- Page 1 OIL FREE AIR COMPRESSOR ITEM :65161...
-
Page 3: Important Notice
IMPORTANT NOTICE Notice In order to operate this air compressor, please read and fully understand instructions contained in this manual before use. This compressor should be only operatated by professional personnel who fully abide by the safety instrucitons contained herein. It is strictly prohibited to change the factory's settings without manufacturer's prior written consent. -
Page 4: Maintenance
01 GENERAL 01 PRESSURE SWITCH USAGE 02 USAGE REQUIREMENTS 02 MAINTENANCE 03 TROUBLESHOOTING CHART 05 PARTS ILLUSTRATION... - Page 5 OIL FREEAIR COMPRESSOR l. Featuring low noise, energy-saving, environmental protection and used securely, this machine is widely used in the fields of medical, sanitation, foodstuff, scientific testing and so forth. 2.Pressure Switch usage: 1).Turnthe pressure switch to "on" or "auto" state, turn on the power, then the machine will start.
- Page 6 WARNINGS: In order to guarantee to operate properly, please cut off the power before below mentioned procedures. 3.Usage Requirements: ° 1 ). The storage & transportation environment must be controlled between -40 C and 50 C, the relative humidity �95%. 2).
- Page 7 1 ). Always make sure the air compressor is clean. 2). Twice per week make sure to clean away all liquid in the tank. Once operating, make sure air tank pressure is below 0. lMpa. 3). To keep the safety valve precise at any conditions, when the air tank pressure reach to between O.
- Page 8 TROUBLESHOOTING CHART POSSIBLE CAUSE(S) PROBLEM CORRECTIVE ACTION Compressor will not run 1.No electrical power. 1.Plu � ged in?Check fuse/breaker. 2.Rep ace blown fuse. 2. Blown fuse. 3.Reset determining why problem Breaker open. happened. Thermal overload open. 4.Molor will restart when cool 5.Pressure switch bad.
- Page 9 STRUCTURE OF AIR PUMP PARTS LIST OF AIR PUMP OLF550/OLF750 Q. TY Q. TY DESCRIPTION DESCRIPTION VALVEPLAIB SIDE COVER INTAKE VALVE LEFTFAN METAL CUSIDON LEFT CRANKCASE RIGHTFAN CONNECT ROD CRANK. PISTONRING FASTEN PLATE BEARING 6006-2Z SCREWM6*8 SCREWM6*16 SCREWM5*20 CYLINDER RIGHT CRANKCASE CYL INDER SEAL RING WIRE FASTEN RING CYLINDER COVER SEAL RING...
- Page 10 STRUCTURE OF AIR PUMP PARTS LIST OF AIR PUMP Q. TY Q. TY DESCRJPTION DESCRIPTION SCREWST4.2 SCREWM4•6 SIDE COVER FASTEN PART LEFfFAN EXHAUSTVALVE SCREWM5 VALVE PLATE LEFf CRANKCASE INTAKEVALVE ADJUSTABLE HOLDER METAL CUSIIlON SCREWM5•20 CONNECT ROD CRANK PISTONRING BEARING 6908-2Z FASTEN PLATE SCREWM6•8 SCREWM6•!6...
-
Page 12: Warranty
WARRANTY PLEASE READ THE FOLLOWING CAREFULLY THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT.
