied Touch pen. For details on Windows touch operations, refer to Windows Help. Name Function Finger movements Touch once briefly. Single tap Works as the left click of a ⚫...
  • Page 20: Basic Screen Operations

    Tap the List of apps icon at the bottom right of the screen to display a list apps installed on the product. Main Apps Icon Name Function To start ELMO Note (whiteboard). (⇒P.25) ELMO Note To start Camera Roll. (⇒P.38) Camera Roll To start a USB camera. (⇒P.40) ELMO Camera To start E Browser.
  • Page 21: Shortcuts Of Apps

    ◆ Shortcuts of Apps You can add, delete, or change the position of app icons (app shortcuts) on the H ome screen. You need to set “Allow home screen editing” in the Security Settings to ON before Note editing the app icons. Settings >...
  • Page 22: Uninstallation Of Apps

    ◆ Uninstallation of Apps Long-press the app icon that you want to uninstall on the Home screen. A popup of “Uninstall app” will appear. Tap “Uninstall app”. A confirmation dialog box will appear. Tap “OK”. The app will be uninstalled from the product.
  • Page 23: Connection Status Icons On The Home Screen

    ◆ Connection Status Icons on the Home Screen The icons displayed at the top right of the Home screen provide information about the status of the network connection of the product. Icon Name Function This icon appears when the product is connected with OPS (sold separately).
  • Page 24: Displaying The Side Menu Bar

    Press “CLEAR ALL” to close all ⚫ the tasks. To start the Overlay app.(⇒P.37) Overlay To start ELMO Note (whiteboard).(⇒P25) ELMO Note To start E Browser.(⇒P.42) E-Browser To start a USB camera.(⇒P.40) ELMO Camera To start pre-installed utilities.
  • Page 25: Using Apps

    Tap the ELMO Note icon in the list of apps or the side menu bar. ◆ Initial Startup When you start ELMO Note or Overlay app for the first time, the initial settings screen will appear. Enable "Accessibility Permission" and "Storage Permission" settings before start.
  • Page 26: Basic Operations

    Tap “START ELMO NOTE” after completing all the settings. ◆ Basic Operations Drawing lines and shapes Tap the Pen icon and trace on the screen When the Pen icon is double-tapped, you can change the line color and thickness.(⇒ with your finger or Touch pen.
  • Page 27: Screen Description

    Tap this icon again to show the toolbar. To start the Camera Roll app. 15 Camera Roll Images and videos can be attached to ELMO Note. (⇒P.38) To start the ELMO Camera app. (⇒P.40) 16 USB camera To enlarge the area selected by dragging operation.
  • Page 28: Pen Menu

    ◆ Pen Menu The Pen menu will appear when the Pen icon in the toolbar is tapped again in the Pen mode. Name Function Normal pen To draw with a normal pen. Instruction pen To draw lines that will disappear in 3 seconds. Paint brush To draw with a pen with a vertical rectangular nib.
  • Page 29: Eraser Menu

    ◆ Eraser menu The Eraser menu will appear when the Eraser icon in the toolbar is tapped again in the Eraser mode. Name Function To delete a portion of the drawing touched by the Eraser icon. Normal eraser There are 3 different sizes of icons available: Small, Medium, Large To delete a portion of the drawing touched by your finger while Partial eraser dragging on the screen.
  • Page 30: Shapes Menu

    ◆ Shapes Menu The Shapes menu will appear when the Shapes icon in the toolbar is tapped again in the Shapes mode. Name Function 2D・3D To switch between 2D and 3D for the shape. Line To select the color of the line. Fill To select the color of the shape.
  • Page 31: Background Menu

    ◆ Background Menu The Background menu will appear when the Background icon in the toolbar is tapped. Name Function To select the background. Background Tap any background design to change the background. To select the color of the background. Fill You can also select the color from the color palette.
  • Page 32: Page Operation Menu

    ◆ Page Operation Menu The Page operation menu will appear when the icon [ x /y ] in the toolbar is tapped. Up to 5 pages are displayed as thumbnails at the same time. If there are more than 6 pages, you can switch the display by scrolling the menu with a swipe action.
  • Page 33: Functions Available When Selecting An Object

    ◆ Functions Available When Selecting an Object Tap the Select icon in the toolbar to select an object (shape, image, and video). Name Function To copy the selected object. The Paste icon will appear when any part of the screen other Copy than the object is tapped.
  • Page 34: Menu Operations

    ◼ Video Object Operations Tap the Operation icon in the toolbar to operate a video object. Video in pause mode Video in playback mode Name Function To play the video. The Playback mode and the Pause mode can be Playback / switched by tapping on the video object.
  • Page 35: Split Screen Mode

    ◆ Split Screen Mode In the Split screen mode, two or three users can draw or delete lines at the same time. Tap the Split screen icon in the menu. A dialog box will appear. Select “Two split screen” or “Three split screen” and tap “OK”.
  • Page 36: Saving Images

    The saving process may fail when saving a large amount of data that exceeds ⚫ 10 pages in PDF format. If ELMO Note is closed unexpectedly, restore the data and save it again, or save it in another format. When USB flash drive is selected as the save destination , the image data will ⚫...
  • Page 37: Using Overlay Function

    When toolbar is displayed When toolbar is hidden (in the Operation mode) Name Function Operation Same functions as ELMO Note (whiteboard) are available. functions Refer to page P.27 for details. To capture and save the screen image. Screenshot The captured screen image will be saved in the Camera Roll folder in png format.
  • Page 38: Using Camera Roll Function

    3.3 Using Camera Roll Function You can display saved images and videos in a list to compare them or paste to ELMO Note. ◆ Startup Tap the Camera Roll icon in the list of apps. ◆ Screen Description Name Function To upload images and videos to Cloud.
  • Page 39: Comparing Images And Videos

    ◆ Pasting to ELMO Note (whiteboard) Select images and videos and tap the ELMO Note icon. ELMO Note (whiteboard) will start and the selected images and videos will be pasted. Up to 2 videos can be pasted to ELMO Note.
  • Page 40: Using A Usb Camera

    ◆ Startup Tap the ELMO Camera icon in the list of apps or the side menu bar. ◆ Screen Description Tap the icon either at the bottom right of bottom left of the screen to display the menu bar.
  • Page 41: Usb Camera Settings Screen

    To record when using the Overlay app (⇒P.37), use the Screenshot icon on ⚫ the overlay toolbar or the Screenshot button on the front of the display monitor. In rare cases, the ELMO Camera app may freeze when the USB camera is ⚫ disconnected. In that case, restart the app.
  • Page 42: Viewing Web Page (E Browser)

    3.5 Viewing Web Page (E Browser) You can view web pages with E Browser. An Internet connection is needed to view web pages. ◆ Startup Tap the E Browser icon in the list of apps or the side menu bar. ◆...
  • Page 43 〈Menu〉 Name Function To go back to the previous page. Back To go to the next page. Next To update the page being viewed. Refresh New tab To open a new tab. Bookmarks To display, edit or delete a list of bookmarks. Recent tabs To display or delete the history of tabs.
  • Page 44: Popup Display Settings

    ◆ Popup Display Settings When playing video content, a notification pop-up may appear at the bottom right of the screen. To hide this pop-up, turn off the setting “Show notifications”. Notification popup Tap “Settings” in the E Browser menu. Tap “Notifications”. Turn off the setting “Show notifications”.
  • Page 45: Using Elmo Timer Function

    3.6 Using ELMO Timer Function The ELMO timer has a timer function and a stopwatch function. ⚫ With the timer function, multiple timers and tasks can be set. ⚫ With the stopwatch function, a lap recording is possible. ◆ Startup Tap the Timer icon in the list of apps.
  • Page 46: Creating Tasks Using Timer

    ◆ Creating Tasks using Timer Perform the steps 1 to 3 described in "Basic Operation (Timer)". Tap the title of the created timer in the Timer List screen. Tap the icon “ + “ in the Task List screen to create a new task. In the Timer settings screen, set the time for the task and save the timer setting.
  • Page 47 ◼ Maximizing or Minimizing the Screen Maximizing the screen:Press to maximize the screen. Press to return the screen to normal size. Minimizing the screen:Press to minimize the screen. Press to return the screen to normal size.
  • Page 48: Timer List Screen

    Change title To change the title of the selected timer. Delete timer To delete the selected timer. Exit To end the ELMO timer app. Minimize screen To minimize the timer screen.(⇒P.50) To display the Stopwatch screen.(⇒P.50) Stopwatch Maximize To maximize the timer screen.
  • Page 49: Task List Screen

    ◆ Task List Screen Name Function Create new task To create a new task. The Timer settings screen will appear. Edit task To edit the selected task. The Timer settings screen will appear. Return To go back to the Timer List screen. Delete task To delete the selected task.
  • Page 50: Minimizing The Screen

    To reset the timer to the start time. Maximize To maximize the screen. screen Exit To end the ELMO timer app. ◆ Stopwatch Screen Name Function Start / Stop To start the stopwatch. Tap this icon again to stop the stopwatch.
  • Page 51: Using Wireless Casting Function(Transcreen

    3.7 Using Wireless Casting Function(Transcreen) You can do mirroring of the screen of a device such as a computer, tablet, and smartphone to the display monitor of the product. ◆ Preparation Connect a device such as a tablet to the network and install the Transcreen app. For iOS (iPhone or iPad) and MacOS, mirroring is possible without installing the Transcreen app.
  • Page 52: Using On Windows Os

    ◆ Using on Windows OS Tap the Screen Mirror icon in the list of apps. Start the Transcreen app installed on the Windows device. Select the device name of the product and tap “Start Mirroring”. The screen of the connected device will be displayed on the display monitor of the product.
  • Page 53: Using On Chrome Os

    ◆ Using on Chrome OS Tap the Screen Mirror icon in the list of apps. Start the Transcreen app installed on the Chrome device. Select the device name of the product and tap “Connect”. Tap “Share Screen”. Select the screen you want to display and tap “Share”. The screen of the connected device will be displayed on the display monitor of the product.
  • Page 54: Using Anti-Virus Function (Avira Security)

    Tap the “Performance” tab, and then tap “Optimizer” to perform a cleanup of the internal memory. ① ② Items marked with are paid content. If you Note would like to use it, contact the dealer from whom you purchased the product or the nearest ELMO sales office.
  • Page 55: Using Elmo Play

    3.9 Using ELMO Play With ELMO Play, you can download apps from the ELMO portal site and add various useful functions to the product. (Paid content is also available.) ◆ Startup Tap the ELMO Play icon in the list of apps.
  • Page 56: Using File Manger Function

    ⚫ ZIP file:zip ⚫ App:apl ⚫ The xod file (ELMO Note) will be displayed in the category of "Whiteboard" in future version upgrades. To select the location to read files from. Local:Files stored in the product will be displayed. ⚫...
  • Page 57 Name Function To select a file when is displayed. File select mode The File Manager app will enter the File edit mode when this icon is tapped. (⇒P.57) Remove USB flash To remove the USB flash drive safely by tapping drive 11 Exit To end the File Manager app...
  • Page 58: Cloud Account Settings

    ◆ Cloud Account Settings If you are using Cloud for the first time or if you want to add a Clo ud account to the product, use "Browser" to set the authentication. Tap the Settings icon in the list of apps. Tap “Application”, and then tap “Application List”.
  • Page 59 Select “Google Drive” or “One Drive”, then login (authentication process) to it. Login screen Login screen (Google Drive) (One Drive) If the following dialog box appears when you login to your account, tap “Advanced” and then tap “Go to File Manager (unsafe)”. ①Tap “Advanced”.
  • Page 60: Uploading Files To Cloud

    ◆ Uploading Files to Cloud Open the File Manager and select a file to upload to Cloud. Tap the Cloud icon after selecting a file. The Login screen will appear. Select the account and go to the cloud folder. Tap “Confirm” to start the upload. ①...
  • Page 61: Using Utilities Function

    3.11 Using Utilities Function You can use pre-installed utilities. ◆ Startup Tap the Utilities icon in the side menu bar. ◆ Screen Description Name Function To display a list of utilities. Utilities Tap each icon to start the respective utility. To adjust the audio volume by moving the slider left or right.
  • Page 62: Using With External Devices

    Using with External Devices You can display the live image being output from the document camera or computer on the display monitor, or play the audio of the product through an external speaker. 4.1 Connecting Devices ◆ Displaying the Computer Screen (Video and Audio) ◼...
  • Page 63 ◼ Connecting via HDMI(Use the ports on the side) HDMI cable (supplied) HDMI in USB cable (supplied) ⚫ Depending on the OS of the computer, you may not be able to operate the Note computer even if you touch the display monitor connected to the computer via USB Type-C.
  • Page 64 ◼ Connecting with VGA cable and Audio cable If you connect the VGA in port on the bottom of the display monitor and the VGA out port of the computer with a VGA cable, the computer screen will appear on the display monitor. If you connect the Audio in port on the bottom of the display monitor and the Audio out port of the computer with a stereo mini audio cable, the computer audio will be played through the display monitor.
  • Page 65: Controlling The Product From A Computer (Serial Control)

    Note that not all functions can be controlled. LAN cable (commercially available) LAN cable LAN cable (commercially available) (commercially available) For information about commands used for RS-232C and LAN control, contact ⚫ Note the dealer from whom you purchased the product or the nearest ELMO sales office.
  • Page 66: Displaying The Screen Of The Connected Device (Video And Audio)

    ◆ Displaying the Screen of the Connected Device (Video and Audio) ◼ Connecting via HDMI If you connect the HDMI in port on the front or side of the display monitor and the HDMI out port of the device with the supplied HDMI cable, the image being output from the device will appear on the display monitor and the audio will be played through the display monitor.
  • Page 67: Operation

    Switching the Input Source You can switch the input source connected to the product. ◆ Operation Tap the Menu icon in the list of apps or the side menu bar. Tap “Source Preview”. You can also switch between screens by directly tapping the Note input source name such as VGA, OPS, HDMI1 displayed on the Source Settings screen.
  • Page 68: Configuring The Source Settings

    ◆ Configuring the Source Settings Tap “Admin Setting” and enter the administrator password. The default password is 0000000 (7 digits). The Source Settings menu will appear. ~ Name Function Video Quality To set the brightness, contrast, and color tone of the input video. (*You cannot configure the screen settings of an Android device with this menu item.) You can select this menu item from "Menu"...
  • Page 69 Name Function HDMI CEC To turn on or off the CEC function of HDMI. ●Default setting: ON (This setting item is available only when the HDMI image is displayed on the display monitor.) Auto Adjust To automatically adjust the display position of the VGA image. (This setting item is available only when the VGA image is displayed on the display monitor.)
  • Page 70: Configuring The Settings

    Configuring the Settings ◆ Startup Tap the Settings icon in the list of apps. ◆ Before Configuring the Settings To configure various settings, you need to enter the administrator password. Tap the Settings icon in the list of apps. Tap “Admin Setting” and enter the administrator password. Note The default password is 0000000 (7 digits).
  • Page 71 ◼ Configuring the Wireless Network (Wi-Fi) Settings (with the Settings App) Tap the Settings icon in the list of apps. Tap “Network and Connection” and tap “Wireless”. Set the slide switch to ON. Select the network to connect. Enter the password for the network device and the product will be c onnected to the device.
  • Page 72 Set the slide switch for “Use Wi-Fi” at the top right of the screen to ON. A list of available network connections will appear. Scroll down the list and tap “Add network”. Add the network. ネットワークを追加 Enter the setting items, and then tap “SAVE”. Enter the Tap “SAVE”...
  • Page 73 Tap “Network and Connection” and tap “Ethernet”. Set the slide switch to ON. Tap “IP settings” and set it to “Static” to configure the Ethernet settings manually. Consult with your network administrator for details of the network settings. ⚫ Note If you use Wireless connection, Ethernet connection will be disabled.
  • Page 74 ◼ Configuring the HotSpot Settings You can use the product as a hotspot to connect wireless devices. Tap “Network and Connection” and tap “Hotspot”. Set the slide switch to ON. Configure the settings of the device to be connected. Select “Wi-Fi” in the settings menu of the connected device. Look for the access point with the name indicated in “Hotspot Name”...
  • Page 75: System Settings

    ◆ System Settings ◼ Wallpaper Name Function Add wallpaper To start the File Manager app. You can add a wallpaper by selecting a file. You can select files with the extension jpg and png. Wallpaper To change the wallpaper at set intervals. shuffling The interval can be set at 1 minute, 10 minutes, 30 minutes, 1 hour, or 6 hours.
  • Page 76 ◼ Date and Time Name Function Automatically To set whether or not to use the date and time information determine date and provided by the network. time Manually Set Date and To set the date and time of the system manually when Time "Automatically determine date and time”...
  • Page 77 ◼ Power Settings Name Function Power-on Mode To select the startup mode from "Power-on", "Power-on Standby", and "Power-on Memory". ●Default setting: Power-on Power-on by Alarm:To set the time when the power is Timer for Power On/Off automatically turned on. Power-off by Alarm:To set the time when the power is automatically turned off.
  • Page 78 ◼ Device Information Name Function Update To update the firmware via the network. Device Name To display the device name of the product. Tap the device name to change it. Information To display various information of the product. Restore factory settings To reset the product to the factory default settings. The internal memory will be deleted after the reset.
  • Page 79 ◼ Others (Lock settings) Name Function Remote Lock To set whether or not to disable the remote control operation. ●Default setting: OFF This setting will be set to OFF when the product is restarted. Touch Lock To set whether or not to disable the touch operation. ●Default setting: OFF This setting will be set to OFF when the product is restarted.
  • Page 80: Optional Item

    Optional Item 6.1 Easy Controller By using the optional Easy Controller, you can do basic operations such as draw and erase with the buttons. Install the Easy Controller to the right side of the display monitor. Clamps If you want to install the Easy Controller to the left side of the display monitor, rotate the clamps (2 pcs) 180 degrees.
  • Page 81: Easy Controller Buttons

    To capture the currently displayed screen and save it as a Screenshot still image. Utilities To start the shortcut of the app. Operation button, Pen button, Eraser button, Select button, Shapes button, Note Enlarge button, Undo button, and Redo button are used in ELMO Note and the Overlay app.
  • Page 82: Troubleshooting And Maintenance

    Troubleshooting and Maintenance 7.1 Troubleshooting ◆ The product does not operate properly. Symptom Check points and Countermeasures Check if there is an obstacle between the remote control and the receiver, preventing infrared rays from reaching. Operate the remote control toward the receiver. The remote control does not work properly.
  • Page 83: No Audio Is Output From The Speaker

    ◆ No audio is output from the speaker. Symptom Check points and Countermeasures Check if the power of the product is off or the product is in the standby mode. No image is displayed and no audio is output Check that the cables are connected correctly. from the speaker.
  • Page 84: Maintenance

    7.2 Maintenance Clean and check the product regularly for long-term use. Caution ⚫ Be sure to disconnect the power plug from the outlet before cleaning. ⚫ Rubbing or wiping the screen strongly may scratch the surface of the LCD display. ⚫...
  • Page 85: Specifications

    Specifications 8.1 Product Specifications Model EL55R2 EL65R2 EL75R2 EL86R2 AC:100~240V 50/60Hz Power supply Power 300W 300W 330W 450W consumption 0~40℃ Temperature 20~80%(no condensation) Humidity 15W+15W 15W+15W 15W+15W 15W+15W Speaker VESA 400x400 600x400 800x400 800x600 (M6 screw) (M8 screw) (M8 screw)...
  • Page 86 Touch port KL55R2(HOL),KL65R2(HOL),KL75(HOL),KL86(HOL) is a model without HDMI-out Some specifications may differ depending on the version and destination of ⚫ Note the product. For details, contact the dealer from whom you purchased the product or the nearest ELMO sales office.
  • Page 87: After-Sales Service

    After warranty period Repairable products will be repaired on chargeable basis upon request of the customer. Please contact the dealer from whom you purchased the product or the nearest ELMO sales office. When making a repair request, please inform us of the product name, customer name, address, telephone number, date of purchase, and details of the failure.
  • Page 88 Trademarks is a registered trademark of TECHNO HORIZON CO., LTD. ⚫ Bluetooth is a registered trademark of Bluetooth SIG, Inc. ⚫ Microsoft, Windows, and One Drive are registered trademarks of the Microsoft ⚫ Corporation in the U.S. and other countries. HDMI, HDMI logo, and High-Definition Multimedia Interface are trademarks or registered ⚫...
  • Page 89 テクノホライゾン株式会社 エルモカンパニー OVERSEAS SUBSIDIARY COMPANIES ELMO USA CORP. 〒457-0071 □Headquarters 愛知県名古屋市南区千竈通二丁目 13 番地 1 Web:https://www.elmo.co.jp 6851 Jericho Turnpike Suite 145 製品のお問い合わせは、下記オフィスへ Syosset, NY 11791 Tel. (516) 501-1400 □ 札幌オフィス Fax.(516) 501-0429 〒060-0908 E-mail: elmo@elmousa.com 北海道札幌市東区北 8 条東 3 丁目 1-1 宮村ビル 3 階...
