Summary of Contents for PerkinElmer Peltier N1015158
- Page 1 OPERATING MANUAL Peltier Controlled Fluid Circulator (P/N: N1015158) Web address: http://las.perkinelmer.com/OneSource/Environmental-directives.htm Customer Care: 1-800-762-4000 (inside the USA) (+1) 203-925-4602 (outside the USA) 0800 40 858 (Brussels) 0800 90 66 42 (Monza)
-
Page 2: Table Of Contents
N1015158: OPERATING MANUAL Table of Contents 1. GENERAL INFORMATION 1.1 General warnings 1.2 Quality, reliability and safety 1.3 Safety markings 2. INSTRUMENT DESCRIPTION 2.1 Instrument description 2.2 N1015158 front and rear panel 2.3 Specifications 2.4 User interface 3. INSTALLATION 3.1 Checking the serial number 3.2 Checking main supply and fuses 3.3 Instrument set-up 4. -
Page 3: General Information
N1015158 OPERATING MANUAL 1. GENERAL INFORMATION 1.1. General Warnings Check the voltage selector Always disconnect the mains plug before starting any work inside the instrument Set the temperature to the required values on power on If using substances dangerous for health and the environment, observe the laws and the standards in force in the laboratory where this instrument is used If using flammable or explosive substances take the necessary... -
Page 4: Quality, Reliability And Safety
N1015158 OPERATING MANUAL Quality, Reliability and Safety This equipment has been designed with emphasis on QUALITY, RELIABILITY and SAFETY, and Perkin Elmer will accept responsibility for these aspects only if the following conditions are met: Electrical installation of the room or building in which the equipment is to be used must comply with regulations specified in the country where the equipment is to be used. -
Page 5: Instrument Description
N1015158 OPERATING MANUAL 2. INSTRUMENT DESCRIPTION 2.1. Instrument description The N1015158 is a Peltier effect thermostatting system using an internal sealed liquid circuit allowing full compatibility and connection to all thermostattable accessories. The Peltier effect is based on the reversed thermoelectric effect. This is a phenomenon in which a temperature difference is caused by a flow of current through a closed circuit consisting of two different metals. -
Page 6: N1015158 Front And Rear Panel
N1015158 OPERATING MANUAL 2.2. N1015158 front and rear panel The front and the rear panel have grids to dissipate the heat generated in the unit. Two fans force the air movement. These grids must be free to guarantee the instrument specifications. The front panel features the display with keypad. - Page 7 N1015158 OPERATING MANUAL 2.3.5. External Control Possibilities • USB as standard. 2.3.6. Dimensions Width: 170 mm Height: 280 mm Depth: 430 mm Weight: 6 kg 2.3.7. Electrical data • Mains supply: 115/120 V or 220/240 V t 10% (factory setting 220/240 V) •...
-
Page 8: User Interface
N1015158 OPERATING MANUAL • Room temperature between 10°C and 35°C 2.4. User interface The menu-driven interface of the N1015158 allows the user to set the temperature and to view the configuration. Three buttons are used to access the various functions and change the set parameters. The multi-functional controller with its display is described below under manual operation. -
Page 9: Installation
N1015158 OPERATING MANUAL 3. INSTALLATION 3.1. Checking the serial number The plate containing the serial number is located on the rear panel at the base of the unit. Check that this number is identical to the serial number on the delivery note. If not, please inform Perkin Elmer immediately. -
Page 10: Instrument Set-Up
N1015158 OPERATING MANUAL 3.2.1. Changing the Mains Voltage Setting and Fuses The voltage set is shown in the window of the voltage selector below the mains input connection. To change this setting switch off the unit at the mains switch, remove the mains cable and proceed as follows: •... - Page 11 N1015158 OPERATING MANUAL 3.3.2. External Connections The N1015158 has no special electrical external connections which would allow relay control etc. Operations are performed either manually or via remote control using the USB connections. Contact Perkin Elmer for further information about the remote control functions.
-
Page 12: Operating Instructions
N1015158 OPERATING MANUAL 4. OPERATING INSTRUCTIONS 4.1. Manual operation Main page and functions of the buttons Page Display L button Middle R button button Stand by Stand by Main Normal status Current temperature Menu Modify the Set temperature temperature Heating / cooling power (R) setpoint Temperature setpoint Flashing selected parameter... - Page 13 N1015158 OPERATING MANUAL Configure parameters A password is required to enter this menu. CAUTION: all these parameters are correctly set in the factory: no changes should be made by the user!!! Diagnostic parameters Description Unit of measure Cell temperature °C Radiator temperature °C Water resistance...
-
Page 14: Maintenance
N1015158 OPERATING MANUAL 5. MAINTENANCE The N1015158 requires very little routine maintenance by the user. Any operation that requires the units to be opened must only be performed by Perkin Elmer technicians or authorized personnel. Always unplug from the mains when opening the units 5.1. -
Page 15: Troubleshooting
N1015158 OPERATING MANUAL 6. TROUBLESHOOTING The N1015158 is able to indicate malfunctions and incorrect use. The messages available are directly visible on the display, indicated audibly or transmitted via USB for remote communication. 6.1. Audible alarm The N1015158 will send an audible alarm if either a leakage was detected or another failure occurs. - Page 16 TANK WILL DROP AND WILL NEED TO BE TOPPED UP. ONLY USE THE DISTILLED WATER SUPPLIED IN THE SEPARATE 200CC CONTAINER INSIDE THE PACKAGING TO TOP UP THE WATER IN THE UNIT. Web address: http://las.perkinelmer.com/OneSource/Environmental-directives.htm Customer Care: 1-800-762-4000 (inside the USA) (+1) 203-925-4602...
