- Page 1 Bush Baby Stealth Manual For Custom-Built Products THANK YOU FOR PURCHASING YOUR BBS CAMERA Version 2.1...
- Page 2 1 x Charging Adapter with Indicator Lights 1 x MicroUSB Cable 1 x Removable Battery 1 x Wall AC Adapter 1 x MicroSD Card Reader 1 x 16GB MicroSD Card 1 x User Manual GET FAMILIAR WITH YOUR BBS CAMERA Version 2.1...
- Page 3 Version 2.1...
- Page 4 Version 2.1...
- Page 5 BEFORE YOU START To preserve battery power, your product will come with the battery connector disconnected. Before attempting to use the device, be sure to connect the battery’s connector to the circuit board power lead (red plastic pieces at the end of black and red wires).
- Page 6 OPERATING THE BUSHBABY STEALTH CAMERA IMPORTANT NOTICE: Allow the device to charge 6 – 8 hours before using. REMOVING AND CHARGING THE BATTERY 1. Remove battery from your device. 2. Disconnect the battery connector that is connecting the battery to the circuit board. Be careful not to pull on the wires as that could damage them –...
- Page 7 a. The larger the battery capacity, the longer it takes to charge. HOW TO TURN ON THE BUSHBABY STEALTH CAMERA 1. Press the Power Button on the remote control one time (see page 3). 2. The device is automatically in Standby mode.
- Page 8 1. While the camera is in standby mode, hold the “C” button for 3 seconds then release. 2. The unit will vibrate three times. When the device stops vibrating, the camera is recording 1080P video. 3. To save video and return to standby mode, quickly press the “C”...
-
Page 9: Microsd Card Slot
HOW TO TAKE PICTURES 1. When the camera is in Standby Mode, press the “C” button (see page 3). The unit will vibrate, and then take a picture. It then returns to standby mode. MICROSD CARD SLOT To access the MicroSD Card Slot, you must check inside the hat’s bill to find the camera board. - Page 10 3. To remove the SD card, gently push the card in so that it clicks. 4. The internal spring tension will eject the card. 64GB and 128GB microSD cards will require special formatting to work. The device will not function with these cards if they are not properly formatted beforehand.
- Page 11 1. Connect the MicroSD card to your computer using the MicroSD card USB adapter. (The Micro SD card is located on the side of the camera board.) 2. Locate “Removable Disk” inside the (My) Computer folder. AutoPlay Removable Disk > Open folder to view files Version 2.1...
- Page 12 Or… Go to Start > Computer > Removable Disk 3. Open the Removable Disk drive. 4. Open the DCIM folder. 5. Open the folder featuring a sequence of numbers. 6. Double click the file you want to view. VLC Player is recommended for watching videos.
- Page 13 we recommend you use VLC media player to play back the videos. It can be downloaded for free from www.videolan.org COPYING AND DELETING YOUR FILES The video files created are just like any other file on your computer, and can be managed in the exact same manner.
- Page 14 not done, the SD card will fill with hidden files and the Bottle will no longer record new files. SETTING THE TIME AND DATE ON THE VIDEO FILES You will need to remove the MicroSD card from your device and plug it into your computer using the provided card reader.
- Page 15 5. Open the Removable Disk drive. 6. Right click with your mouse and paste the downloaded time file. Alternatively, if you cannot get the above method to work, do the following: 7. Right click anywhere in the blank white space. 8.
- Page 16 Before Step 8 After Step 8 11. Open the text document. 12. Enter the date/time in the following format: a. Example: 2016/08/08 15:00:00 13. Save the text document. Version 2.1...
-
Page 17: Troubleshooting
14. Safely eject the MicroSD card from your computer and reinsert it into your device. Power on the device and begin a test recording to confirm date/time setting succeeded. TROUBLESHOOTING THE DEVICE WON’T TURN ON Charge the device for at least 6-8 hours before the first use. - Page 18 You need to reset the device. o Disconnect and reconnect the battery. MY COMPUTER DOESN’T RECOGNIZE THE DEVICE Try using a different USB slot on your PC. THE VIDEO IS UNCLEAR The device needs charging. THE INDICATOR LIGHT IS ON, BUT THE CAMERA WILL NOT RECORD VIDEO OR TAKE PHOTOS ...
-
Page 19: Other Problems
THE INDICATOR LIGHT IS FLASHING RED/BLUE There is no SD card in the device. OTHER PROBLEMS Call our technical support at 770–694– 6921 Version 2.1... -
Page 20: Specifications
SPECIFICATIONS Video 1080P Resolution 720P Video Format .AVI Frames per Up to 30 FPS Second Vision Angle 75° Motion 6 meters for straight- Detection line distance Photo 4032 x 3024 Resolution Photo Format .JPG Type of Memory External MicroSD Memory Up to 128GB Capacity Recording... - Page 21 Version 2.1...
- Page 22 Version 2.1...
- Page 23 Version 2.1...
- Page 24 QUALITY CONTROL CHECKLIST ☐ BBS Remote ☐ Wall AC Adapter ☐ MicroUSB Cable ☐ MicroSD Card ____GB ☐ MicroSD Card Reader ☐ Removable Battery ☐ Charging Adapter with Indicator Lights ☐ User Manual ☐ Bush Baby Stealth Camera ☐ With Audio ☐...
