DIGITAL / ANALOG TRAINER
MODEL XK-550K
A COMPLETE MINI-LAB FOR BUILDING, TESTING
AND PROTOTYPING ANALOG AND DIGITAL CIRCUITS
Tools and meter shown not included.
Assembly & Instruction Manual
Elenco Electronics, Inc.
Copyright © 1995 Elenco Electronics, Inc.
Revised 1999
REV-F
753550K

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XK-550K and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Elenco Electronics XK-550K

Summary of Contents for Elenco Electronics XK-550K

  • Page 1 DIGITAL / ANALOG TRAINER MODEL XK-550K A COMPLETE MINI-LAB FOR BUILDING, TESTING AND PROTOTYPING ANALOG AND DIGITAL CIRCUITS Tools and meter shown not included. Assembly & Instruction Manual Elenco Electronics, Inc. Copyright © 1995 Elenco Electronics, Inc. Revised 1999 REV-F 753550K...
  • Page 2 XK-550K POWER SUPPLY KIT (PS-550-B) PARTS LIST SYMBOL VALUE R1, R2 VR1, VR2 100K SYMBOL VALUE C6 - C10 .1 F 100V C11 - C17 100 F C1, C2, C4, C5 1000 F 35V 2200 F 25V SYMBOL DESCRIPTION r 15 D1 - D15...

  • Page 3: Parts Verification

    PARTS VERIFICATION Before beginning the assembly process, first familiarize yourself with the components and this instruction book. Verify that all parts are present. This is done best by checking off each item in the parts list. RESISTORS Trim Pot IDENTIFYING RESISTOR VALUES Use the following information as a guide in properly identifying the value of resistors.
  • Page 4 Introduction Assembly of your XK-550 Digital/Analog Trainer Kit will prove to be an exciting project and give you much satisfaction and personal achievement. If you have experience in soldering and wiring techniques, then you should have no problem with the assembly of this kit.

  • Page 5: Power Supply Specifications

    POWER SUPPLY The XK-550K has five built-in power supplies which will satisfy most design needs. This includes two variable power supplies giving up to +20 volts and -20 volts at .5 amp. Below 15V, the current available is 1 amp. Three fixed power supplies give you +12VDC, -12VDC or +5VDC at 1 amp each.

  • Page 6: Start Here

    INSTALL COMPONENTS TO PC BOARD START HERE ê r S1 - 5-Pin Connector (see Figure A) r L-Bracket (see Figure B) r VR4 - 100K r VR3 - 1K (see Figure C) r S3 - 3-Pin Connector r S2 - 3-Pin Connector (see Figure A) r L-Bracket (see Figure B)
  • Page 7 INSTALL COMPONENTS TO PC BOARD START HERE ê r C11 - 100 F 25V (see Figure E) r R1 - 120 5% 1/4W Resistor (brown-red-brown-gold) r C6 - .1 F Mylar (104) (see Figure D) r J28 - Jumper Wire (see Figure F) r J6 - Jumper Wire (see Figure F)
  • Page 8 INSTALL COMPONENTS TO PC BOARD Bottom Left Corner of PC Board Figure H Hold the bredblock down flush to the PC board from the top legend side and solder the metal pins in place. Then, melt the plastic pins with your soldering iron to hold the plastic blocks in place, as shown.
  • Page 9 INSTALL COMPONENTS TO PC BOARD START HERE ê r C2 - 1000 F 35V Lytic r C4 - 1000 F 35V Lytic (see Figure I) r C1 - 1000 F 35V Lytic r C5 - 1000 F 35V Lytic (see Figure I) Figure I These lytics must be mounted hori- zontal to the PC board.

  • Page 10: Mounting The Pc Board

    MOUNTING THE PC BOARD Note: The holes in the two side panels have been punched differently. Be sure that you have the correct side panel when mounting them to the PC board. r Mount the PC board with four 4-40 x 1/4” screws (see Figure K). Do not tighten the screws. Note: From the foil side of the PC board, inspect the edges to be sure that there are no component leads shorting against...
  • Page 11 Figure L MOUNT COMPONENTS TO THE SIDE PANELS Mount U1, U3 and U5 to the left side panel as shown in Figure N. Insert the pins of each IC into the holes of the PC board. Then, with the hardware shown in Figure M, attach each IC to the side panel. Solder the pins of the ICs to the PC board.
  • Page 12 Mount U2 and U4 to the right side panel as shown in Figure O. Insert the pins of each IC into the holes in the PC board. Then, with the hardware shown in Figure MA, attach each IC to the side panel. Solder the pins of the ICs to the PC board.
  • Page 13 HOW TO INSTALL CONNECTORS ONTO TRANSFORMER WIRES A connector will be placed in the primary wires of the transformer. This will allow you to remove the top panel from the trainer. Follow the procedures below. 1. Cut a six inch length off of each black primary wire. 2.
  • Page 14 MOUNT COMPONENTS TO PANEL r Push the illuminated switch into the hole in the top panel with the lugs as shown in Figure Q. r Install the fuse holder with the side lug in the position shown in Figure Q. Fasten the fuse holder in place with the nut as shown in Figure R.
  • Page 15 WIRE SWITCH AND FUSE HOLDER (see Figure U) Fuse r Slide the line cord bushing onto the line cord as shown in Figure U. r Spread the three line cord wires apart 6” from the end. r Strip the insulation off of both ends of the 6” red wire to expose 1/4” of bare wire. Pass the wire through the 1/2”...
  • Page 16 RESISTANCE ANALYSIS OF POWER SUPPLY Static testing of the power supply circuits. Do not plug the power supply into the 120VAC power supply source until all resistance readings check out. The values given below are approximate. See Figure O for locations of testing points. From Right Side Panel GND 5-pin connector...
  • Page 17 Locations for Testing Points LM-7812 ••• ••• LM-7805 LM-7912 ••• ••• LM-317 Figure O -16- Plug of line cord On test points 4 - 14 use the leads of the diodes. 5 pin connector right 5 pin connector -20 5 pin connector +20 5 pin connector left •••...

  • Page 18: Fuse Replacement

    VOLTAGE ANALYSIS OF POWER SUPPLY Proceed with the voltage analysis only if the resistance readings were satisfactory. Place the top panel on the unit. If any capacitors are inserted backwards, the panel will shield you if they explode. Make sure that the ON/OFF switch is in the OFF position. Plug the line cord into the 120VAC power source.

  • Page 19: Power Supply Testing

    POWER SUPPLY TESTING Plug the trainer into a 120VAC outlet and switch to the “ON” position (the power switch should light). With a dig- ital voltmeter, measure the voltage outputs at the power blocks. The +12V should measure between 11.4 and 12.6 volts.
  • Page 20 PROBLEM No voltage at negative variable output. No or low voltage at negative variable output with load. No +12V at output. No +12V at output with load. No -12V at output. No -12V at output with load. No +5VDC at output No +5VDC at output with load.

  • Page 21: Final Assembly

    FINAL ASSEMBLY If you are immediately going to build the remaining sections, do not continue with the instructions on this page and proceed to page 22. r Fasten the front panel in place with four #6 x 3/8” thread cutting screws, as shown in Figure W.
  • Page 22 INSTALL COMPLETED UNIT INTO CASE r Latch the case lid down. Remove the protective backing from the case label. Stick the label in the depres- sion in the middle of the case lid. r Tie a knot in the line cord 12” from the switch. See Figure AA for the location of the line cord hole in the case.

  • Page 23: Circuit Description

    CIRCUIT DESCRIPTION The power supply features two variable output voltages and three fixed 12V, -12V and 5V variable output voltages are 1.25V to 20V and -1.25 to -20V at up to 1 ampere maximum current. All supplies are regulated to better than .2V when going from no load to full load.
  • Page 24 In practice, the current through the diodes is not as shown in Figure 2C. Because capacitor C1 has a charge after the first cycle, the diode will not conduct until the positive AC voltage exceeds the positive charge in the capacitor.
  • Page 25 Test Point 2200 F REV-E...
  • Page 26 QUIZ - POWER SUPPLY SECTION INSTRUCTIONS - Complete the following examination and check your answers carefully. 1. AC voltage is supplied to the rectifier stages by the . . . r A. step-up transformer. r B. step-down transformer. r C. 1 to 1 transformer. r D.
  • Page 27 XK-550 ANALOG KIT (AN-550-C) PARTS LIST SYMBOL VALUE R14, R44 R46, R47 5% 1/4W 5% 1/4W R7, R11 4.7K 6.8K 8.2K R4, R45, R48 100K TRIM POT VR6, VR7 100K SYMBOL VALUE 5pF (5) 22pF (22) 100pF (101) .001 F (102) .0022 F (222) .01 F (103) .1 F (104)

  • Page 28: Specifications

    INTRODUCTION - ANALOG SECTION The Analog Section of your trainer contains a complete function generator capable of producing sine, square, and triangle waveforms. The frequency of this generator can be continuously varied from 1 hertz to over 100,000 hertz in five steps: 10, 100, 1K, 10K, and 100K. A fine frequency control makes selection of any fre- quency in between easy.

  • Page 29: Start Here

    INSTALL COMPONENTS TO PC BOARD START HERE ê r J9 - Jumper Wire (see Figure A) r C25 - .0022 F (222) Discap r J10 - Jumper Wire r J25 - Jumper Wire (see Figure A) r VR8 - 100K Trim Pot (see Figure E) r C26 - 22pF (22) Discap r C23 - 100pF (101) Discap...
  • Page 30 INSTALL COMPONENTS TO PC BOARD START HERE ê r B6 - 4 pin Bredblox (see Figure F) r D16 - 1N4148 Diode (see Figure G) r R14 - 100 5% 1/4W Resistor (brown-black-brown-gold) r B5 - 4 pin Breadblox (see Figure F) r R12 - 1K 5% 1/4W Resistor (brown-black-red-gold)
  • Page 31 INSTALL COMPONENTS TO PC BOARD START HERE ê r J18 - Jumper Wire (see Figure A) r R13 - 8.2K 5% 1/4W Resistor (gray-red-red-gold) r J17 - Jumper Wire (see Figure A) r C18 - .001 F (102) Mylar (see Figure EA) r R6 - 12K 5% 1/4W Resistor (brown-red-orange-gold)
  • Page 32 RESISTANCE ANALYSIS OF ANALOG SECTION Static testing of the analog circuits. Do not plug in the power supply into 120VAC power source until all resistance readings check out. The values given below are approximated. SET SW3 TO SQUARE WAVE (refer to top panel From ª...
  • Page 33 VOLTAGE ANALYSIS OF ANALOG SECTION Proceed with the voltage analysis only if the resistance readings were satisfactory. The values given below are approximate. The following measurements will be taken from the copper side of the PC board. Turn the unit on and place it upside down.
  • Page 34 5. Set VR8 fully clockwise from the copper side of the PC board, and adjust the DC OFFSET knob until the meter reads 0 volts DC. 6. Set the meter to the 20 volts AC range and slowly turn VR8 counter-clockwise until the meter reads 5.5 volts AC.

  • Page 35: Final Assembly

    FINAL ASSEMBLY If you are immediately going to build the remaining section, do not continue with the instructions on this page, proceed to page 35. r Fasten the front panel in place with four #6 x 3/8” thread cutting screws, as shown in Figure K. r Fasten the PC board to the spacer to the front panel with a fiber washer and a 4-40 x...
  • Page 36 CIRCUIT DESCRIPTION The function generator frequencies are produced by an XR2206 integrated circuit. This IC is capable of producing high quality sine, square and triangle waveforms of high stability and accuracy. The output waveform can be both amplitude and frequency modulated by an external voltage.
  • Page 37 SCHEMATIC DIAGRAM - ANALOG SECTION -36-...
  • Page 38 INTRODUCTION The Digital Section is the fourth package of the XK-550K kit that you are building. The Digital Section of your trainer contains all of the necessary functions to do your digital designs. They consist of a clock generator, two no bounce logic switches, 8 LED indicator lamps and 8 data switches.
  • Page 39 USERS DESCRIPTION OF FRONT PANEL 1. OUTPUT TERMINALS - For all functions as stated. 4 pins per block. 2. TWO LOGIC SWITCHES - These are no bounce logic switches. Give one signal state change per move- ment of switch. 3. INPUT TERMINALS FOR LOGIC INDICATOR LEDs - “A” input corresponds with “A” lamp, etc. 4.
  • Page 40 INSTALL COMPONENTS TO PC BOARD START HERE ê r R34 - 100K 5% 1/4W Resistor (brown-black-yellow-gold) r R35 - 100K 5% 1/4W Resistor (brown-black-yellow-gold) r R33 - 100K 5% 1/4W Resistor (brown-black-yellow-gold) r R32 - 100K 5% 1/4W Resistor (brown-black-yellow-gold) r R28 - 100K 5% 1/4W Resistor (brown-black-yellow-gold) r R27 - 100K 5% 1/4W Resistor...
  • Page 41 INSTALL COMPONENTS TO PC BOARD START HERE ê r R43 - 120 5% 1/4W Resistor (brown-red-brown-gold) r R42 - 120 5% 1/4W Resistor (brown-red-brown-gold) r S5 - 4 pin connector (see Figure A) r R41 - 120 5% 1/4W Resistor (brown-red-brown-gold) r R40 - 120 5% 1/4W Resistor...
  • Page 42 INSTALL COMPONENTS TO PC BOARD START HERE ê r U9 - 14-pin IC Socket r U9 - 74HC04 IC (see Figure D) CONTINUE ê r U8 - 14-pin IC Socket r U8 - 74HC04 IC (see Figure D) r J19 - Jumper Wire (see Figure C) r R15 - 220 5% 1/4W Resistor...
  • Page 43 INSTALL COMPONENTS TO PC BOARD r SW4 - Slide Switch r SW5 - Slide Switch START HERE r SW6 - Slide Switch r B7 - 4-pin Bredblox r B8 - 4-pin Bredblox CONTINUE r B9 - 4-pin Bredblox r B10 - 4-pin Bredblox Figure E Hold the bredblox down flush to the PC board from the top legend side and sol-...
  • Page 44 RESISTANCE ANALYSIS OF DIGITAL SECTION Place the top panel onto the unit. Static testing of the digital section circuits. Do not plug the power supply into a 117 volt power source until all of the resistance readings check out. The values given below are approxi- mate.
  • Page 45 VOLTAGE ANALYSIS OF DIGITAL SECTION Plug the power supply into a 117 volt power source. The values given below are approximate. From Switch Position In up position In up position In up position In up position In up position In up position In up position In up position In up position...
  • Page 46 TESTING THE DIGITAL SECTION TESTING THE LOGIC INDICATOR FUNCTION There are eight logic indicators which you will be checking out. Put a wire to the 5V power supply and touch the “A” logic indicator test pin. The “A” LED should light up. Remove the wire and the LED should go out. Do the same for the B, C, D, E, F, G and H pins.
  • Page 47 FINAL ASSEMBLY r Fasten the front panel in place with four #6 x 3/8” thread cutting screws, as shown in Figure I. r Fasten the PC board to the spacer to the front panel with a fiber washer and a 4-40 x 1/4” screw (from Power Supply Section) from the foil side of the PC board, in the location shown in Figure J.
  • Page 48 INSTALL COMPLETED UNIT INTO CASE r Tie a knot in the line cord 12” from the switch location. Feed the line cord between the cross bracket and the PC board. r Locate the line cord hole in the case (see Figure N). Insert the line cord into the hole through the slot. To open up the slot, press down on one side of the slot (see Figure O).
  • Page 49 CIRCUIT DESCRIPTION - DIGITAL SECTION THE DATA SWITCHES There are eight data switches labeled SW1 through SW8. The circuit is very simple. To perform the desired functions, there is a double throw double pole switch, wired as a single pole double throw. One end is connected to the 5V, the other to ground and the center lug is connected to the output.

  • Page 50: Schematic Diagram

    SCHEMATIC DIAGRAM -49-...
  • Page 51 QUIZ - DIGITAL SECTION INSTRUCTIONS: Complete the following examination, check your answers carefully. 1. The logic switches consist of . . . r A. two NAND gates and an SPST switch. r B. three OR gates. r C. two NAND gates and a DPDT switch. r D.
  • Page 52 Elenco Electronics, Inc. 150 W. Carpenter Ave. Wheeling, IL 60090 (847) 541-3800 Web Site: http://www.elenco.com e-mail: elenco@elenco.com...
